- Page 1 User manual 36X12Z WASH Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………………3 Technical Specifications……………………………………………………………………………4 Control Menu ………………………………………………………………………………………4-5 DMX Channels ……………………………………………………………………………………6 Trouble Shooting……………………………………………………………………………………7 Fixture Cleaning………………………………………………………… …………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Power supply: AC100V - 240V ，50 hz - 60 hz Power consumption: 420 w Color temperature: 8500 k Control: DMX512 Protection level: IP20 Channels: 16CH channel. Pan: 540°, Tilt: 270 Dimming: 0-100% linear adjustment. Strobe: stroboscopic speed (1-30 times/SEC) NW: 11KGS 3.Control Menu There are system settings, running mode, display settings, factory set up four... - Page 5 Menu Description System Settings 1, DMX address 002 confirms the modification by confirming the key, the upper and lower keys select the DMX address, and then confirm and return to exit. And ... 2, the encoder shutdown confirms the modification through the confirmation key, and then chooses to close / open up and down, confirm again, return exit.
-
Page 6: Dmx Channels
4.DMX Channels CH16 Channel Function Tilt P/T Speed Dimmer Red (R) group 1 Green (G) group 1 Blue (B) group 1 White (W) group 1 Shutter Focus Function mode Functional mode speed Pan Fine Tilt Fine Rest(255) Total (useless) -
Page 7: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
