Black Horse Off Road B39 Installation Instructions

TEL:1-866-XANATOS
MOUNT KIT
B39
QTY
2 MOUNT BRACKET
2 ADAPTER BRACKET
2 NUT PLATES (PASSENGER, DRIVER)
4 M12×60N HEX BOLT
2 M12×50 HEX BOLT
4
M12 HEX NUT
Φ12 SAE FLAT WASHERS
10
Φ12 LOCK WAHERS
6
4 M10×25 HEX BOLT
Φ10 FLAT WASHER
4
Φ10 SPLIT LOCK WAHSER
4
STEP1: REMOVE THE CONTENTS FROM THE BOX AND CHECK FOR ANY DAMAGE. VERIFY ALL
PARTS AGAINST PARTS LIST.
STEP2: READ AND UNDERSTAND INSTRUCTIONS COMPLETELY BEFORE BEGINNING
INSTALLATION.NOTE:IF YOUR VEHICLE IS EQUIPPED WITH FACTORY TOW HOOKS, YOU
WILL NEED TO REMOVE THEM, LEAVING THEIR BRACKETS IN PLACE BEFORE
PROCEEDING.
STEP3: REMOVE HORNS ON PASSENGER SIDE USING 13 MM SOCKET.
VEHICLE WITHOUT TOW HOOKS
STPE4: INSTALL BRACHETS USING M10 FASTENERS AND NUT PLATES AS SHOWN IN FIGURE
1.2 AND 3.LEAVE LOOSE. (BEND NUT PLATES TO ACHIEVE PROPER ALIGNMENT WHEN
PLACING INSIDE THE FRAME. NUT PLATES SHOULD LINE UP HOLES A AND B IN FRAME.
SEE FIGURE 2 AND 3. PROCEED TO STEP 7.
VEHICLE WITH TOW HOOKS
STEO5: INSTALL ADAPTER BRACKETS USING ORIGINAL FASTENERS. SEE FIGURE 4,5 AND
6.
STEP6: INSTALL TOW HOOKS AS SHOWN IN FIGURE 6. STRAIGHTEN TOW HOOKS (SEE STEP
8).
STEP7: MOUNT SAFARI BAR USING M12 FASTENERS AS SHOWN IN FIGURE 3 AND 4.
STEP8: CENTER AND LEVEL SAFARI BAR.
INSTALLATION INSTRUCTIONS
APLICATION 92-98 JEEP GRAND CHEROKEE
PARTS KIT CONTENTS
DESCRIPTION
TIGHTEN AND TORQUE FASTENERS AS LISTED.
TOOLS REQUIRED
13MM SOCKET
15MM SOCKET
18MM WRENCH
9/16" SOCKET
3/4"SOCKET
3/4" WRENCH
RATCHET
3" EXTENSION
Page 1 of 2
