Summary of Contents for Uplus Lighting IR 1210 PAR
- Page 1 User manual IR 1210 PAR Please read the instructions carefully before use...
- Page 2 TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………5 DMX Channels ……………………………………………………………………………………6 Dimension …………………………………………………………………………………………6 Trouble Shooting…………………………………………………………………………………7 Fixture Cleaning………………………………………………………… ………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
- Page 3 1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...
- Page 4 •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
- Page 5 3.Control Menu [MENU] menu selection or return to previous menu. [UP] press [UP] through the menu list to increase/change the value of the current function. [DOWN] press [DOWN] through the menu list to decrease/change the value of the current function. [ENTER] confirm &...
- Page 6 4.DMX Channels 4 CH Mode Channel Function DMX Value Description R Dimmer 0-255 Red dimming from dark to bright G Dimmer 0-255 Green dimming from dark to bright B Dimmer 0-255 Blue dimming from dark to bright W Dimmer 0-255 White dimming from dark to bright 8 CH Mode Channel...
- Page 7 6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
