3875 Cypress Drive Petaluma, CA 94954 800.228.2555 707.773.1100 Fax 707.773.1180 www.gcx.com
The purpose of this guide is to:
1. Parts Reference Table (page 1)
2. Describe attachment of Dual Probe or Gel Cup Mount to Tablet Roll stand (page 2).
3. Describe attachment of Single Probe or Gel Cup Mount to Tablet Roll stand (page 3).
4. Describe re-attachment of the Track Cover to Tablet Roll stand (page 4)
5. Routine Maintenance (page 4)
The following parts and hardware are included in this installation kit (hardware not shown)
Item # Description
1
Single or Double Probe/Gel Cup Mount with Adapter
TOOLS:
•
Phillips Screwdriver (Not Provided)
Installation Guide
Probe/Gel Cup Mount to Tablet Roll Stand
DU-PRB-0001-9X Rev A 02/28/2025 GCX Corp Page 1
Qty
1
