- Page 1 BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET INSTALLATION INSTRUCTIONS BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET PART # RB-BA15B Page 1 of 7...
-
Page 2: Before Installation
BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET Before Installation Please read the instruction completely for easy installation, which will also help you to avoid scratches or other potential damages to your appealing car. The figures here are for reference only and may have differences with the actual product you received, however they share the same assembly way. - Page 3 BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET ○ ○ Connecting plate Decoration plate backboard ○ ○ Connect bracket 2-L Connect bracket 2-R ○ ○ Connect bracket Block ○ ○ Support bracket-R Support bracket-L ○ ○ Gum cover Rubber plug ○...
- Page 4 BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET ○ ○ Flat washer D10(10x30x2.5mm) Lock washer D10 ○ ○ Hex bolt M8_40 Button head allen bolt M8_30 ○ ○ Assembly bolt M8_25 Button head allen bolt M8_25 ○ ○...
-
Page 5: Installation Steps
BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET Installation Steps Step1: Assemble tubes with standard parts. Lock all the standard parts after adjust the position. Installation are same ○ ○ ○ Use standard parts at both sides. ○... - Page 6 BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET Step 2: Assemble Luggage frame and tubes with standard parts. Lock all the standard parts after adjust the position. ○ ○ ○ 35 to Use standard parts ○ ○ ○...
- Page 7 BLACK ATLAS ROLL BAR FOR 99-20 FORD F250/F350/F450 WITH CARGO BASKET Step 3: Put roll bar on the truck in an appropriate place. And use pen to mark the holes. 4places in each part, 8 ○ ○ places total. Remove the roll bar then drill the size of Φ12 holes. Put the roll bar back and use standard ○...
