  • Page 1 User Manual of Energy Storage System(ESS) SMILE-G3-S5 (LCD) System...

  • Page 3: Disclaimer

    DISCLAIMER DISCLAIMER Copyright © AlphaESS Co., Ltd. 2022. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of AlphaESS Co., Ltd. The material furnished in this document is believed to be accurate and reliable. The information and recommendations in this document do not constitute commitments or warranties in the form of assignments.

  • Page 4: Copyright Statement

    COPYRIGHT STATEMENT COPYRIGHT STATEMENT This manual is under the copyright of Alpha ESS Co., Ltd. with all rights reserved. Please keep the manual properly and operate in strict accordance with all safety and operating instructions in this manual. Please do not operate the product before reading through...

  • Page 5: Table Of Contents

    CONTENT CONTENT DISCLAIMER ......................1 COPYRIGHT STATEMENT ................... 2 CONTENT ......................3 1. INTRODUCTION ....................5 1.1. Content and Structure of this Document ..........5 1.2. Target Group ....................5 1.3. Levels of Warning Messages ..............6 1.4. Definition of Abbreviations and Nouns ..........7 2.
  • Page 6 CONTENT 4.1.2. Battery Storage ......................... 27 5. Register APP and AlphaCloud ..............29 5.1. Register on APP ..................29 5.1.1. Download and Install APP ....................29 5.2. Regiter on AlphaCloud ................29 5.2.1. Register as Installer Account ....................29 6. Operation ......................32 6.1.

  • Page 7: Introduction

    1. INTRODUCTION 1.1. Content and Structure of this Document This document is valid for product of SMILE-G3-S5 (LCD)； This document describes the operation, troubleshooting and decommissioning of the product as well as the operation of the product user interface.

  • Page 8: Levels Of Warning Messages

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 1.3. Levels of Warning Messages The following levels of warning messages may occur when handling the product DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 9: Definition Of Abbreviations And Nouns

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 1.4. Definition of Abbreviations and Nouns alternating current application auxiliary battery battery management system direct current energy management system inverter photovoltaic...

  • Page 10: Safety

    The product is suitable for indoor and outdoor installation. The product (SMILE-G3-S5(LCD)) must only be operated with PV arrays of protection class II in accordance with IEC 61730, application class A. The PV modules must be compatible with this product.

  • Page 11: Safety Instructions

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 2.2. Safety Instructions 2.2.1. General Safety Precautions • Overvoltage or wrong wiring can damage the battery pack and cause deflagration, which can be extremely dangerous. •...
  • Page 12 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 2. If the battery pack is not on fire yet, extinguish the fire before the battery pack catches fire. 3. If the battery pack is on fire, do not try to extinguish but evacuate people immediately.

  • Page 13: Symbols Explanation

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 2.3. Symbols explanation Symbols on the type label of the inverter: Symbol Explanation Beware of a danger zone This symbol indicates that the product must be additionally grounded if additional grounding or equipotential bonding is required at the installation site.
  • Page 14 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Symbols on the type label and warning label of the battery pack. Symbol Explanation Beware of a danger zone This symbol indicates that the inverter must be additionally grounded if additional grounding or equipotential bonding is required at the installation site.

  • Page 15: Product Introduction And Application Scenarios

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3. Product Introduction and Application Scenarios 3.1. Nomenclature introduction SMILE-G3-S5 Location Name Explain SMILE Residential system Generation 3 5 kW Single-phase hybrid inverter 3.2.

