MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.)
(BBMAX12T+MF5)
TEL：1-866-XANATOS
INSTALLATION INSTRUCTIONS
MAX T BULL BAR FOR 2004-2020 Ford F150 (Exclude Raptor, Ecoboost
And 2004 Heritage Edition.) (BBMAX12T+MF5)
PART # MBT-MF512
Page 1 of 10
Advertisement
Table of Contents
Related Manuals for Black Horse Off Road MBT-MF512
Summary of Contents for Black Horse Off Road MBT-MF512
- Page 1 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) TEL：1-866-XANATOS INSTALLATION INSTRUCTIONS MAX T BULL BAR FOR 2004-2020 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) PART # MBT-MF512 Page 1 of 10...
-
Page 2: Before Installation
MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) Before Installation ⚫ Please read the instruction carefully before starting installation, which will help you to avoid scratches or other potential damages to your appealing car. ⚫... -
Page 3: Installation Steps
MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) ○ ○ Bolt Plates M12_40 U-Bolts M10x143.5 ○ ○ M6_20 Hex Bolts M6_20 Combo Bolts ○ ○ Hex Bolts M10_35 Hex Bolts M8_35 ○ ○... - Page 4 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) STEP 1: Determine if the vehicle is equipped with tow hooks, (Fig 1). Vehicles with Factory Tow Hooks (NOTE: Tow hooks cannot be reinstalled) a.
- Page 5 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) c. Repeat to install the passenger side Frame Bracket. d. Skip to Step 2. All vehicles without Tow Hooks Remove the lower plastic portion of the bumper to gain access to the ends of the frame rails, (Fig 4).The lower bumper or splash guard will need to be cut out to allow the Mounting Brackets and end of Bull Bar to pass through, (Step 4).
- Page 6 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) b. Attach the Bracket to the Bolt Plates with (2) 12mm Flat Washer, (2) 12mm Lock Washers and (2) 12mm Hex Nuts, (Fig 7). c.
- Page 7 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) b. Attach the driver side Frame Bracket to the U-Bolt with (2) 10mm Flat Washers and (2) 10mm Nylon Lock Nuts, (Fig 10). c. Snug but do not tighten the hardware. d.
- Page 8 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) STEP 3: With assistance, line up the mounting tabs on the Bull Bar with the inside of the (2) previously installed Frame Mounting Brackets. Attach the Guard to the Brackets with the included (4) 10mm x 35mm Hex Bolts, (8) 10mm Flat Washers, (4) 10mm Lock Washers and (4) 10mm Hex Nuts, (Fig 13).
- Page 9 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) Front Front (Fig 15) Only cut enough to clear the Brackets Fig 14 Do not cut through the front or rear edges of the cover. STEP 5: Install the License Plate Bracket a.
- Page 10 MAX T BULL BAR FOR 2004-2019 Ford F150 (Exclude Raptor, Ecoboost And 2004 Heritage Edition.) (BBMAX12T+MF5) STEP 6: Complete Installation NOTE Any damages and losses caused by improper installation and application, goes beyond our quality warranty. Page 10 of 10...
