Summary of Contents for Uplus Lighting 7X40Z WASH
- Page 1 User manual 7X40Z WASH Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………6 Trouble Shooting…………………………………………………………………………………7 Fixture Cleaning………………………………………………………… ………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Menu Operation On the base of the control panel offers a number of features, such as setting DMX fixture address, switch the lamp, run the test program, the mode selection. Main Menu Second Third Fourth Dmx Address 000 - 512 Dmx512 0-255 Slow... -
Page 6: Dmx Channels
Version information Vxxx Pan reset Normal/wrong Tilt Reset Normal/wrong Default settings Code settings Password:↓↓↑↑ Pan_INIT Pan fine adjust System Set TILT_INIT Tilt fine adjust ZOOM_INIT Zoom adjust SET_R RED color set SET_G Green color set SET_B Blue color set SET_W White color set Reset Reset... -
Page 7: Trouble Shooting
60-69 built-in color effect 6 70-79 built-in color effect 7 80-89 built-in color effect 8 90-99 built-in color effect 9 100-109 built-in color effect 10 110-119 built-in color effect 11 120-129 built-in color effect 12 130-139 built-in color effect 13 CH 14 Color effect 140-149... -
Page 8: Fixture Cleaning
2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity. 3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the unit or the previous one. 4.
