- Page 1 S5810-28TS Switch Hardware Guide Copyright © 2025 FS.COM AII Rights Reserved Page 1 of 26...
-
Page 2: About This Guide
Management Platform — provides Day 0 to Day 2+ Automated Lifecycle Management 1.1.3 System Hardware and Software Features The S5810-28TS switch runs the PicOS® operating system and delivers Layer 2 and Layer 3 switching, routing, and security services. Table 1 lists the hardware and software features supported on the models. - Page 3 1.2 Chassis 1.2.1 Chassis Physical Specifications The S5810-28TS switch is a rigid sheet-metal structure that houses all components of the switch. Table 2 shows the physical specifications of the S5810-28TS switch models. Table 2. Physical Specifications of the S5810-28TS Switch Model Copyright ©...
- Page 4 1.2.2 Field-Replaceable Units Field-replaceable units (FRUs) are components that you can replace at your site. The FRUs in the S5810-28TS switch are hot-removable and hot-insertable: You can remove and replace them without powering off the switch or disrupting switch functions. The S5810-28TS switch has the following FRUs: •...
-
Page 5: Cooling System
S5810-28TS Models with Left-to-Right Airflow In the S5810-28TS switch models that have left-to-right airflow, the cold air intake to cool the chassis is through the vents on the front left of the switch, and hot air exhausts through the vents on the right panel (see Figure 5). -
Page 6: Power System
1.4.1 AC Power Supply in S5810-28TS Switch You can install up to two power supplies in the power supply slots in the rear panel of the S5810-28TS switch chassis. On the S5810-28TS switch, the slots are labeled PWR1 and PWR2. - Page 7 Power status LED Latch Latch of the power module 1.4.1.1 AC Power Supply Specifications Table 6 shows the power supply specifications for AC power supplies for the S5810-28TS switch. Table 6. Technical Specifications for AC Power Supplies Item Specification Dimensions (W x D x H) 156mm*50.5mm*38mm...
- Page 8 1.4.2 DC Power Supply in S5810-28TS Switch You can install up to two power supplies in the power supply slots in the rear panel of the S5810-28TS switch chassis. On the S5810-28TS switch, the slots are labeled PWR1 and PWR2.
- Page 9 Component Description Handle Handle of the power module Forward fan Power connector Terminal Block 2-pin Power status LED Latch Latch of the power module 1.4.2.1 DC Power Supply Specifications Copyright © 2025 FS.COM AII Rights Reserved Page 9 of 26...
-
Page 10: Site Planning, Preparation, And Specifications
S5810-28TS Switch Hardware Guide Table 10 shows the power supply specifications for DC power supplies for the S5810-28TS switch. Table 10. Technical Specifications for DC Power Supplies Item Specification Dimensions (W x D x H) 156mm*50.5mm*38mm Weight 0.385kg Power connector... - Page 11 Table 13. Gas Requirement Average Maximum (mg/m³) mg/m³ cm³/m³ mg/m³ cm³/m³ Sulfur Dioxide (SO ) 0.11 0.37 Hydrogen Sulfide (H S) 0.071 0.36 Chlorine (Cl) 0.034 Nitrogen Oxides (NO) 0.26 0.52 Copyright © 2025 FS.COM AII Rights Reserved Page 11 of 26...
- Page 12 There is one grounding studs in the lower left corner of the rear panel. It's pasted with a conspicuous label. 2.1.8 Preventing Electromagnetic Interference Electromagnetic interference mainly comes from outside the equipment or application system and affects the equipment through capacitive Copyright © 2025 FS.COM AII Rights Reserved Page 12 of 26...
-
Page 13: Initial Installation And Configuration
Initial Installation and Configuration 3.1 Unpack and Mount the S5810-28TS Switch Below is an optimized guide for unpacking and preparing the S5810-28TS switch for installation, including key precautions and potential risk alerts. 3.1.1 Parts Inventory (Packing List) for a S5810-28TS Switch Copyright ©... - Page 14 S5810-28TS Switch Hardware Guide The switch shipment includes a packing list. Check the parts you receive with the switch against the items in the packing list. Table 15. Inventory of Components Provided with a S5810-28TS Switch Models Component Quantity Power Cord...
