- Page 1 User manual 100 SPOT Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels …………………………………………………………………………………6-8 Trouble Shooting…………………………………………………………………………………8 Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu set up option explain running mode From ver status: receiving DMX signal from control station or host slow pace Random walk sound control DMX address 1~512 Press OK to enter the edit status.When selected, press "up" and "down" keys to change the address code.Press OK again to select the ten editors.Press OK again to select the single bit edit.Press the Exit Edit Status once again... -
Page 6: Dmx Channels
option explain software release Current software version DMX channel value This enters the subinterface and displays channel values in value and percentage for viewing System error record If the red ERR indicator shines, the lamp is running wrong, and the details can be viewed into the subinterface.After viewing, press Clear to empty the error record Note: Sometimes it is not really a Hall or optical coupling installation problem, but a reverse motor wiring... - Page 7 020 - 024 color 4 025 - 029 color 5 030 - 034 color 6 035 - 039 color 7 040 - 044 White+color 1 045 - 049 color 1+color 2 050 - 054 color 2+color 3 color 055 - 059 color 3+color 4 060 - 064 color 4+color 5...
-
Page 8: Trouble Shooting
Slow rotation …… …… FAST rotation FAST rotation …… …… GOBO 1 RT Slow rotation 191-192 Stop Slow rotation …… …… FAST rotation 000-009 Remove the Prism 010-014 Insert prism Prism Prism slow rotation …… …… Prism fast rotation focus 000-255 Pan fine 000 - 255... -
Page 9: Fixture Cleaning
6.Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Clean with soft cloth using normal glass cleaning fluid.
