TrailFX A7065S Assembly Instructions Manual

Fits:2001-2013 Chevrolet Silverado 1500 , 1500HD Crew Cab (Excl. C/K "Classic")
2002-2013 GMC Sierra 1500 , 1500HD Crew Cab
2001-2014 Chevrolet Silverado / GMC Sierra 2500 (LD), 2500HD/3500 CREW CAB (Excl. C/K "Classic")
ASSISTANCE IS RECOMMENDED.
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT.
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
DO NOT OVER TORQUE. STANDARD OPERATING LOAD FOR TIGHTEN
BODY MOUNT NUTS & BOLTS VARIES FROM 45 TO 65 FOOT POUND.
Qty
1 Driver/Left Side Bar
1 Passenger/Right Side Bar
1 Driver/Left Front Mounting Bracket
1 Passenger/Right Front Mounting Bracket
1 Driver/Left Side Center Mounting Bracket
1 Passenger/Right Side Center Mounting Bracket
1 Driver/Left Rear Mounting Bracket
1 Passenger/Right Rear Mounting Bracket
1 Driver/Left Front Support Bracket
1 Passenger/Right Front Support Bracket
2 Center Support Brackets
2 12-1.75mm x 30mm Hex Bolts
IMPORTANT ALERT: GM uses a very strong thread-locking compound on all body bolts. Use of an air
assisted impact ratchet can cause damage to the threads on factory body mount bolts and the internal nut
assembly because of this thread locking compound.
We only recommend the use of hand tools to slowly remove and reinstall body mount bolts on all GM
vehicles.
PROCEDURE:
CRITICAL INFORMATION: If during the removal process, it becomes increasingly difficult to unscrew the
body mount bolt with hand tools, tighten the bolt several rotations to clear the thread locking compound
from the threads, then reverse direction and continue to unscrew until the body mount bolt is out. Repeat
this process as necessary on all GM body mount bolts. Use of an appropriate anti-seize compound is highly
recommended for re-installation. Tighten body mount bolt to factory torque specifications for your particular
model year.
Page 1 of 7
5" Oval Bent End Nerf Bar
Part No. A7065S/B
Part Description
PARTS LIST:
Qty
4 12mm x 32mm x 3mm Flat Washers
2 12mm Lock Washers
2 12mm Hex Nuts
2 10mm Nut Plates
6 10-1.50mm x 30mm Hex Bolts
10 10mm x 20mm OD x 2mm Flat Washers
6 10mm Lock Washers
4 10mm Hex Nuts
12 8-1.25mm x 25mm Hex Bolts
12 8mm ID x 24mm OD x 2mm Flat Washers
12 8mm Lock Washers
Cutting Not
60-180 min
Required
support@trailfx.com
1 866 638 4870
POLISHED STAINLESS STEEL – LIMITED LIFETIME
POWDER COATED BLACK – 3 YEARS
Part Description
www.TrailFX.com
Drilling Not
Required
Rev 012319
