Tyger LanderX TG-LX3F84628 Manual

TYGER LanderX
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY
DAMAGE BEFORE INSTALLATION COULD LEAD TO A
REJECTION OF ANY CLAIM. IF MISSING PARTS OR ANY
DAMAGE FOUND, PLEASE TAKE A PICTURE FOR THE
CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
x1
Driver/Left TYGER LanderX
x1
Passenger/Right TYGER LanderX
x3 Mounting Brackets [A]
ATTENTION: Refer to
Front
Front
x12
Hex Bolts
Customer Support: www.tygerauto.com/contact
D
x3 Mounting Brackets [B]
P
x12
10-1.5mm x 30mm Hex Bolts
x12
8-1.25mm x 25mm Combo Bolts
D P
and labelling on the side of the tubes to determine Driver and Passenger LanderX
x3
[A]
Mounting Brackets
x12
Combo Bolts Lock Washers
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
x12
10mm Lock Washers
x18
10mm x 27mm x 3mm Flat Washers
x 6
10mm Hex Nuts
Top View
P
Passenger Side LanderX
D
Driver Side LanderX
x3
[B]
Mounting Brackets
x12 x18
Flat Washers
1/4
TG-LX3F84628
Class 10.9 Torque (ft-lbs)
6-7
15-16
31-32
54-55
87-88 125-126
x 6
10mm Clip Nuts
x6 x6
Clip Nuts
Hex Nuts
6-7
22-23
44-45
78-79
V240322
