GE CARESCAPE Monitor B650 on VHM-
PL Variable Height Arm Channel Mount
with Vertical Position Lock
PRODUCT DETAILS
VHM-PL (Locking) Variable Height Arm with 14" / 35.6 cm
Extension and Slide-In Mounting Plate
WS-0012-28
Load Range: 15 to 30 lb / 6.8 to 13.6 kg
RECOMMENDED ACCESSORIES
25" / 63.5 cm Channel
WC-0002-07
Seismic channel
Includes mounting hardware and instructions
OSHPD Pre-Approval: WC-0002-03, -05, -07, -09, -11, and -15.
Dual Cable Hooks with 3" / 7.6 cm Down Post for Cable
Management
WMM-0006-13
GCX is an ISO 13485 registered company (TUV-USA). GCX, PolyMount, and PolyQuip are registered trademarks, and VHRC,
VHC, VHM, VHRS, PRC, M Series, and Stor-Locx are trademarks, of GCX Corporation. All other brand names, product names, or
trademarks belong to their respective holders. © Copyright 2017.
Find this product at http://www.gcx.com/p/14502. Created on July 18, 2017
www.gcx.com
Advertisement
Table of Contents
Related Manuals for GCX VHM-P
Summary of Contents for GCX VHM-P
- Page 1 GCX is an ISO 13485 registered company (TUV-USA). GCX, PolyMount, and PolyQuip are registered trademarks, and VHRC, VHC, VHM, VHRS, PRC, M Series, and Stor-Locx are trademarks, of GCX Corporation. All other brand names, product names, or trademarks belong to their respective holders. © Copyright 2017.
- Page 2 GCX quality management processes are ISO 13485 certified. GCX, PolyMount, and PolyQuip are registered trademarks, and VHRC, VHC, VHM, VHRS, PRC, M Series, and Stor-Locx are trademarks, of GCX Corporation. All other brand names, product names, or trademarks belong to their respective holders. © Copyright 2017.
-
Page 3: Table Of Contents
Installation Time Approximately 10-15 minutes The purpose of this manual is to describe general installation, operation, and adjustment procedures for VHM-P and VHM-PL Series Arms. This manual should be used in conjunction with any instrument-specific installation guides. Please read this manual and all instrument-specific installation material before installing or using this product. -
Page 4: Parts Reference
1. 1/8” Hex Wrench 4. #2 Phillips Screwdriver 2. 5/32” Hex Wrench 5. Scissors, utility knife or similar cutting tool 3. 1/2” (13mm) / 3/4” (19mm) Wrench 6. Wire Cutters (for cable ties) DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 2 of 15... -
Page 5: Product Warning / Safety Labels
Maximum weight for mounting plate with tilt function. Counter Balance Load Range: 25 - 45 lbs / 11.3 - 20.4 kg 15 - 30 lbs / 6.8 - 13.6 kg DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 3 of 15... -
Page 6: Installation, Operation, And Maintenance Warnings
GCX technical support at 800.228.2555 or + 1 707.773.1100. VHM-P and PL Arms have a wide range of motion both up/down and side to side. Please consider potential pinch Points that may cause personal injury. -
Page 7: Installing The Arm In Channel
5.4 Using the 1/8'' hex wrench provided, tighten the (2) upper and the (2) lower set screws in Slide to secure position of Arm. Slide Set Screws (2 upper) Set Screws (2 lower) DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 5 of 15... -
Page 8: Mounting The Device
6.0 Mounting the Device Installation Note: Most devices will require the attachment of device-specific Mounting Adapter provided by GCX. Please attach this hardware in accordance with instructions provided with the Mounting Adapter. Pull Spring Plunger at the front of the Mounting Plate and slide device laterally into the Mounting Plate until the Plunger snaps into the clearance hole at the front of the Mounting Adapter. -
Page 9: Adjusting The Arm
Counterbalance is correctly adjusted when the mounted device can be moved up or down with minimal force and does not rise or fall after releasing the Arm. Counterbalance Adjustment Screw DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 7 of 15... - Page 10 1) Tighten (+) or loosen (-) the Pivot Tension Nut with a 3/4" (19 mm) socket wrench until desired tension is achieved. Caution: Do not remove the Pivot Tension Nut. DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 8 of 15...
-
Page 11: Cable Management
If replacement cable ties are required, standard and one (1) small cable. Use of the Cable Sleeves commercial cable ties can be used. is optional. Information on cable routing with and without Cable Sleeves follows. DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 9 of 15... - Page 12 Clip excess length of the cable tie as flush as possible to avoid creation of a sharp edge. Clip excess length of the cable tie as flush as possible to avoid creation of a sharp edge. 1/2” (13mm) DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 10 of 15...
- Page 13 1/2” (13mm) from the end of the Cable Sleeve. Clip excess length of the cable tie as flush as possible to avoid creation of a sharp edge. 1/2” (13mm) DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 11 of 15...
- Page 14 Rear Pivot Covers (Section 9). Cables from Left side are routed up the Right side of the Slide. Cables from the Right side are routed up the Left side of the Slide DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 12 of 15...
-
Page 15: Installing Pivot Covers
#2 Phillips screw driver - Do not overtighten the screw. Captive Screw Adjustable Stop Locating Tabs DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 13 of 15... -
Page 16: Channel Cover Installation
Dry the arm thoroughly after cleaning. CAUTION: GCX makes no claims regarding the efficacy of the listed chemicals or processes as a means for controlling infection. Consult your hospital’s infection control officer or epidemiologist. To clean or sterilize mounted instruments or accessory equipment, refer to the specific instructions delivered with those products. -
Page 17: Troubleshooting The Vhm-P And Vhm-Pl
Contact GCX does not operate correctly (arm will not lock or will not unlock): VHM-PL (locking) remains un-locked Handle Grip locked open for Remove hex key (section 7.1) Counter Balance adjustment DU-WS-0012-01 Rev B 5/24/16 GCX Corp. Page 15 of 15...
