- Page 1 Quick Start Guide KF1100 Pro and KF1200 Pro Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Product Overview
1.Product Overview 3.58"(91.0mm) 0.54" (13.8mm) 3.15"(80.0mm) 0.54" (13.8mm) ★ Note: Features and parameters with mark are not available in all devices. -
Page 3: Back Plate
Back Plate 3.25"(82.5mm) 3.03"(77.0mm) 0.51" (13.1mm) 0.51" (13.1mm) Description Description Flash Speaker Camera Tamper Switch Restart Button Near-Infrared Flash Reset Button LED Indicator Receive Antenna Mounting Hole Wiring Hole Card Reading Area 2.Installation Environment INSTALL INDOORS AVOID INSTALLATION AVOID DIRECT AVOID USE OF ANY HEAT SOURCE ONLY... -
Page 4: Device Installation
Fasten the device to the back plate with a security screw. Note: The installation method of KF1200 Pro is the same as that of KF1100 Pro. Only KF1100 Pro is used as an example, and will not be repeated here again. -
Page 5: Standalone Installation
AUX OUT AUX IN TCP/IP RS485 READER VOUT POWER RS485 DIP KF1200 Pro Door Sensor Door Sensor KF1200 Pro KF1100 Pro KF1200 Pro Face Template Mode A&C Standalone Mode Face Reader Mode 5.Terminal Block Power +12V +12V Alarm ALARM RS485... -
Page 6: Power Connection
6.Power Connection AC Adapter DC12V Minimum AC adapter :12V, 1.5A, Recommended AC adapter 12V 3A Use an AC adapter with a higher current rating to share power with the other devices. 7.Ethernet Connection Connect the device and the computer software over an Ethernet cable. As shown in the example below: Default IP address: 192.168.1.201 IP address... -
Page 7: Standalone Mode
8.Device Operating Mode The KF1000 Pro series has three device operating modes: Standalone Mode, Reader Background Identifying Mode and Face Server Mode. 1. Standalone Mode In the standalone mode, the KF1000 Pro series can be used as an standalone to connect with the DM10 as shown in the wiring diagram below. - Page 8 2. Reader Background IdentifyingMode In reader mode, the KF1000 Pro Series can communicate with the inBio Pro Plus controller via RS485. The wiring diagram is shown below. +12V +12V Separate Power Supply Recommended AC adapter :12V 3A ALARM Key Parameters: 485A Device Operating Mode: KF1000 Pro Series...
- Page 9 3. Face ServerMode In Face Server mode, the KF1000 Pro Series can be used as a converter to capture face templates from photos sent by the software, store them in the software, and then send the face templates to the controller through the software for verif ication and comparison. Refer to the following procedure to set up.
-
Page 10: Login To The Webserver
10.Login to the WebServer After the device is powered on, connect the device using a cable network to access the WebServer by entering the IP address and the server port in the address bar of your browser. The IP address is set as: https://device IP address: port. By default, the port is 1443. For example: https://192.168.1.201:1443 User name: admin Password: admin@123... -
Page 11: Quick Start
11.Quick Start UserRegistration User Authentication Verified ViewRecords 1. User registration Method 1: Registering on the WebServer Click [User Mgt. ] > [All Users] > [New User] to register a new user on the WebServer. Enter the User ID, Name, Password, Card, setting user role and access control role. Enter the User Info. - Page 12 Method 2: Registering on the software (ZKBio CVSecurity) 1. Click [Advanced Settings] > [COMM.] > [IP Address] to set the IP address and then click [Cloud Service Setup] to set cloud service address on the WebServer. As shown in the figure below. 192.168.163.58 192.168.163.1 Enter the IP Info.
-
Page 13: User Authentication
2. Click [Access] > [Access Device] > [Device] > [Search] to search the device on the software. When an appropriate server address and port is set on the device, the searched devices are then displayed automatically. 3. Click [Add] in an operation column, a new window will pop-up. Select Icon Type and Area from each dropdowns and click [OK] to add the device. -
Page 14: View Records
3. View records Click [Access] > [Access Control Reports] > [All Transactions] on the software to view the records. 12.Wi-Fi Settings Click [Advanced Settings] > [Wi-Fi Settings] to enable the Wi-Fi function, select a Wi-Fi and enter the password. Until the connection status shows “Connected“ which indicates that the Wi-Fi connection is successful. - Page 15 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved.
