- Page 1 Installation Guide Atlas Bio Series Access Control Panels Ver 2.0 This installation guide is used for Atlas-160 Bundle, Atlas-260 Bundle and Atlas-460 Bundle. www.zktecousa.com...
-
Page 2: Table Of Contents
..........Hanwha Wave/DW Spectrum Integration Setup ZKey Mobile Credential App .......... Atlas Mobile App ..............Adding Your Panel to AtlasCloud ....... Special Considerations for Complex Networks ..Where to Go Next ..............Atlas Bio Series Access Control Panels Installation Guide... -
Page 3: What's In The Box
RLED BEEP BEEP COMM2 HOLD HOLD SHIELD SHIELD WLAN +12V +12V DOOR RETURN RETURN GLED GLED RLED RLED BEEP BEEP HOLD HOLD SHIELD SHIELD 4 Screws & Anchors 1 Screwdriver 4 Diodes Atlas Bio Series Access Control Panels Installation Guide... -
Page 4: Optional Accessories
Optional Accessories Wiegand Card Reader Prox Card Door Sensor Exit Button ZK9500 USB Fingerprint Scanner CR10E Card Enrollment Reader EP30CF FR1500A FP & Prox Reader AHEB-0808 Atlas x60 Metal Enclosure Atlas Bio Series Access Control Panels Installation Guide... -
Page 5: Safety Precautions
Do not use the device for any purpose other than those specified. Remove dust or dirt regularly. While cleaning, wipe dust off with a smooth cloth or towel instead of water. Contact your supplier in case of any problem! Atlas Bio Series Access Control Panels Installation Guide... -
Page 6: Product Pin Diagram
Press reset button for about 2-5 seconds, zk firmware will check if there is a USB disk which stores an upgrade package inserted into controller, if yes, then controller will do firmware upgrade automatically. Press reset button for about 5-10 seconds, zk firmware will temporarily set IP to default 169.254.202.242. Atlas Bio Series Access Control Panels Installation Guide... -
Page 7: Led Indicators
Flashing (DOOR) Green LED indicates RLED RETURN SHIELD a door opening signal (a door is opened). BEEP GLED DOOR HOLD RLED RETURN SHIELD BEEP GLED Figure 8 HOLD RLED SHIELD BEEP Atlas Bio Series Access Control Panels Installation Guide HOLD... -
Page 8: Product Dimension
1 for locks and 1 Number of Outputs 1 Form C relay for Form C relay for Form C relay for Aux output) Aux output) Aux output) Atlas Bio Series Access Control Panels Installation Guide... - Page 9 The surface of the metal enclosure is coated with high temperature baking paint, which can prevent rust. And the around holes are spot welded by a round metal plate. You have to frustrate them with tool when you want to put cable through. Atlas Bio Series Access Control Panels Installation Guide...
