TYGER LanderX
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY
DAMAGE BEFORE INSTALLATION COULD LEAD TO A
REJECTION OF ANY CLAIM. IF MISSING PARTS OR ANY
DAMAGE FOUND, PLEASE TAKE A PICTURE FOR THE
CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
Driver/Left TYGER LanderX
x1
Passenger/Right TYGER LanderX
x1
Driver/Left Mounting Brackets
x3
Reference the letters printed on the brackets to determine mounting locations
Front
B
Customer Support: www.tygerauto.com/contact
Passenger/Right Mounting Brackets
x3
8-1.25mm Clip-On Nuts
x12
A
8-1.25mm x 25mm Combo Bolts
x12
A
Driver/Left TYGER LanderX
Passenger/Left TYGER LanderX
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
15-16
10mm
31-32
12mm
54-55
14mm
87-88
B
A
B
1/4
TG-LX3C82388
Class 10.9 Torque (ft-lbs)
6-7
22-23
44-45
78-79
125-126
8-1.25mm x 30mm Hex Bolts
x12
8mm x 24mm x 2mm Flat Washers
x12
8mm Lock Washers
x12
B
6-7
A
Front
V230628
Advertisement
Related Manuals for Tyger LanderX TG-LX3C82388
Summary of Contents for Tyger LanderX TG-LX3C82388
- Page 1 78-79 CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT: 14mm 87-88 125-126 WWW.TYGERAUTO.COM/CONTACT Driver/Left TYGER LanderX Passenger/Right Mounting Brackets 8-1.25mm x 30mm Hex Bolts Passenger/Right TYGER LanderX 8-1.25mm Clip-On Nuts 8mm x 24mm x 2mm Flat Washers Driver/Left Mounting Brackets 8-1.25mm x 25mm Combo Bolts...
