Black Horse Off Road MBB-FOB2901 Installation Instructions

TEL˜ 1-866-XANATOS
MAX BULL
BAR
BLACK
PART NUMBER
MBB-FOB2901
QTY
SAFARI BAR ASSEMBLY (PURCHASED SEPARATELY
1 MOUNT BRACKET-PASSENGER SIDE
1 MOUNT BRACKET-DRIVER SIDE
1 M12×50 HEX HEAD BOLT
Φ12 FLAT WASHER
2
Φ12 HELICAL SPLIT LOCK WASHER
2
2 M10×30 HEX HEAD BOLT
Φ10 FLAT WASHER
6
Φ10 LOCK WAHSER
12
6 M10 BOLT PLATE
4 M10 HEX NUT
6 NOTE: SOME FASTENERS MAY NOT BE USED.
FASTENERS ARE CONTAINED IN BOLT KITS 60-1156
AND 60-1220
STEP1. Remove the contents from the box and check for any damage. Verify all
parts against parts list.
STEP2. Read and understand instructions completely before beginning
installation.
STEP3. Determine driver and passenger side brackets. Locate the oblong and two
round holes just below the body mount on the bottom side of frame.
STEP4. Insert one bolt plate through the oblong hole in bottom of frame on
passenger side. Position it over one of the round holes. Start the M10
bolt, flat washer and lock washer into the bolt plate. Repeat for the
remaining round hole. See Figure 1.
STEP5. Slide bracket on to the two M10 bolts. Make sure the washers are to the
INSTALLATION INSTRUCTIONS
APLICATION : 2002-2005 Ford Explorer & 2002-2005
Mercury Mountaineer
PARTS KIT CONTENTS
DESCRIPTION
Page 1 of 2
TOOLS REQUIRED
3/4"SOCKET
9/16 SOCKET
SOCKET EXTENSION
RATCHET
TORQUE WRENCH
