STEP BARS
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE
CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO
IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF
ANY CLAIM. IF MISSING PARTS OR ANY DAMAGE FOUND, PLEASE TAKE A
PICTURE FOR THE CLAIM PURPOSE. TO FILE YOUR CLAIM, PLAESE VISIT:
WWW.TYGERAUTO.COM/CONTACT
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
15-16
10mm
31-32
12mm
54-55
14mm
87-88
Front
®
TG-SS2F35228
Class 10.9 Torque (ft-lbs)
6-7
22-23
44-45
78-79
125-126
(4) Mounting Brackets
Driver/Left Tyger Rider
Customer Support: www.TygerAuto.com/Contact
Parts List
x1
x1
x4
x8
x12
x12
x12
6-7
1/3
Driver/Left Tyger Rider
Passenger/Right Tyger Rider
Mounting Brackets
8-1.25mm x 25mm Combo Bolts
8mm x 24mm OD x 2mm Flat Washers
8mm Nylon Lock Nuts
8mm Plastic Washers
V200914
Advertisement
Related Manuals for Tyger TG-SS2F35228
Summary of Contents for Tyger TG-SS2F35228
- Page 1 STEP BARS ® Parts List TG-SS2F35228 Driver/Left Tyger Rider BEFORE INSTALLATION Passenger/Right Tyger Rider READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO Mounting Brackets IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF ANY CLAIM.
