Uplus Lighting 600 BSWF User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User manual
600 BSWF
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 600 BSWF and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting 600 BSWF

Summary of Contents for Uplus Lighting 600 BSWF

  • Page 1 User manual 600 BSWF Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-7 DMX Channels ……………………………………………………………………………………8-15 LUX Date …………………………………………………………………………………………16-17 Dimension …………………………………………………………………………………………18 Trouble Shooting…………………………………………………………………………………19 Fixture Cleaning………………………………………………………… ………………………19 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.

  • Page 4: Technical Specifications

    2.Technical Specifications Input Voltage: 100-240V, 50/60Hz Output Voltage: V1:48V 12.5A(light source), V2:24V8A(a main board) Power consumption: 600 W Power supply: 800W Light source: 600W Module LED Engine Lifetime:≥20,000Hours Color temperature: 8500K Linear CTO color temperature adjustment (2700K-7000K) Standard color rendering index Ra ≥ 70 High color rendering index Ra ≥...

  • Page 5: Control Menu

    3.Control Menu Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Menu Menu Menu Menu Menu Menu DMX address 1 - 512 mode1(34) Channel mode DMX set up mode2(25) mode3(29) Horizontal reversal Vertical reverse Horizontal/vertical close feedback open Straight line Dimming curve...
  • Page 6 ZOOM module Full test In the test... level vertical cyan Rose red yellow Color temperature Color Rotation Gobo Gobo Rotation Fixed Gobo iris prism Rotation of prism Equipment frost 1 detection Effect test frost 2 zoom focus strobe dimmer Cut rotation Cut down 1 Cut down 2 Cut on1...
  • Page 7 Color -128 -> 127 Rotation -128 -> 127 gobo gobo rotation -128 -> 127 Fixed gobo -128 -> 127 iris -128 -> 127 prism -128 -> 127 Rotation of -128 -> 127 prism frost 1 -128 -> 127 frost 2 -128 ->...

  • Page 8: Dmx Channels

    4.DMX Channels 34 Channels (Mode1 Function Value Effect Pan Fine Pan Fine Tilt Tilt Tilt Fine Tilt Fine P/T Speed Fast to slow 0-100% 0-100% 0-100% 0-100% white light color1 color2 color3 color4 color5 color6 Half color1 Half color2 Color Half color3 Half color4 Half color5...
  • Page 9 Gobo4shake Gobo5shake Gobo6shake Gobo7shake white light Rotate forward, going from fast to slow Reverse rotation, slow to fast 0 - 360° Rotate forward, going from fast to slow Gobo Rotation stop Reverse rotation, speed from fast to slow white light Gobo1 Gobo2 Gobo3...
  • Page 10 CRI open No function frost1 Frost cut No function Frost2 frost cut zoom The Angle goes from large to small focus 0-100% No function (open light) Common stroboscope 1Hz to 20Hz No function (open light) strobe Pulse stroboscope 1Hz-20Hz No function (open light) Random ordinary stroboscopic No function (open light) dimmer...
  • Page 11 No function No function No function 25 Channels (Mode2) Function Value Effect Pan Fine Pan Fine Tilt Tilt Tilt Fine Tilt Fine P/T Speed Fast to slow 0-100% 0-100% 0-100% 0-100% white light color1 color2 color3 color4 color5 color6 Half color1 Half color2 Color Half color3...
  • Page 12 Gobo2shake Gobo3shake Gobo4shake Gobo5shake Gobo6shake Gobo7shake white light Rotate forward, going from fast to slow Reverse rotation, slow to fast 0 - 360° Rotate forward, going from fast to slow Gobo Rotation stop Reverse rotation, speed from fast to slow white light Gobo1 Gobo2...
  • Page 13 360°shake CRI close CRI open No function frost1 Frost cut No function Frost2 frost cut zoom The Angle goes from large to small focus 0-100% No function (open light) Common stroboscope 1Hz to 20Hz No function (open light) strobe Pulse stroboscope 1Hz-20Hz No function (open light) Random ordinary stroboscopic No function (open light)
  • Page 14 29 Channels (Mode3) Function Value Effect Pan Fine Pan Fine Tilt Tilt Tilt Fine Tilt Fine P/T Speed Fast to slow 0-100% 0-100% 0-100% 0-100% white light color1 color2 color3 color4 color5 color6 Half color1 Half color2 Color Half color3 Half color4 Half color5 Half color6...
  • Page 15 Common stroboscope 1Hz to 20Hz No function (open light) Pulse stroboscope 1Hz-20Hz No function (open light) Random ordinary stroboscopic No function (open light) dimmer Dimming 0% to 100% Dimmer fine Dimming fine 0 to 100% Cut rotation 0-90° Cut down 1 0-100% Cut down 2 0-100%...

  • Page 16: Lux Date

    4.LUX Date...

  • Page 18: Dimension

    5.Dimension...

  • Page 19: Trouble Shooting

    6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
