- Page 1 3'' BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA TACOMA 05-15 INSTALLATION INSTRUCTIONS 3'' BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA TACOMA 05-15 PART # MBB-TOD1109 Page 1 of 4 1/23/15 Rev 3(DP)
- Page 2 3'' BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA TACOMA 05-15 PARTS LIST: 3” Bull Bar 10-1.50mm x 30mm Hex Bolts Driver/Left Frame Mounting Bracket 10mm x 30mm OD x 2.5mm Large Flat Washers Passenger/Right Frame Mounting Bracket 10mm x 20mm OD x 2mm Small Flat Washers Large Spacer Washers 10mm Lock Washers 10-1.50mm x 120mm x 30mm Hex Bolts...
- Page 3 3'' BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA TACOMA 05-15 For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild soap may be used also to clean the Bull Bar. For gloss black finishes: Mild soap may be used to clean the Bull Bar. Passenger Side Installation Pictured Remove (2) factory hex nuts on outside of frame...
- Page 4 3'' BLACK UNIVERSAL MAX BULL BAR FOR TOYOTA TACOMA 05-15 Passenger Side Installation Pictured 10mm x 120mm Hex Bolt 10mm x 20mm Small Flat Washer Spacer Washer 10mm x 30mm Large Flat Washer 10mm Lock Washer 10mm Hex Nut Front Front (Fig 4) Passenger side pictured from behind bumper 10mm x 120mm Hex Bolt...
