Dealer / Installer:
Provide a copy of these instructions to the end user of this product. These instructions
provide important operating and safety information for proper usage of this product.
Demonstrate the proper use of the product with the end user. Have the end user
demonstrate that they understand the proper use of the product.
End User:
Read and follow all instructions included in this manual. Ask your Dealer / Installer for
assistance if you do not understand the proper use of the product. Never remove any
WARNING
decals from the product. Failure to follow these instructions can result in injury or death.
APPLICATION
: 2005-2023 NISSAN FRONTIER CREW CAB
Qty
2
A4 Sidebars
3
Driver/Left Mounting Brackets
3
Passenger/Right Mounting Brackets
12
8mm x 20mm T-Bolts
24
8mm x 24mm OD x 2mm Flat Washers
Size
08 MM
(3) Passenger/Right
Mounting Brackets
Visit
www.trailfx.com
Assembly, Installation, Operation and
Maintenance Instructions
A4 ALUMINUM STEP BAR
Part Description
TORQUE SPECIFICATION
Torque
20.0 ft/lbs
(6) Plastic
Covers
or Call (866) 638-4870 for Warranty Information / Tech Support / Product Updates.
Keystone Automotive Operations Inc. All Rights Reserved. 12/02/2022-R01
PARTS LIST
Qty
12
8mm Lock Washers
12
8mm Hex Nuts
12
8mm Flanged Nuts
6
Plastic Covers
12
Plastic Clips
Size
(3) Driver/Left
Mounting Brackets
A4 Sidebar
Part Number:
AL4021B
60 - 180 minutes
Part Description
Torque
Front
Page-1-4
Advertisement
Related Manuals for TrailFX A4
Summary of Contents for TrailFX A4
- Page 1 Part Number: Assembly, Installation, Operation and AL4021B Maintenance Instructions A4 ALUMINUM STEP BAR 60 - 180 minutes Dealer / Installer: Provide a copy of these instructions to the end user of this product. These instructions provide important operating and safety information for proper usage of this product.
- Page 2 Passenger/Right center and rear locations, (Figure 4). 5. Select the Passenger/Right A4 Sidebar. Insert (6) T-Bolts into the channels in the bottom of the Sidebar, (3) per channel, (Figure 5). Attach the Sidebar to the Mounting Brackets with (6) 8mm Flat Washers, (6) 8mm Lock Washers and (6) 8mm Hex Nuts, (Figure 6).
- Page 3 Ensure the Year / Make / Model as well as cab and bed dimensions are correct for the application. Review all steps for installation to ensure they were followed correctly. Who should be contacted for questions regarding product / installation assistance? www.trailfx.com / support@trailfx.com or 1-(866) 638-4870 Visit www.trailfx.com...
- Page 4 If any products are found to have a manufacturing or material defect, the product will be replaced or repaired at the option of TrailFX and Keystone Automotive Operations Inc. with proof of purchase by the original purchaser. The original purchaser shall pay all transportation and shipping costs associated with the return of the defective product and the defective product shall become the property of Keystone Automotive Operations Inc.