  • Page 16: Battery Introduction

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. LCD Display Object Name Description Red: The inverter is in fault. Green: The battery is in charging or discharging. Indicator Green: The inverter is in normal state. Green: The system has connected to the server.
  • Page 17 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. In the Main interface, press ENT key to enter the menu’s main interface. Use the Up and Down key to select a sub-menu, press the ENT key to enter the selected sub-menu, press Return key to return to the previous layer.
  • Page 18 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Communication interface displays the real-time communication state of BMS, Net, MeterGrid and MeterDC. 3.2.1.3 Display Content of Sub-Menu History Item History menu contains seven sub- menus: Grid Consumption, INV Gen., BAT Gen., PV Gen., Grid Charge, PV Charge, Error Logs.
  • Page 19 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. PV Charge interface displays total battery energy charging from the PV- panels. Error Logs interface displays the 10 latest fault records of this system, including the name and time of the error.
  • Page 20 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 4 Step 5 Set on-grid capacity, storage capacity Click the Battery Function and check and number of PV strings (MPPT num- battery type.
  • Page 21 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 12 Step 13 Set the OVP10min Trip value .Change the Grid Set the OVP Trip Time value .Change the arguments. Grid arguments. Step 15 Step 14 Set the OVP10min Trip time value .Change...
  • Page 22 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 22 Step 23 Set the OFP restore value .Change the Grid ar- Set the UFP restore value .Change the Grid guments. arguments.
  • Page 23 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 32 Step 33 Set whether the GFCI detection is enabled, Set whether the N-Line detection is ena- “YES”is enable, ”NO” is disenable. bled,“YES”is enable, ”NO”...
  • Page 24 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. South Africa, RD1699 for Spain. Step 41 Step 42 If you use CT meter, please set CT me- If you use UPS function, please set ter to Enable and the relevant ratio.
  • Page 25 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Make sure all the following num- ber is correct. Display Content of Additional Function Setting If you use Backup box, please set as below: Step 1 Step 2 Click Enable to set to Yes.
  • Page 26 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.2.2. Battery Introduction During normal operation of battery, three LED indicators on the front cover provide information about the SOC of the battery with white lights on and off or flashing (0.5S on, 1.5S off).

  • Page 27: Application Scenarios

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.3. Application Scenarios 3.3.1. DC-coupled Storage System 3.3.2. AC-coupled Storage System...
  • Page 28 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.3.3. Hybrid-coupled Storage System...

  • Page 29: Storage

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 4. Storage 4.1. Storage 4.1.1. Inverter Storage The following requirements should be met if the inverter is not put into use directly: 1.
  • Page 30 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Keep batteries away from direct sunlight. Keep batteries at least 2 m away from heat sources. 7. The batteries in storage must be disconnected from external devices. The indicators (if any) on the batteries should be off.

  • Page 31: Register App And Alphacloud

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 5. Register APP and AlphaCloud 5.1. Register on APP 5.1.1. Download and Install APP 1. Android device users can download the App through major Android application markets such as Google Play.
  • Page 32 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. If not, please register by filling in the following web form； In this form, all fields with a red star are compulsory, and you can select the finally users or installation procedures.
  • Page 33 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. More details are available in the Online Monitoring Web Sever Installers User Manual, which can be downloaded from AlphaESS homepage. Please scan the QR code below to get the User Manual of the APP and Cloud. AlphaESS APP User Maunal AlphaESS Cloud User Maunal...

  • Page 34: Operation

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 6. Operation 6.1. Checking Before Power-On No. Check Item Acceptance Criteria The mounting space is proper, and the mounting Mounting environment environment is clean and tidy, without foreign object. Battery pack and The battery pack and inverter are mounted correctly, inverter mounting...
  • Page 35 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 6. Switch on the AC breaker between the backup port of the energy storage inverter and the loads (this AC Breaker should be labelled Main Switch Battery ESS Backup or similar).

  • Page 36: Powering Off The Product

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 6.3. Powering off the Product 1. Switch off the AC breaker between the energy storage inverter and the backed- up loads (this AC breaker should be labelled Main Switch Battery ESS Backup or similar).

  • Page 37: Routine Maintenance

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 7. Routine Maintenance Normally, the energy storage system need no maintenance or calibration. Disconnect the product from all power sources before cleaning. Clean the housing, cover and display with a soft cloth.

  • Page 38: Uninstallation & Return

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 8. Uninstallation & Return 8.1. Removing the Product Procedure Step 1: Power off the product by following instructions in Chapter 6.3 Powering •...

  • Page 39: Specification

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 9. Specification 9.1. Datasheet of Inverter...

  • Page 40: Datasheet Of Battery

    Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 9.2. Datasheet of Battery...
  • Page 41 Error! Use the Home tab to apply 标题 1 to the text that you want to appear here.
