- Page 1 User manual 6 EYE RETRO BAR Please read the instructions carefully before use...
- Page 2 TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………4 DMX Channels ……………………………………………………………………………………5-6 Trouble Shooting……………………………………………………………………………………7 Fixture Cleaning………………………………………………………… …………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
- Page 3 1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.
- Page 4 2.Technical Specifications SPECIFICATIONS: Light Source: 6*60W & 144*0.2w 3in1 led Input Voltage:AC90-260V 50/60Hz Power Consumption: 420W Control mode:DMX512,Auto-run , Master-Slave Control Channel: 8/28 channels Powercon:powercon in & out DMX sockets:3-pin XLR sockets Display: Digital Display Strobe：1-25t/s multiple stroboscopic effect Dimming：0-100% linear dimmer 3.Control Menu Menu Operation On the base of the control panel offers a number of features, such as setting DMX fixture address,...
- Page 5 4.DMX Channels 8 DMX channels CH 8 DMX Value Function Function Illustration 0－255 Total Dimmer Total Dimmer 0－3 No function Strobe 4－255 Slow to fast 0-255 R Dimmer dark to light 0-255 Green G Dimmer dark to light 0-255 Blue B Dimmer dark to light 0-255 White...
- Page 6 0-255 Blue4 B4 Dimmer dark to light 0-255 White4 W4 Dimmer dark to light 0-255 Red5 R5 Dimmer dark to light 0-255 Green5 G5 Dimmer dark to light 0-255 Blue5 B5 Dimmer dark to light 0-255 White5 W5 Dimmer dark to light 0-255 Red6 R6 Dimmer dark to light...
- Page 7 5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
