- Page 1 User manual 150 COB PAR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 Technical Specifications………………………………………………………………………4 Control Menu ……………………………………………………………………………………5 DMX Channels …………………………………………………………………………………6-10 Trouble Shooting…………………………………………………………………………………11 Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Light Sources: 1*150W COB RGB3IN1 Circle: 120pcs*0.2W White LED Power Consumption: 210W Power Voltage: AC 100-240V, 50/60Hz Beam angle:40° Dimension: 21*21*24.5cm Inner Pack Size:26*26*38cm Outer Pack Size:82*55*41cm Quantity: 6pcs N.W/PCS:2.35KG G.W/CTN:23.4KG Control DMX Channel: 7/11/35 Channel Control Modes: DMX 512, Auto mode, Master/Slave, Sound active Construction Display: LED Display Data In/Out socket: 3-pin XLR sockets... -
Page 5: Control Menu
3.Control Menu A- Menu To navigate thru menu use "up" and "down" button. To enter and validate use "enter" To get out menu use "mode" After a few seconds the display turn off, press any button to restart it. Instruction MENU Display Address... -
Page 6: Dmx Channels
4.DMX Channels B・ MASTER/SLAVE MODE To use master slave mode, link product as a daisy chain with Master in first position. Then choose an automatic mode for Master and put every slave in DMX mode Addrl then slave product will act as the master. - Page 7 255 White LED ring Dimmer 1 thru 24 White Ring Strobe Open Single flash (from slow to fast) Double flash (from slow to fast) Open 255 White LED ring Macros See Macros after DMX Chart 255 White LED Macros speed DMX channel´s functions and values (35 DMX channels): MODE 35 CHANNELS CHANNELS...
- Page 8 White LED 18 White LED 19 White LED 20 White LED 21 White LED 22 White LED 23 White LED 24 White LED Ring Strobe Open Single flash (from slow to fast) Double flash (from slow to fast) Open White LED ring Macros See Macros after DMX Charts White LED macros speed D- MACROS FUNCTIONS...
- Page 9 White LED Ring Macros 0--9 11--14 White LED 1/9/17 15--19 White LED 2/10/18 20--24 White LED 3/11/19 25--29 White LED 4/12/20 30--34 White LED 5/13/21 35--39 White LED 6/14/22 40--44 White LED 7/15/23 45--49 White LED 8/16/24 50--54 White LED 1/9/17+ 5/13/21 55--59 White LED 2/10/18 + 6/14/22 White LED 3/11/19 + 7/15/23 60--64...
- Page 10 156--160 White LED 1 thru 24 macro 11 161--165 White LED 1 thru 24 macro 12 166--170 White LED 1 thru 24 macro 13 171--175 White LED 1 thru 24 macro 14 176--180 White LED 1 thru 24 macro 15 181--185 White LED 1 thru 24 macro 16 186--190...
-
Page 11: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