-
Page 10: Installation Of Panel & Enclosure
We recommend drilling the mounting plate screws into solid wood (i.e. stud/beam). If a stud/beam cannot be found, then use the supplied drywall plastic mollies (anchors). Wiring methods shall be in accordance with National Electrical Code, ANSI/NFPA 70. Do Not Connect to A Receptacle Controlled by a Switch. Atlas Bio Series Access Control Panels Installation Guide... -
Page 11: Wiring Legend
Wording “Compliance with IEEE 802.3 (at or af ) is not required” Reference to National Electrical Code, ANSI/NFPA 70 for Power over communications Atlas Bio Series Access Control Panels Installation Guide... -
Page 12: Power Wiring Diagram
1) This product comes with a 12V DC surge protected Class 2 power supply. 2) This product comes with a POC cable source. This equipment is in compliance with section 34.7 of UL 294, 7th Edition. ETHERNET Figure Atlas Bio Series Access Control Panels Installation Guide... -
Page 13: Wiegand Connection
Note: Color of wiring is subject to the specific Wiegand D0 reader. Wiegand D1 Green LED Beeper Wiegand Card Reader COMM 485A 485B AUX1 AUX2 BREAK AC FAIL BAT FAIL +12V Figure Atlas Bio Series Access Control Panels Installation Guide... -
Page 14: Osdp Connection
OSDP readers should be connected via the RS485 communication port. When scanning a card or inputting a PIN, the reader will send the card or PIN to the panel via OSDP communication. NOTE: OSDP and ZKTeco RS485 (FR1500A readers) cannot be supported simultaneously. OSDP Reader Note: Color of wiring is subject to the specific reader. -
Page 15: Aheb Series Connection
RETURN GLED GLED RLED RLED +12V BEEP BEEP HOLD HOLD SHIELD SHIELD COMM1 RETURN Output Input GLED RLED BEEP COMM2 HOLD SHIELD WLAN +12V AHEB-0808 AHEB-0808 AHEB-0808 Figure DOOR RETURN GLED Atlas Bio Series Access Control Panels Installation Guide RLED... -
Page 16: Ep30Cf Connection
GLED GLED RLED RLED +12V BEEP BEEP HOLD HOLD SHIELD SHIELD COMM1 RETURN GLED RLED BEEP COMM2 HOLD 12V DC 12V DC SHIELD WLAN +12V EP30CF EP30CF EP30CF EP30CF Figure DOOR Atlas Bio Series Access Control Panels Installation Guide RETURN... -
Page 17: Fr1500A Connection
GLED GLED RLED RLED +12V BEEP BEEP HOLD HOLD SHIELD SHIELD COMM1 RETURN GLED RLED BEEP COMM2 HOLD 12V DC 12V DC SHIELD WLAN +12V FR1500A FR1500A FR1500A FR1500A Figure DOOR Atlas Bio Series Access Control Panels Installation Guide RETURN... -
Page 18: Dip Switch Setting For Fr1500A Device Id
RS485 address or 600 ft , the number 6 switch should be 1 is for IN reader, RS485 address 2 is for OUT ON as below. reader). Distance: More than 200 meters Atlas Bio Series Access Control Panels Installation Guide... -
Page 19: Rex Connections
COMM1 RETURN RETURN GLED GLED RLED RLED BEEP BEEP COMM2 HOLD HOLD SHIELD SHIELD WLAN +12V +12V DOOR RETURN RETURN GLED GLED RLED RLED BEEP BEEP HOLD HOLD SHIELD SHIELD Figure 21 Atlas Bio Series Access Control Panels Installation Guide... -
Page 20: Lock Connection
HOLD HOLD SHIELD SHIELD +12V WLAN +12V DOOR RETURN RETURN GLED GLED RLED RLED BEEP BEEP HOLD HOLD SHIELD SHIELD ETHERNET ETHERNET Door Contact Sensor Sensor 12V DC FR107 Diode Figure 22 Atlas Bio Series Access Control Panels Installation Guide... -
Page 21: Aux. I/O Connection
Figure 23 AUX. Output Connection Normally, the AUX output is used to connect an external alarm which can be linked to a reader or Aux input events. ETHERNET ALARM 12V DC Figure 24 Atlas Bio Series Access Control Panels Installation Guide... -
Page 22: Ethernet Connection
As the Atlas x60 supports auto MDI/MDIX, it is not necessary to use a crossover type cable. COMM ETHERNET 485A 485B AUX1 AUX2 BREAK AC FAIL BAT FAIL +12V ZK9500 Figure 26 Atlas Bio Series Access Control Panels Installation Guide... -
Page 23: Troubleshooting
2 Years from original purchase date, replacement/repair of hardware under ZK standard warranty requires an evaluation of the failed system by a ZK Technical Support specialist, and the issuance of a Technical Support RMA number. Atlas Bio Series Access Control Panels Installation Guide... -
Page 24: Electrical Specifications
The input ports are pulled Pull- up resistance (Ω) 4.7k up with 4.7k resistors WIEGAND INPUT Voltage (V) 10.8 13.5 Current (mA) ZK ELECTRIC LOCK Voltage (V) DC 10.8 13.2 Current (mA) Atlas Bio Series Access Control Panels Installation Guide... -
Page 25: Specifications
Weight Atlas-160: 9lbs (3.8kg); Atlas-260/460: 10lbs (4.2kg) Enclosure Metal Cabinet Mounting Wall Mount Dimensions (Bundle Only) 14in. X 2.5in. X 12in. 380mm(L) X 80mm(W) X 280mm(H) 32 bit 1.2GHz 256MB Flash Certified Atlas Bio Series Access Control Panels Installation Guide... - Page 26 Hanwha Wave/DW Spectrum Integration Setup ........ ZKey Mobile Credential App ................Atlas Mobile App ......................Special Considerations for Complex Networks ........Adding Your Panel to AtlasCloud ..............Where to Go Next ....................... Atlas Bio Series Access Control Panels Installation Guide...
