Summary of Contents for Uplus Lighting 12X40Z WASH
- Page 1 User manual 12X40Z WASH Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………6-11 Dimension …………………………………………………………………………………………12 Trouble Shooting…………………………………………………………………………………13 Fixture Cleaning………………………………………………………… ………………………13 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Menu Operation On the base of the control panel offers a number of features, such as setting DMX fixture address, switch the lamp, run the test program, the mode selection. Primary menu Second-level menu Three-level menu/Parameter Parameter DmxAddr 001 - 512 Ch Mode 11CH/17CH/18CH/58CH... -
Page 6: Dmx Channels
Password 0 - 255 0 - 255 Tilt 0 - 255 Zoom 0 - 255 Home Set 0 - 255 Green 0 - 255 Blue 0 - 255 White 0 - 255 Reset Cance/Run FixReset Factory Cance/Run Language EN/CH Display DispFlip Open/Close DispMode... - Page 7 17 CH Mode 17CH Function DMX Values Details CH 1 0-255 0-540° CH 2 Pan Fine 0-255 16 bit CH 3 Tilt 0-255 0-270° CH 4 Tilt Fine 0-255 16 bit CH 5 P/T Speed 0-255 Fast to slow CH 6 Dimmer 0-255 Linear dimmer（dark to bright)
- Page 8 84-90 Shape 1 91-97 Shape 2 98-104 Shape 3 105-111 Shape 1 112-118 Shape 2 119-125 Shape 3 126-132 Shape 1 133-139 Shape 2 140-146 Shape 3 CH15 Shape 147-153 Pattern 1 154-160 Pattern 2 161-167 Pattern 3 168-174 Pattern 4 175-181 Pattern 5 182-188...
- Page 9 213-225 Random slow strobe CH 7 Strobe 226-238 Randon medium-speed strobe 239-251 Random fast strobe 252-255 open CH 8 red dimmer 0-255 Dark and bright green dimmer 0-255 Dark and bright CH10 blue dimmer 0-255 Dark and bright CH11 white dimmer 0-255 Dark and bright CH12...
- Page 10 252-255 Colorful rotation effect CH14 Speed 0-255 Fast to slow CH15 Shape back 0-255 Shape back color selection CH16 Back Dim 0-255 Dark to bright CH17 zoom 0-255 zoom CH18 Reset 0-239 No effect 240-250 All motor resets 251-255 No effect 58 CH Mode 58CH Function...
- Page 11 CH27 Led5 blue dimmer 0-255 Dark and bright CH28 Led5 white dimmer 0-255 Dark and bright CH29 Led6 red dimmer 0-255 Dark and bright CH30 Led6 green dimmer 0-255 Dark and bright CH31 Led6 blue dimmer 0-255 Dark and bright CH32 Led6 white dimmer 0-255...
-
Page 12: Dimension
5.Dimension... -
Page 13: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
