- Page 1 MAX T BULL BAR FOR 2010-2019 Toyota 4Runner (Exclude 14-19 Limited)(BBMAX12T+MT03) TEL：1-866-XANATOS INSTALLATION INSTRUCTIONS MAX T BULL BAR FOR 2010-2020 Toyota 4Runner (Exclude 14-19 Limited) (BBMAX12T+MT03) PART # MBT-MT0312 Page 1 of 7...
-
Page 2: Before Installation
MAX T BULL BAR FOR 2010-2019 Toyota 4Runner (Exclude 14-19 Limited)(BBMAX12T+MT03) Before Installation ⚫ Please read the instruction completely for easy installation, which will also help you to avoid scratches or other potential damages to your appealing car. ⚫ The figures here are for reference only and may have differences with the actual product you received, however they share the same assembly way. - Page 3 MAX T BULL BAR FOR 2010-2019 Toyota 4Runner (Exclude 14-19 Limited)(BBMAX12T+MT03) ○ ○ LICENSE PLATE BRACKET2 M6_20 FLAT WASHER D8_22_2 ○ ○ FLAT WASHER D10_27_3 FLAT WASHER M10_35 ○ ○ HEX BOLT M8_35 HEX BOLT M6 ○ ○ NYLON LOCK NUT M10 HEX BOLT M6_20 ○...
- Page 4 MAX T BULL BAR FOR 2010-2019 Toyota 4Runner (Exclude 14-19 Limited)(BBMAX12T+MT03) during bracket installation. Remove plastic center and (2) side splash guards Fig 1 STEP 2: Starting on the driver side, remove the (3) factory bumper mount bolts located toward the outside of the bumper mount, (Fig 2).
- Page 5 MAX T BULL BAR FOR 2010-2019 Toyota 4Runner (Exclude 14-19 Limited)(BBMAX12T+MT03) STEP 4: Carefully unwrap the Guard. Select (1) driver side Tube Mounting Bracket. Attach the Bracket to the end of the Guard with (2) 8mm Hex Bolts, (2) 8mm Lock Washers and (2) 8mm Flat Washers, (Figs 4-5).
- Page 6 MAX T BULL BAR FOR 2010-2019 Toyota 4Runner (Exclude 14-19 Limited)(BBMAX12T+MT03) STEP 8: Install the license plate as the picture shown Step A. Connect the license plate bracket1 to guard by Combo bolt M6_20. Step B. Connect the license plate bracket 1 with license plate bracket 2 by (2) HEX BOLT M6_20; (2) FLAT WASHER D6;(2) LOCK WASHER D6;(2) HEX NUT M6.
- Page 7 MAX T BULL BAR FOR 2010-2019 Toyota 4Runner (Exclude 14-19 Limited)(BBMAX12T+MT03) STEP 10: Do periodic inspections of the installation to make sure that all hardware is secure and tight. Cut out area illustrated as an example only Front (Fig 8) Driver/left side splash guard pictured Complete Installation NOTE Any damages and losses caused by improper installation and application, goes beyond our quality...
