Summary of Contents for Uplus Lighting 600 BSWF
- Page 1 User manual 600 BSWF Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………6-10 Dimension …………………………………………………………………………………………11 Trouble Shooting…………………………………………………………………………………12 Fixture Cleaning………………………………………………………… ………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Input Voltage: 100v-240v 50-60Hz Power supply: 800W Light source: 600W LED Color temperature: 6500k Spot angle: 4-50 degree RDM function: DMX address code,channel mode and other functions can be changed from the console Control mode: DMX512, automatic operation, master-slave mode Channel mode: 35CH Pan: 540 °... -
Page 5: Control Menu
3.Control Menu Main Menu Second Third Fourth Dmx Address 000 - 512 Dmx Mode 35CH Run Mode DMX / Auto Pan Invert Close / Open Tilt Invert Close / Open Fixture XY Coder Close / Open Dimmer Curve Line/S-Cur/Squar/Cur4 Dimmer Speed Smooth/Fast Fan Mode Auto/Quiet... -
Page 6: Dmx Channels
All Reset Cancel / Run Fixture Reset Factory Cancel / Run Language CH / EN Display Display Flip Normal / Reverse Display Mode 60s / Show 4.DMX Channels 35 Channels Channel DMX Value Function 0－255 Pan 8bit 0－255 Pan 16bit 0－255 Tilt 8bit 0－255... - Page 7 Linear White 8-15 Color1 16-23 Color2 24-31 Color3 32-39 Color4 40-47 Color5 48-55 Color6 56-63 Color7 64-127 Color Linear 128-189 FAST ROTATION - SLOW ROTATION 190-193 STOP 194-255 SLOW ROTATION - FAST ROTATION 0－255 Fixed Gobo white 10-19 Gobo 1 20-29 Gobo 2 30-39...
- Page 8 0－255 Rotation Gobo white 10-19 Gobo 1 20-29 Gobo 2 30-39 Gobo 3 40-49 Gobo 4 50-59 Gobo 5 60-69 Gobo 6 70-79 Gobo 7 80-94 Gobo 1 Jitter 95-109 Gobo 2 Jitter 110-124 Gobo 3 Jitter 125-139 Gobo 4 Jitter 140-154 Gobo 5 Jitter 155-169...
- Page 9 128-190 FAST ROTATION - SLOW ROTATION 191-192 STOP 193-255 SLOW ROTATION - FAST ROTATION 0－255 Frost 0-127 white 128-255 Frost 0－255 Focus 0-255 Focus，Linear 0－255 Focus Fine 0-255 Focus Fine，Linear 0－255 Zoom 0-255 Zoom，Linear 0－255 Zoom Fine 0-255 Zoom Fine，Linear 0－255 Blade1-1 0-255...
- Page 10 30-39 Dimmer Curve：Square 40-49 Dimmer Curve：Inverse Square 50-59 Dimmer Curve：S-Curve 60-69 Dimmer Curve：Linear 70-79 Fan Mode：Auto 80-89 Fan Mode：Quiet 90-179 Reserved 180-189 Dimmer Speed:Fast 190-199 Dimmer Speed:Smooth 200-209 All Reset 210-219 Effect Reset 220-229 Pan&Tilt Reset 230-255 Reserved Gobo effects :...
-
Page 11: Dimension
5.Dimension... -
Page 12: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
