COPYRIGHT STATEMENT COPYRIGHT STATEMENT This manual is under the copyright of Alpha ESS Co., Ltd. with all rights reserved. Please keep the manual properly and operate in strict accordance with all safety and operating instructions in this manual. Please do not operate the product before reading through...
1. INTRODUCTION 1.1. Content and Structure of this Document This document is valid for product of SMILE5; This document describes the operation, troubleshooting and decommissioning of the product as well as the operation of the product user interface.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 1.3. Levels of Warning Messages The following levels of warning messages may occur when handling the product DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 1.4. Definition of Abbreviations and Nouns alternating current application auxiliary battery battery management system direct current energy management system inverter photovoltaic...
The product is suitable for indoor and outdoor installation. The product (SMILE5) must only be operated with PV arrays of protection class II in accordance with IEC 61730, application class A. The PV modules must be compatible with this product.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 2.2. Safety Instructions 2.2.1. General Safety Precautions • Overvoltage or wrong wiring can damage the battery pack and cause deflagration, which can be extremely dangerous. •...
Page 12
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 2. If the battery pack is not on fire yet, extinguish the fire before the battery pack catches fire. 3. If the battery pack is on fire, do not try to extinguish but evacuate people immediately.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 2.3. Symbols explanation Symbols on the type label of the inverter: Symbol Explanation Beware of a danger zone This symbol indicates that the product must be additionally grounded if additional grounding or equipotential bonding is required at the installation site.
Page 14
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Symbols on the type label and warning label of the battery pack. Symbol Explanation Beware of a danger zone This symbol indicates that the inverter must be additionally grounded if additional grounding or equipotential bonding is required at the installation site.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3. Product Introduction and Application Scenarios 3.1. Nomenclature introduction SMILE5 Location Name Explain SMILE Residential system 5 kW Single-phase hybrid inverter...
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.2. Product Description 3.2.1. Inverter Introduction Item Description Item Description Battery Switch PV-Switch PV-Switch Breaker BAT+ Battery Connectors PV1, PV2 PV connector BAT- Grid Backup Backup Switch...
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.2.2. Inverter Display Interface Introduction Object Name Description Red: The inverter is in fault. Green: The battery is in charging or discharging. Indicator Green: The inverter is in normal state.
Page 18
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.2.2.2 Display Content of Sub-Menu Status Item Status menu contains five sub-menus: Solar, Battery, Grid, UPS and Comm. These display the relevant information about the current operation or communication interface respectively.
Page 19
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.2.2.3 Display Content of Sub-Menu History Item History menu contains seven sub- menus: Grid Consumption, INV Gen., BAT Gen., PV Gen., Grid Charge, PV Charge, Error Logs.
Page 20
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Error Logs interface displays the 10 latest fault records of this system, including the name and time of the error. 3.2.2.4 Display Content of General Setting Item Step 1: Click Setting and enter the password.
Page 21
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 8: Grid menu contains seven sub- Step 9: Set the Max. Feed in rate menus: FeedIN Control, Voltage Limit, value. Frequency Limit, Protect Thold, Protect Enable, Power Limit,Power Factor Click the Grid Function to set relevant pa-...
Page 22
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 18: Step 19: Set the UFP Trip value .Change the Set the UFP Trip Time Grid arguments. value .Change the Grid arguments. Step 21: Set the UFP Trip Time Step 20:...
Page 23
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. range. Step 30: Set whether the over frequency de- Step 31: Set whether the under fre- tection is enabled, ”YES” is enable, ”NO” is quency detection is enabled, “YES”...
Page 24
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 40: Click Safety in the setting menu. Set safety standard to AS4777 for Australia, ARN4105 for Germany, CEI0_21 for Italy, NRS097_2_1 for South Africa, RD1699 for Spain.
Page 25
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Step 45: Click Language to set lan- Step 46: Make sure all the follow- guage. ing number is correct. Display Content of Additional Function Setting If you use Backup box, please set as below: Step 2: Set the priority of the load, L1...
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.2.3. Battery Introduction...
Page 27
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. The LED indicators provide information about the SOC operational status of the battery pack. LED Ring Description SOC<5% 5%=<SOC<25% Standby: 25%=<SOC<50% Green light flickering 1s Work: 50%=<SOC<75% Green light flickering 10s...
Page 28
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Connection area overview of SMILE5-BAT Position Designation Battery+ Power Connector Battery- Power Connector Grounding BMS COM Ports Battery Power Button Battery Breaker Battery LED Display Connection area overview of SMILE-BAT-10.1P, SMILE-BAT-10.3P, SMILE-BAT-13.3P.
Page 29
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Position Designation Grounding Battery Breaker Battery+ Power Connector Battery- Power Connector BMS COM Ports Battery Power Button Battery LED Display...
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 3.3. Application Scenarios 3.3.1. DC-coupled Storage System 3.3.2. AC-coupled Storage System...
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 4. Storage 4.1. Storage 4.1.1. Inverter Storage The following requirements should be met if the inverter is not put into use directly: 1.
Page 33
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. Keep batteries away from direct sunlight. Keep batteries at least 2 m away from heat sources. 7. The batteries in storage must be disconnected from external devices. The indicators (if any) on the batteries should be off.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 5. Register APP and AlphaCloud 5.1. Register on APP 5.1.1. Download and Install APP 1. Android device users can download the App through major Android application markets such as Google Play.
Page 35
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. If not, please register by filling in the following web form; In this form, all fields with a red star are compulsory, and you can select the finally users or installation procedures.
Page 36
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. More details are available in the Online Monitoring Web Sever Installers User Manual, which can be downloaded from AlphaESS homepage. Please scan the QR code below to get the User Manual of the APP and Cloud. AlphaESS APP User Maunal AlphaESS Cloud User Maunal...
(press the button on the next battery within 5s). 4. Switch on the AC breaker between the grid port of the SMILE5-INV and the grid. 5. Switch on the AC breaker between the backup port of the SMILE5-INV and the loads.
2. Switch off the PV switch at the bottom of the SMILE5-INV. 3. Switch off the PV switch between the PV string and the SMILE5-INV if there is any. 4. Long press the power button of the battery for 6 seconds, then switch off the battery breaker of the battery.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 7. Routine Maintenance Normally, the energy storage system need no maintenance or calibration. Disconnect the product from all power sources before cleaning. Clean the housing, cover and display with a soft cloth.
Error! Use the Home tab to apply 标题 1 to the text that you want to appear here. 8. Uninstallation & Return 8.1. Removing the Product Procedure Step 1: Power off the product by following instructions in Chapter 6.3 Powering •...
