  • Page 1 Quick Start Guide AC02-C1XH-U10 Series Version: 1.0...
  • Page 2 1. Cautions Please note the following cautions. Mis-operation may lead to any injury or equipment failure: 1. Do not energize the system before installation is complete; never carry out installation activities when the system is energized. 2. All peripheral devices must be grounded. 3.

  • Page 3: Product Dimension

    2. Product Dimension AC02-C11H-U10 AC02-C12H-U10 AC02-C14H-U10 6.89" (175.0mm) 6.89" (175.0mm) 8.50" (216.0mm) Mainboard Bracket Mounting Holes for AC02-C11H-U10 /AC02-C12H-U10 Mounting Holes for AC02-C14H-U10 Bracket Mounting Holes 4.17" (106.0mm) 0.24" (6mm)
  • Page 4 Metal Enclosure Cable Conduit (Punch Hole for cables) LED Status Indicator Advanced Access Control POWER Heat Lock Dissipation Grill 2.76" (70.0mm) Bracket/Controller Mounting Position Metal Enclosure Mounting Holes Power Supply Mounting Position 10.82" (275.0mm) Backup Battery Mounting Position 13.62" (346.0mm)
  • Page 5 3. Installation of Metal Enclosure on the wall 1. According to the mounting holes position of the metal enclosure. Drill three mounting holes in a suitable spot on the wall and make sure it is about 114 inches (2.9m) above the ground, which can be adjusted according to actual needs.
  • Page 6 4. LED indicators, Wires, Auxiliary Input and Output 1) Understanding the LED indicators: RUN indicator (green): Flashing indicates the system works normally. CARD indicator (yellow): Flashing indicates card is punched on reader. LINK indicator (green): Always (green) indicates TCP/IP communication is proper. 2) Recommended use of wires: ACT indicator (yellow): Flashing indicates data is in trans- Use 2-conducotor power cord...
  • Page 7 AC02-C12H-U10 AC02-C14H-U10 SD Card Slot SD Card Slot Function: Backup Access Control Logs Function: Backup Access Control Logs Auxiliary Ethernet Ethernet Input Auxiliary interface (1-2) Input (1-4) Extended RS485 DIP Switches Dip switch Status indicator PC RS485 PC RS485 EXT RS485 interface (Customization) Door button 1...
  • Page 8 5. Controller System Installation Emergency Exit Switch Client Side TCP/IP OSDP Alarm IP Camera Door Sensor Door Sensor Wiegand OSDP 485- 485+ Touch EXIT QR500 Exit Button ProID 103 ProID 102 DC12V DC12V DC12V #1 EX0808 #2 EX0808 #8 EX0808 I/O Expansion Board Dynamic QR code...

  • Page 9: Power Connection

    6. Power Connection Without Backup Battery POWER BT+ BT- Ground Switching Power Supply With Backup Battery POWER BT+ BT- Ground Backup Battery Switching Power Supply...

  • Page 10: Ethernet Connection

    7. Ethernet Connection Establish the connection between the device and the software using an Ethernet cable. An illustrative example is provided below: Default IP address: 192.168.1.201 Subnet mask: 255.255.255.0 IP address: 192.168.1.130 Subnet mask: 255.255.255.0 TCP/IP TCP/IP TCP/IP Note: In LAN, IP addresses of the server (PC) and the device must be in the same network segment when connecting to the software.

  • Page 11: Auxiliary Input Connection

    9. Auxiliary Input Connection TCP/IP +12V DC 12V DC TCP/IP Fire Alarm 10. Auxiliary Output Connection AUXOUT TCP/IP +12V DC TCP/IP Alarm...

  • Page 12: Exit Button Connection

    11. Exit Button Connection BUTTON1 TCP/IP Button Exit Button TCP/IP 12. RS485 Connection Baud Rate: ZK485: 9600 OSDP: 115200 485+ 485- TCP/IP +12V DC +12V DC TCP/IP #8 KR614-OSDP #3 KR614-OSDP #2 QR500 #1 QR500...
  • Page 13 Controller Supported Reader Models: Reader Model 485 Unencrypted 485 Encryption OSDP Unencrypted OSDP Encryption ProID100 Series QR50/QR500/QR600 Remarks: means connectable, means not connectable. 2. In 485 communication encryption mode, the ProID100 reader supports tamper alarm function. When the reader is illegal tampering, it will send a tamper signal to the controller via 485, and the controller will report to the software to form a tamper alarm event.
  • Page 14 13. Connecting EX0808 through PC485 OSDP TCP/IP 485- 485+ TCP/IP +12V DC +12V DC +12V DC #1 EX0808 #2 EX0808 #8 EX0808 Important Notes: 1. Conf igure the ZK485 protocol through the PC485 port to connect up to eight EX0808 expansion boards to expand a certain number of auxiliary inputs and auxiliary outputs.
  • Page 15 DIP Switch Setting for RS485/OSDP Communication RS485 RS485 RS485 Description DIP Switch DIP Switch DIP Switch Address Address Address 1 2 4 8 MODE (RS485/OSDP) RS485 Terminal Resistance Important Notes: There are six DIP switches on the EX0808 expansion board and their functions are: 1.

  • Page 16: Lock Relay Connection

    14. Lock Relay Connection Controller not sharing power with the lock(Dry Connect) LOCK1 Sensor Sensor Door Sensor TCP/IP +12V DC Lock Power +12V DC 12V DC FR107 TCP/IP Normally Closed Lock Do not reverse the polarity. Switching dry and wet modes Important Notes: Dry Mode supports separate power supply for the lock using an external independent power supply.
  • Page 17 Controller sharing power with the lock(Wet Connect) Normally Opened Lock Powered From Lock Terminal: LOCK LOCK1 +12V DC 12V DC TCP/IP +12V DC 12V DC FR107 TCP/IP Do not reverse the polarity. Normally Opened Lock Normally Closed Lock Powered From Lock Terminal: LOCK LOCK1 +12V DC...

  • Page 18: Dip Switch Setting

    15. DIP Switch Setting 1 2 3 4 5 6 7 8 1 2 4 8 16 32 Restore Factory Setting RS485 Terminal Resistance 1. Number 1-6 are reserved to set the device number for RS485 communication. The code is binary, and the numbering starts from left to right.

  • Page 19: Restore Factory Setting

    16. Restore Factory Setting 1 2 3 4 5 6 7 8 Restore Factory Setting 1. If you forget the IP address of the AC02-C1XH-U10 series panel or the device does not work normally, you can use the number 7 DIP switch to restore it to factory default settings. The parameters which gets reset are device IP address, communication password, gateway, and subnet mask.

  • Page 20: Troubleshooting

    In the software conf igure reader 1-Indoor, and reader 2-Outdoor. 2. Can we integrate IP Camera and NVR? Currently ZKBiosecurity software supports ZKTeco’ s IP Cameras and NVR. You can associate a camera to the door and setup a linkage for the same.
