Whitmor 6779-4322 Manual

6779-4322 Closet Rod Closet System
A
2 ea
Shelf assembly
B
3 ea
Bottom vertical pole
C
3 ea
Middle vertical pole
D
3 ea
Top vertical pole with claw
STEP 1.
Start by sliding shelf locking
collar (F), then shelf assembly (A) onto
bottom two bottom vertical poles (B).
Repeat for second shelf assembly. Insert
two feet (E) into bottom of bottom vertical
poles (B).
A
F
A
F
B
E
E
3 ea
Foot
G
3 ea
Vertical pole
lock assembly
(These two parts
are pre-assembled)
STEP 2.
hanging rod lock
assemblies (H) and slide
onto one side of
assembled shelf section
from step 1. Slide the other
(H) onto remaining bottom
vertical pole (B). Insert
each end of hanging rod (I)
into (H) on both and
tighten. Insert and lock all
three middle vertical poles
F
(C) by sliding into (B) and
locking. Hanging rod can
now be repositioned higher
F
onto vertical pole (C) if
desired. Insert remaining
foot (E) onto bottom of (B).
Part
B
A
B
C
D
E
F
E
G
H
I
MADE IN CHINA
8680 Swinnea Road • Suite 103 • Southaven, MS • 38671
NEED HELP? For help with assembly, or if you are missing a part,
please call Whitmor's Customer Service Department, 1-888-944-8667
between 8 a.m. and 4:30 p.m. (Central Standard Time) Monday
through Friday. Or email: customer_service@whitmor.com. Visit us
online at www.whitmor.com
Rev#0 6.6.12
2012 Whitmor, Inc.
©
F I
4 ea
Shelf locking Hanging rod
collar
H
2 ea
Hanging rod
lock assembly
(These two parts
are pre-assembled)
Loosen two
Reference
F7495
Note:
F7496
Poles (B&C)
F7497
slide into
F7498
grove and
F7499
twist to lock.
F7500
F7501
F7502
F7503
Printed in China
1 ea
This product's intended use is for
hanging garments and storage.
Tools Needed: No tools required.
STEP 3.
Place three vertical pole
lock assemblies (G) onto top of
middle vertical poles (C). Insert top
vertical poles with claw (D) and
tighten (G).
Note:
Closet Rod System
D
can be installed on a
standard closet rod,
or on a wire shelf.
D
G
G
C
Note:
Parts (G)
C
and (H) come
pre-assembled.
B
H
B
Assembly
Time:
Less than
45 minutes.
Completed
D
G
C
I
H
B
E