-
Page 27: Introduction
This guide refers you to online help topics for more detailed information. The help is available once you have connected the first controller and logged in to the Web Management Application. Open it by selecting “Help” from the menu in the upper right corner. Atlas Bio Series Access Control Panels Installation Guide... -
Page 28: Understanding The Atlas Series Network
For more complex networks, be sure to review the “Special Considerations” discussed at the end of this document before proceeding. Atlas Bio Series Access Control Panels Installation Guide... -
Page 29: Initial Controller Setup
Log in using the default administrator account: User name: admin • Password: admin • You will be directed to the Setup Wizard, where you will enter information required for the controller to operate. Atlas Bio Series Access Control Panels Installation Guide... - Page 30 Choose whether this controller will be a “Primary” or a “Secondary”. Make sure you understand the Atlas Series network, discussed above. The first controller installed should be a primary, and all others should be secondaries. Atlas Bio Series Access Control Panels Installation Guide...
- Page 31 This determines what your controller will be used for: controlling door entry, perhaps door exit, or as special purpose readers. Note: Secondary controllers are configured when they are connected to the system. Atlas Bio Series Access Control Panels Installation Guide...
- Page 32 + Card Enrollment Point - The second reader will be used to easily enter card numbers when adding users. Page 5: Time Zone (primaries only) Atlas Bio Series Access Control Panels Installation Guide...
- Page 33 Note: Secondary controllers get their time and time zone from the primary controller. Page 6: Password (primaries only) Enter a strong password for the primary administrator account. The user name for this account is “admin” and cannot be changed. Atlas Bio Series Access Control Panels Installation Guide...
- Page 34 To assign a static IP address, choose “Manually” and enter the IP address and configura- tion specified by the network administrator. “Using DHCP” is probably the right choice for secondary controllers, unless you have a complicated network discussed below under “Special Considerations for Complex Networks. ” Atlas Bio Series Access Control Panels Installation Guide...
-
Page 35: Connect The Controller To The Network
When you “Complete Setup, ” the controller will reboot itself automatically. If it is already installed, then simply reconnect it’s ethernet port to the local area network. Otherwise, disconnect the controller and complete the physical installation. Connect it to the local area network via ethernet. Atlas Bio Series Access Control Panels Installation Guide... -
Page 36: Complete The Configuration
Registration is required if you ever need to reset your system password, and optionally allows ZKTeco to contact you about software updates and other information. Follow these steps to register for the first time or to update your registration information. - Page 37 “Menu About” and clicking the button.) Register Find and open the registration confirmation file you saved. You should see a “Registration successful” message window. Atlas Bio Series Access Control Panels Installation Guide...
- Page 38 “Remove Secondary, Muster, or Card Enrollment Point” • Change the default connection type for readers (Wiegand, OSDP, or ZKTeco RS-485). These settings are on the sub-controller, and are detailed in the topic, “Hardware Properties”. The defaults vary by model and are listed in the topic, “Models and Configurations”.
