Horus E2 Series

Thank you for choosing our product. Please read the instructions carefully

before operation. Follow these instructions to ensure that the product is

functioning properly. The images shown in this manual are for illustrative

purposes only.

P a g e

| 1

For further details, please visit our Company's website

www.zkteco.com.

User Manual

Table of Contents

Need help?

Do you have a question about the Horus E2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco Horus E2 Series

Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.zkteco.com. P a g e Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 2 ZKTeco supplied equipment vests in and is the property of ZKTeco. The contents hereof should not be used or shared by the receiver with any third party without express written permission of ZKTeco.
Page 3 Horus E2 Series User Manual ZKTeco in no event shall be liable to the user or any third party for any incidental, consequential, indirect, special, or exemplary damages, including, without limitation, loss of business, loss of profits, business interruption, loss of business information or any pecuniary loss, arising out of, in connection with, or relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been advised of the possibility of such damages.
Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks.
Page 5 The general information which helps in performing the operations faster. The information which is significant. Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 6: Table Of Contents
5.4 ANTI-PASSBACK SETUP ..........................43 ACCESS CONTROL RECORDS ......................45 DATA MANAGEMENT ........................46 ALARM MANAGEMENT ........................48 8.1 ADD ALARM ..............................48 8.2 DELETE ALARM ............................49 SYSTEM SETTINGS ..........................50 P a g e Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 7 CONNECT TO ZKBIO CVACCESS SOFTWARE ..................75 10.1SET THE COMMUNICATION ADDRESS ....................75 10.2ADD DEVICE ON THE SOFTWARE ......................76 10.3ADD PERSONNEL ON THE SOFTWARE ....................77 PRIVACY POLICY ............................78 ECO-FRIENDLY OPERATION ........................80 P a g e Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 8: Overview
User Manual Overview The Horus E2 from ZKTeco is an Android-based multi-biometrics terminal designed to streamline both time attendance and access control. Leveraging ZKTeco's cutting-edge technology, the Horus E2 supports a variety of authentication methods, including facial recognition, fingerprint scanning, multi-tech card verification, and QR code scanning.
Page 9 Horus E2 Series User Manual Recommended Facial Expressions Recommended Standing Postures Note: During enrolment and verification, please remain natural facial expression and standing posture. P a g e Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 10: Finger Placement
During enrollment, try to adjust your face in the center of the device screen. Please face the camera and stay still. The device screen is shown below: P a g e | 10 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 11: Standby Interface
If a super administrator has already been registered for this device, you will need the permission of the super administrator to enter the main menu. P a g e | 11 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 12: Virtual Keyboard
1:1 Verification Process 1:1 biometric verification process authenticates a person’s identity by comparing the captured biometric template with a biometric template of that person pre-stored in the database. P a g e | 12 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 14: Facial Verification
This method identifies the acquired facial image of the user with all the facial templates that are stored in the device.  Below are the sample for successful and unsuccessful identification. P a g e | 14 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 16: Fingerprint Verification
 To enter fingerprint identification mode, simply tap your finger on the fingerprint reader.  Below are the sample for successful and unsuccessful identification. P a g e | 16 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 17 If a user has registered a face, a password and card in addition to his/her fingerprint and the verification method is set to fingerprint/ password/ card/ face, the following screen will appear.  Select the fingerprint button to enter fingerprint verification mode. P a g e | 17 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 18: Card Verification
 To enter 1: N card identification mode, please place the registered card on the card reader.  Below are the sample for successful and unsuccessful identification. P a g e | 18 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 19 Tap on the card button to enter card verification mode. After that, swipe the card to verify.  Below are the sample for successful and unsuccessful identification. P a g e | 19 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 21: Main Menu
To ensure the security of the device, we recommend registering an administrator the first time you use this device. For detailed operating instructions, please see section User. P a g e | 21 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 22: User Management
There are two methods to add users: Add user via Software or Add via Device. 4.1.1 Add Users via Device  Tap on button on the [User Management] interface to enter the User creation interface. P a g e | 22 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 23 It is recommended to face the lens and then adjust the position.  On the User Photo interface, tap on the camera button to capture a photo. P a g e | 23 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 24 But a Super Administrator will have more privileges like access to the main menu and will also have the same access as the Normal user. P a g e | 24 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 25 Note: When a user is given super administrator privileges, entering the main menu will require verification. The verification process depends on the verification method that was used during user registration. See the description in section “Verification Mode”. Register Verification Modes P a g e | 25 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 26 Tap on the required button ( left or right) situated on the left and right side of the screen and then tap on the required finger to register. P a g e | 26 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 27 If the fingerprint is successfully registered, "Continue to enroll the next Fingerprint?’’ dialog box will appear.  Tap Yes to record the next fingerprint, or No to return to the fingerprint registration interface. P a g e | 27 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 28 On the Enter the password field enter the password, then on the Confirm password field re-enter the same password.  Tap Confirm. Note: The user password must be 6-8 digit number. P a g e | 28 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 29 The password which has been registered can be deleted or modified. Delete/Overwrite Registered Password  On the User management interface, tap on the required username from the user list to delete or modify the password. P a g e | 29 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 30 On the New User interface, tap Face to enter the face registration page.  On the Face Register interface, move and adjust your face on the registration area. P a g e | 30 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 31 23:59; once this validity period expires, the employee's verification for attendance will be invalid.  On the ‘’User Information’’ interface, tap [User Validity Rule] to set the validity period. P a g e | 31 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 32 This includes the access group, fingerprint privilege and also facilitates to set the group access time-period.  On the New User interface, tap User Access Control Role to set the access level. P a g e | 32 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 33  The device supports up to 99 access control groups. Set the Time period  Tap Time Period to set the time of access for the user. P a g e | 33 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 35: Search User
Tap on the Search bar to search for the users with the relevant user ID/name and the system will automatically find the users with information that is relevant to the search query. P a g e | 35 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 36: Edit User
On the “User Management” interface, select the required user to delete and tap on the button to delete. Delete  On the pop-up window, tap OK to confirm the deletion. P a g e | 36 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 38: Access Settings
If the alarm is enabled and the status of the door status sensor is not restored Door Sensor Delay within the specified time, the alarm is triggered. Valid value: 1~500 seconds. P a g e | 38 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 39: Time Rules Settings
On the Access Control interface, need to connect software, issue Time Rules.  The entire system can define up to 50 Time Rules (the default Time is Rule1, Time Rule1 cannot be modified). P a g e | 39 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 40 End Time is later than the Start Time, (such as 08:00~23:59).  The default Time Zone 1 indicates that door is open all day long and it cannot be edited. P a g e | 40 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 41: Holiday Settings
[Next].  On this interface, tap either Finish to successfully add the newly created holiday, or tap Continue to create another holiday. P a g e | 41 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 42 On the “Holiday period” interface, tap on the required holiday to modify. Delete a Holiday  On the “Holiday period” interface, tap on the button to delete the holiday. P a g e | 42 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 43: Anti-Passback Setup
Anti-passback Out: After a user checks out, only if the last record is a check-in record, the user can check-out again; otherwise, the alarm will be triggered. However, the user can check-in freely. P a g e | 43 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 44 This access direction depends on the selection of the control direction of the device, corresponding to the state of the device.  The interface is shown below: P a g e | 44 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 45: Access Control Records
User Manual Access Control Records  User access records will be saved in the device, making it easier to find the required attendance records of the users. P a g e | 45 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 46: Data Management
Deletes the access photos within a specified time range. Deletes all (including access records and the photos of the user in blocklist) Delete Unregistered User Photos Deletes the unregistered user photo within specified time range. P a g e | 46 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 47 Deletes all the user photos. Delete User Photos Delete Wallpapers Deletes all the wallpapers stored in the device. Delete User Photo Delete all users' template photos. Templates P a g e | 47 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 48: Alarm Management
On the Main menu, tap Alarm Management to configure the alarm settings. 8.1Add Alarm  On the Alarm interface, tap on the button to set the alarm, and then tap “Save” to save and update. P a g e | 48 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 50: System Settings
On the Main menu, tap [System Settings] to configure the device settings. 9.1Network Settings  On the System Settings interface, tap [Network Settings] to configure the settings P a g e | 50 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 51: Ethernet Settings
0.0.0.0; when the device is connected to the network, the parameters such as IP address and subnet mask are automatically displayed as set values. P a g e | 51 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 52: Wi-Fi Settings
You can access the network through Mobile data. When the device is not connected to the network, tap [Mobile Data] on the “Network Settings” interface. The following screen will display: 9.2Date and Time 9.2.1 Date and Time Settings P a g e | 52 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 53 Tap [Set Date] and swipe up and down to set the year, month, and day.  After setting required Date, tap [OK].  Tap [Set Time] and swipe up and down to set the hour and minute. P a g e | 53 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 54: Time Zone Settings
