Uplus Lighting 1000 BSWF User Manual

Hide thumbs

Advertisement

Table of Contents

User manual
1000 BSWF
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000 BSWF and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting 1000 BSWF

Summary of Contents for Uplus Lighting 1000 BSWF

  • Page 1 User manual 1000 BSWF Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 Technical Specifications………………………………………………………………………4 Control Menu ……………………………………………………………………………………5 DMX Channels …………………………………………………………………………………6-17 ……………………………………………………………………………………17 Trouble Shooting…………………………………………………………………………………18 Fixture Cleaning………………………………………………………… ………………………18 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...

  • Page 4: Technical Specifications

    2.Technical Specifications SOURCE ● Light Source: 1000W White LED ● Light Color Temperature:6800K ● Average LED Life: 20,000 Hour POWER ● Input Voltage: 100-240VAC, 50/60Hz ● Power Consumption: 1050W OPTICAL SYSTEM ● Zoom: 5° - 50° linear motorized ● Prism: 4-facet circular & 6 facet linear rotating prisms, independent control ●...

  • Page 5: Control Menu

    3.Control Menu The control board on the fixture base is your interface to access and control all functions on the unit. It’s Touch Screen LCD display gives you a code view of the options and functions. The following will explain each function and its options :...

  • Page 6: Dmx Channels

    4.DMX Channels 35Channel 35 CHANNEL FUNCTION DMX VALUE DESCRIPTION 0-255 0-540degree PAN FINE 0-255 0-2degree TILT 0-255 0-270degree TILT FINE 0-255 0-1degree P/T SPEED 0-255 Fast to slow 0-255 Cyan 0-100% 0-255 Magenta 0-100% 0-255 Yellow 0-100% 0-255 0-100% Open 8-15 Color Read 16-23...
  • Page 7 228-229 Stop 230-255 Backward slow to fast 0-127 0-360degree GOBO ROTATION 128-191 Forward fast to slow 192-255 Backward slow to fast Open 5-12 Gobo1 13-20 Gobo2 21-28 Gobo3 29-36 Gobo4 37-44 Gobo5 45-52 Gobo6 53-60 Gobo7 STATIC GOBO 61-76 Gobo8 77-89 Gobo1 Shake slow to fast...
  • Page 8 FROST 2 0-255 0-100% ZOOM 0-255 5-50degree FOCUS 0-255 0-100% Close 8-15 Open 16-131 Fade strobe Slow to fast 132-139 Open Random strobe slow to 140-181 fast STROBE 182-189 Open 190-231 Slow to fast 232-239 Open 240-247 Slow to fast 248-255 Open DIMMER...
  • Page 9 230-251 No function FUNCTION&RESET 252-255 Fan run fast mode 29 Channel 29 CHANNEL FUNCTION DMX VALUE DESCRIPTION 0-255 0-540degree PAN FINE 0-255 0-2degree TILT 0-255 0-270degree TILT FINE 0-255 0-1degree P/T SPEED 0-255 Fast to slow 0-255 Cyan 0-100% 0-255 Magenta 0-100% 0-255 Yellow 0-100%...
  • Page 10 200-201 Open 202-229 Forward fast to slow 230-255 Backward slow to fast 0-255 FROST 1 0-255 0-100% FROST 2 0-255 0-100% ZOOM 0-255 5-50degree FOCUS 0-255 Close 8-15 Open 16-131 Fade strobe Slow to fast 132-139 Open Random strobe slow to 140-181 fast STROBE...
  • Page 11 180-189 Dimmer Fast 190-199 Dimmer Smooth 200-209 All reset 210-219 Head motors reset FUNCTION&RESET 220-229 P/T reset 230-251 No function 252-255 Fan run fast mode 26Channel 26 CHANNEL FUNCTION DMX VALUE DESCRIPTION 0-255 0-540degree PAN FINE 0-255 0-2degree TILT 0-255 0-270degree TILT FINE 0-255...
  • Page 12 93-109 Gobo2 shake slow to fast 110-126 Gobo3 shake slow to fast 127-143 Gobo4 shake slow to fast 144-160 Gobo5 shake slow to fast 161-177 Gobo6 shake slow to fast 178-201 Gobo7 shake slow to fast 202-227 Forward fast to slow 228-229 Stop 230-255...
  • Page 13 000-127 Prism Rotating 128-190 Forward Fast to Slow PRISM ROTATION 191-192 Stop 193-255 Backward Slow to Fast 0-30 Open 31-255 CRI filter FROST 1 0-255 0-100% FROST 2 0-255 0-100% ZOOM 0-255 5-50degree FOCUS 0-255 0-100% Close 8-15 Open 16-131 Fade strobe Slow to fast 132-139...
  • Page 14 20Channel 20 CHANNEL FUNCTION DMX VALUE DESCRIPTION 0-255 0-540degree PAN FINE 0-255 0-2degree TILT 0-255 0-270degree TILT FINE 0-255 0-1degree P/T SPEED 0-255 Fast to slow 0-255 Cyan 0-100% 0-255 Magenta 0-100% 0-255 Yellow 0-100% 0-255 0-100% Open 8-15 Color 1 16-23 Color 2 24-31...
  • Page 15 DIMMER 0-255 0-100% DIMMER FINE 0-255 0-29 No function 30-39 Dimmer curve 1 40-49 Dimmer curve 2 50-59 Dimmer curve 3 60-69 Dimmer curve 4 70-79 Normal working mode 80-89 Silent working mode 90-99 No function 100-109 LED frequency setting ON 110-119 LED frequency setting OFF 120-179...
  • Page 16 Rotating Gobos Animation Disk Framing System Frost&Prisms...
  • Page 17 LUX Data 5.Dimension (mm)

  • Page 18: Trouble Shooting

    6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