- Page 39 Install a Fingerprint Enrollment Reader (optional) If you are using biometric readers, a ZKTeco USB fingerprint enrollment reader must be installed at any computer where fingerprints will be enrolled. Plug the device into any USB port.
-
Page 40: Add A User And Test Access
(To test biometrics) Scroll down to “Number of Enrolled Fingerprints, ” click “Enroll Fingerprints, ” and follow the on-screen instructions. You must have installed a USB fingerprint enrollment reader during “Complete the Configuration. ” Atlas Bio Series Access Control Panels Installation Guide... - Page 41 Save The card, PIN, and fingerprint you entered should now work to grant access at the specified doors, assuming you chose a compatible “Default Mode” during “Configure Doors. ” Atlas Bio Series Access Control Panels Installation Guide...
- Page 42 Card numbers can be more easily entered by using enrollment points. See the online help topic, “Features and Tasks: Card Enrollment Points. ” The number of digits for PINs can be changed in “Admin System Settings. ” Atlas Bio Series Access Control Panels Installation Guide...
-
Page 43: Adding Secondary Controllers
Enter a “Name, ” and select “Custom Door Names” so you can name the doors. c. Leave all other settings as they are. These are the settings that were discovered. d. Click on the menu bar. Save Atlas Bio Series Access Control Panels Installation Guide... -
Page 44: Adding The Aheb-0808 Expansion Board
To add the AHEB-0808 expansion boards: Log in to the Web Management Application (on the primary controller). Go to “Conf ig Hardware. ” Click on "Modify" to add a ZKTeco AHEB-0808. Atlas Bio Series Access Control Panels Installation Guide... - Page 45 Assign the OSDP address of the board and click "Add". After adding the board, you will then see it in the device tree and can configure the inputs and outputs as needed. Atlas Bio Series Access Control Panels Installation Guide...
-
Page 46: Adding An Ep30Cf Reader
Log in to the Web Management Application (on the primary controller). Go to “Config Hardware. ” Select the controller from the left-hand side menu and select "Readers" to open the parameter settings. Atlas Bio Series Access Control Panels Installation Guide... - Page 47 Home status of the reader after completing the setup. NOTE: For detailed operation of the ARMATURA CONNECT App, please refer to the relevant user manual Atlas Bio Series Access Control Panels Installation Guide...
-
Page 48: Hanwha Wave/Dw Spectrum Integration Setup
Wave & DW Spectrum system. Step 1: Navigate to Config and select Video Systems Login to your Atlas system. Go to "Config Video Systems" to choose the system you are using. Atlas Bio Series Access Control Panels Installation Guide... - Page 49 Username/Password: Login for your Wave/Spectrum Server. Note: If you are using Wisenet Wave or DW Spectrum version 5.0 & higher you will need to set your user settings to allow Digest Authentication. Atlas Bio Series Access Control Panels Installation Guide...
- Page 50 Step 3: Assigning a camera to a door After you have connected to the Wave/Spectrum system, you can click "Config Cameras". Click to select the door to assign the camera to. Atlas Bio Series Access Control Panels Installation Guide...
- Page 51 Click on the camera icon to view recorded video from the Wave VMS. Atlas Bio Series Access Control Panels Installation Guide...
-
Page 52: Zkey Mobile Credential App
ZKey Mobile Credential App ZKTeco provides its "ZKey" mobile app in Apple’s "App Store" and in "Google Play. " You must authorize each mobile device before it can access your system. Using the Atlas built in QR generator (ZKey) Create QR code in the Web Management Application: Go to "Access ... - Page 53 Have the user scan this QR code with their ZKey Mobile Credential app. • Or, click "Copy to clipboard" to share this registration code with the user, for manual entry into the ZKey Mobile Credential app. Atlas Bio Series Access Control Panels Installation Guide...
