Summary of Contents for Uplus Lighting 10X30 COB BAR
- Page 1 User manual 10X30 COB BAR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 2. Technical Specifications…………………………………………………………………………4 3. Control Menu ………………………………………………………………………………………5 4. DMX Channels …………………………………………………………………………………6-7 5. Trouble Shooting…………………………………………………………………………………9 6. Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. • Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu Sq.NO. Display MENU ① ② DOWN ③ ENTER ④ Display: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions (unlock screen) Operations: Press "MENU"... -
Page 6: Dmx Channels
4.DMX Channels DMX Channels(5 channels) Channel Value Function Comment CH 1 0--255 Dimmer,0-100% CH 2 0—255 Red,0-100% CH 3 0—255 Green,0-100% CH 4 0--255 Blue,0-100% 0--007 Open 008--015 Black out 016--131 Strobe,slow to fast 132--139 Open 140—181 LED slow open，fast close,slow to fast CH 5 182—189 Open... - Page 7 038—052 SHOW 3 053—067 SHOW 4 068—082 SHOW 5 083—097 SHOW 6 098—112 SHOW 7 113—127 SHOW 8 CH 13 128—142 SHOW 9 143—157 SHOW 10 158—172 SHOW 11 173—187 SHOW 12 188—202 SHOW 13 203—217 SHOW 14 218—232 SHOW 15 233—247 SHOW 16 248--255...
- Page 8 CH 29 0—255 Red10,0-100% CH 30 0--255 Gree10,0-100% CH 31 0—255 Blue10,0-100% 0--007 Open 008--015 Black out 016--131 Strobe,slow to fast 132--139 Open 140—181 LED slow open，fast close,slow to fast CH 32 182—189 Open 190--231 LED fast open，slow close,slow to fast 232--239 Open 240--247...
-
Page 9: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
