- Page 1 BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA RAV4 06-18 INSTALLATION INSTRUCTIONS BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA RAV4 06-18 PART #MBB-TOB4401 Page 1 of 5...
-
Page 2: Before Installation
BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA RAV4 06-18 Before Installation ⚫ Please read the instruction completely for easy installation, which will also help you to avoid scratches or other potential damages to your appealing car. ⚫ The figures here are for reference only and may have differences with the actual product you received, however they share the same assembly way. - Page 3 BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA RAV4 06-18 Installation Figure Installation Steps STEP1: Verify all parts are present. Fig (1) STEP2: Remove the skid plate as Fig 1 shows. Page 3 of 5...
- Page 4 BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA RAV4 06-18 Use the original car bolts to install Front STEP3: Check the mounting holes under the vehicle. Then use original bolts to install the L/R brackets on the vehicle STEP4: After the brackets are installed, reinstall the skid plate. At this time, the brackets will be interfered the skid plate.
- Page 5 BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA RAV4 06-18 STEP5: Adjust the bull bar to the proper position. Then lock all the standard parts on the L/R brackets. Complete installation. NOTE Any damages and losses caused by improper installation and application, goes beyond our quality warranty.
