- Page 1 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) TEL：1-866-XANATOS INSTALLATION INSTRUCTIONS MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.) (BBMAX12T+MR13) PART # MBT-MR1312 Page 1 of 11...
-
Page 2: Before Installation
MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) Before Installation Please read the instruction carefully before starting installation, which will help you to avoid scratches or other potential damages to your appealing car. The figures here are for reference only and may have differences with the actual product you received, however they share the same assembly way. - Page 3 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) ○ ○ Mounting Bracket (R) Support Bracket (L) ○ ○ Support Bracket (R) License Plate Bracket 1 ○ License Plate Bracket 2 ○ ○ Combo Bolts M6_20 Hex Bolts M6_20 ○...
-
Page 4: Installation Steps
MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) Installation Steps Installation Fig. STEP 1: Start installation under the front bumper and carefully remove the plastic splash guard. NOTE: Depending on the model of vehicle, the splash guard may be attached to the bottom of the truck with hex bolts and several two-piece plastic push-in clips, (Fig 1A). - Page 5 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) STEP 2: Next, determine if the truck is equipped with tow hooks. For models without tow hooks: a. Remove the hex nuts from the two lower bumper bolts, (Fig 2). b.
- Page 6 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) (1) 12mm x 35mm Hex Bolt (2) 12mm Flat Washers (1) 12mm Lock Washer (1) 12mm Hex Nut Mounting Bracket Front Support Bracket (Fig 3) c. Insert the Mounting Bracket assembly up from behind the bumper. Reuse the (2) factory hex nuts to attach the Bracket assembly to the bumper bolts, tighteh the support bracket with (1) 12-1.5mm x 30mm Fine Thread Hex Bolt , (1) 12mm Lock Washer, (1) 12mm Flat Washer.
- Page 7 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) Loosen Remove the (2) remove factory hex bolt Factory hex nuts (Fig 6) Front Support Bracket (Fig 5)Driver side mounting location on model equipped with tow hooks b. Select the Upper Bracket & the Mounting Bracket, bolt the two brackets together with (1) 12mm x 35mm Hex Bolt, (2) 12mm Flat Washers, (1) 12mm Lock Washer and (1) 12mm Hex Nut Do not tighten at this time.(Fig 3).
- Page 8 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) (2) 8mm x 35mm Hex Bolts (2) 8mm Lock Washers (2) 8mm Flat Washers Front (Fig 6)Bull Bar Tube Bracket STEP 5: Repeat Step 4 to install the passenger side Tube Bracket. STEP 6: With help, position the Guard with Tube Brackets up to the inside of the Mounting Brackets.
- Page 9 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) STEP 7: Stand back from the vehicle and check to see that the Guard is centered and level on the vehicle and adjust as necessary. Fully tighten first the hardware securing the Mounting Brackets to the vehicle.
- Page 10 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) STEP 9: Reinstall the splash guard using the factory hardware. Use the included (2) 5mm x 15mm Allen Bolts, (4) 5mm Flat Washers and (2) 5mm Lock Nuts at the ends of the splash guard if required to replace rivets, (Fig 11).
- Page 11 MAX T BULL BAR FOR 2009-2018 Ram 1500 (Exclude Rebel models.)(BBMAX12T+MR13) STEP 10: Reinstall the Guard as described in Step 6, (Fig 12). STEP 11: Level and adjust the Guard and tighten all hardware. STEP 12: Complete Installation NOTE Any damages and losses caused by improper installation and application, goes beyond our quality warranty.