After setting time, tap [OK]. 9.2.2 Time Zone Settings  Tap [Select time zone] and swipe up and select a time zone.  After the selection is complete, tap [OK]. P a g e | 54 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 55: Date And Time Format Settings
On Date and Time interface, tap [Date format].  On Date Format interface, select a required date format.  On Date and Time interface, tap [24-Hour Time Format] option to enable this function. P a g e | 55 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 56: Access Control Record Settings
24-Hour Time Format 24 hours 9.3Access Control Record Settings  On the System Settings interface, tap on [Access Control Record Settings] to enter the access record settings interface. P a g e | 56 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 57: Camera Mode
If this mode is selected, the device takes a photo when the user fails Save after failed verification verification and save it. P a g e | 57 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 58: Verification Settings
1 to 9 seconds. Screen This is the facial template matching time interval that users, can set as 0 Facial Recognition interval to 9 seconds. P a g e | 58 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 59: Validity Period Of User Information
9.4Cloud Service Settings On System Settings interface, tap [Cloud Service Settings] to enter the Cloud Service Settings interface. P a g e | 59 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 60: Wiegand Settings
The address is changed from HTTP to HTTPS. 9.5Wiegand Settings On System Settings interface, tap [Wiegand Settings] to access the interface as shown below. P a g e | 60 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 62 “C “denotes the card number; “E” denotes the even parity bit; “O” denotes the odd parity bit; “F“ denotes the facility code; “M” denotes the manufacturer code; “P” denotes the parity bit; and “S” denotes the site code. P a g e | 62 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 63: Wiegand Out
Pulse Width(us) time. Pulse Interval(us) The time interval between pulses. ID Type Select the ID type as User ID or Card number. P a g e | 63 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 64: Display Settings
Delay Parameter options include: 1 minute, 2 minutes, 5 minutes, 10 minutes. Choose your favourite wallpaper from the theme Customization of Wallpaper Wallpaper and Theme wallpaper interface. P a g e | 64 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 66: Sound Settings
Voice Volume are enabled. It can be set from 0-15. 9.9Biometric Parameters  On the System Settings interface, tap [Biometric Parameters] to enter the Biometric parameters interface. P a g e | 66 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 67 If it does not, the verification fails. The higher the threshold, the more accurate the matching; the lower the threshold, the higher the matching success rate. P a g e | 67 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 68 On the contrary, if the threshold is too low, the accuracy of face Threshold recognition will be lower, which may lead to misjudgement and other phenomena. The default value is 76. P a g e | 68 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 69: Auto-Testing
When setting the threshold, it is recommended to open auxiliary line correction function. 9.10Auto-testing  On the System Settings interface, tap on [Auto-Testing] to enter the auto testing interface. P a g e | 69 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 70 Test Wiegand in and Wiegand out to check if it works. RS485 Used to test whether the RS485 read head can transmit data normally. Relay Used to test open/close locker and open/close alarm is normal. P a g e | 70 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 71: Advanced Settings
It can use the software to deliver the firmware upgrade file for online Enable upgrade through ZKClouds upgrade. Note: If you need an upgrade file, please contact out technical staff. Firmware upgrade is not recommended under normal circumstances. P a g e | 71 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 72: About The Device
It displays all the versions of all the system's apps, such as the Version system settings, data management, and other installed apps. P a g e | 72 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 73: Security Setting
After this function is enabled, the user's name will not be Verity masked personnel name displayed during attendance verification. Enable ADB network Start ADB network debugging. debug Access Privacy Agreement. Privacy Policy P a g e | 73 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 75: Connect To Zkbio Cvaccess Software
To set the server address and server port. Server address: Set the IP address as of ZKBio CVAccess server. Server port: Set the server port as of ZKBio CVAccess. P a g e | 75 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 76: Add Device On The Software
Click [Add] in operation column, a new window will pop-up. Select Icon type, Area, and Add to Level from each dropdown and click [OK] to add the device. P a g e | 76 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 77: Add Personnel On The Software
Fill in all the required fields and click [OK] to register a new user. Click [Access] > [Device] > [Control] > [Synchronize All Data to Devices] to synchronize all the data to the device including the new users. P a g e | 77 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 78: Privacy Policy
Privacy Policy Notice: To help you better use the products and services of ZKTeco and its affiliates, hereinafter referred as "we", "our", or "us", the smart service provider, we consistently collect your personal information. Since we understand the importance of your personal information, we took your privacy sincerely and we have formulated this privacy policy to protect your personal information.
Page 80: Eco-Friendly Operation
The components which contain toxins or harmful elements are included due to the current economic or technical limitations which prevent their replacement with non-toxic materials or elements. P a g e | 80 Copyright©2024 ZKTECO CO., LTD. All rights reserved.
Page 81 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved.