- Page 54 Click the ZKey App on your smartphone to open it. You can view your credential types here. Click the "+" button to add a credential. You can input the registration # or scan the QR from the user profile. Atlas Bio Series Access Control Panels Installation Guide...
- Page 55 You can now click on that credential and present it to the QR reader to gain access. Note: It's a 1-time use and will need to be generated to be used again. To use BT credential, click on it and then press the lock button. Atlas Bio Series Access Control Panels Installation Guide...
- Page 56 Each authorization code can authorize only one mobile device. You may delete and add authorizations as needed to support several devices. The number of devices you can authorize is limited by your license. Atlas Bio Series Access Control Panels Installation Guide...
-
Page 57: Atlas Mobile App
Click the Atlas App on your smartphone to open it. Input Server, Username, and Password in the login screen. Click on "Change QR Code" and scan the QR code you have registered. Press "Sign In" to log into the App. Atlas Bio Series Access Control Panels Installation Guide... - Page 58 Click "System Status" to view controllers, doors, activity & backup status. View Individual Door Status & Send Manual Commands Click "Door Status" to view individual door status. Select a door in the list and go to the information view screen. Atlas Bio Series Access Control Panels Installation Guide...
- Page 59 Atlas Mobile App Click the Manual Commands icon in the upper right corner of the interface. Set the command parameters, and click "OK" to save and exit. Atlas Bio Series Access Control Panels Installation Guide...
- Page 60 Atlas Mobile App Check Your Notifications (If Any) Click "Notifications" to chck your notifications. View & Monitor Any Events Click "Events" to view any events. Atlas Bio Series Access Control Panels Installation Guide...
- Page 61 Atlas Mobile App Activate & Deactivate an Emergency Lockdown Click "Lockdown" to activate an emergency lockdown. The interface prompts "SYSTEM UNDER LOCKDOWN!" when initiated successfully. Atlas Bio Series Access Control Panels Installation Guide...
- Page 62 Atlas Mobile App Click "Clear Lockdown" to deactivate the emergency lockdown. View & Manage Alarms Click "Alarms" to view and manage alarms. Atlas Bio Series Access Control Panels Installation Guide...
- Page 63 Click "Users" to enter the user list screen and click "+" to register a new user. Enter basic user information, add card number, QR Code, set access level, and add PIM or generate one. Atlas Bio Series Access Control Panels Installation Guide...
- Page 64 Edit User Click "Users" to enter the user list screen and select a user. Editing a user is done in the same way as adding a user. It will not be repeated. Atlas Bio Series Access Control Panels Installation Guide...
-
Page 65: Adding Your Panel To Atlascloud
It will then ask you to put in your credentials. These are the same credentials that you are using for your AtlasCloud portal login. This is how the panel knows where to link to. Atlas Bio Series Access Control Panels Installation Guide... - Page 66 - If you do not have an existing customer, you can input the name and it will create a new one in your portal. - If you already have that customer, you can add this panel to their account. Atlas Bio Series Access Control Panels Installation Guide...
- Page 67 Once done, it will show you a confirmation screen to ensure the information is correct. If so, you can then click “Complete Activation. ” After activating, it will show successful and reboot the controller. Atlas Bio Series Access Control Panels Installation Guide...
- Page 68 Adding Your Panel to AtlasCloud The controller's main page will show that AtlasCloud is online. And you will see now see it in your AtlasCloud Portal! Atlas Bio Series Access Control Panels Installation Guide...
-
Page 69: Special Considerations For Complex Networks
ETL Certification Resistance to attack Level I; Line security Level I; Endurance Level I; Standby Power Level I. Atlas Bio Series Access Control Panels Installation Guide... - Page 70 -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Atlas Bio Series Access Control Panels Installation Guide...
- Page 71 Atlas Bio Series Access Control Panels Installation Guide...
- Page 72 ZKTecoUSA - a division of ZKTeco 1600 Union Hill Road, Alpharetta, GA, 30005 USA Tel: (862)505-2101 www.zktecousa.com...