- Page 15 1. Secure the mounting brackets and inner rails to the two sides of the switch with M4 screws. 2. Attach the switch to the rack using M6 screws and cage nuts. Copyright © 2025 FS.COM AII Rights Reserved Page 15 of 26...
- Page 16 2. Lay the chassis flat on the workbench and ensure adequate airflow around the chassis. 3.2 Connect the S5810-28TS to Power 3.2.1 Connect the S5810-28TS Switch to Earth Ground 3.2.1.1 Installation Guidelines A reliable grounding system is the basis for stable and reliable operation, which is indispensable for preventing lightning strikes and interference.
- Page 17 • The cross-sectional area of the protection ground wire should be at least 2.5mm² (12AWG). 3.2.2 Connect Power to S5810-28TS Switch 3.2.2.1 Installation Guidelines 1. To avoid electric shock, do not connect the power cable while the power is on.
- Page 18 DC power distribution box. Connect the positive and negative power cables to the positive and negative terminals in the DC power distribution box correctly. Copyright © 2025 FS.COM AII Rights Reserved Page 18 of 26...
- Page 19 Ensure that you have a rubber safety cap available to cover the transceiver. The transceivers for FS devices are hot-removable and hot-insertable field-replaceable units (FRUs). You can remove and replace the transceivers without powering off the device or disrupting the device's functions.
- Page 20 1. If the fiber-optic cable connector is covered with a rubber safety cap, remove the cap. Save the cap. 2. Remove the rubber safety cap from the optical transceiver. Save the cap. 3. Insert the cable connector into the optical transceiver. Copyright © 2025 FS.COM AII Rights Reserved Page 20 of 26...
- Page 21 Do not let fiber-optic cables hang free from the connector. Do not allow fastened loops of cables to dangle, which stresses the cables at the fastening point. 3.4 Connect the S5810-28TS to External Devices 3.4.1 Connect a Device to a Network for Out-of-Band Management Ensure that you have an Ethernet cable that has an RJ-45 connector at either end.
- Page 22 You can configure and manage your network devices through a dedicated management channel, using the console port available on each device. Connect the PC to the device's console port using a console cable, as shown in the image below. Copyright © 2025 FS.COM AII Rights Reserved Page 22 of 26...
-
Page 23: Post-Installation Checks
At least two personnel are required to power on the chassis. Do not service the chassis before it is powered off. • Carefully check your work area for possible hazards, such as ungrounded power extension cables, missing safety grounds, and moist floors. Copyright © 2025 FS.COM AII Rights Reserved Page 23 of 26... - Page 24 • Never assume that power is disconnected from a circuit. Instead, always check. 3.6 Configure PicOS® on the S5810-28TS 3.6.1 Connect and Configure S5810-28TS The initial configuration of the switch requires the user to connect the terminal or computer to the switch’s console port. Once the user accesses the switch and establishes the CLI (Command Line Interface) through a serial console connection, an IP address is assigned to the management port, and an IP route to the gateway is created.
- Page 25 Hwaddr: 00:18:23:30:e5:72 State: UP Gateway: 192.168.10.1 Inet addr: 192.168.10.5/24 Traffic statistics Input Packets......3620 Input Bytes......462971 Output Packets.....597 Output Bytes.......75459 Copyright © 2025 FS.COM AII Rights Reserved Page 25 of 26...
- Page 26 Email：sales@feisu.com Tel：+86(400)865 2852 FS has several offices around the world. Addresses, phone numbers are listed on the FS Website at https://www.fs.com/contact_us.html. FS and FS logo are trademarks or registered trademarks of FS in the U.S. and other countries. Copyright © 2025 FS.COM AII Rights Reserved...
