When using the AUX interface for remote configuration or dial backup, you need to connect the local

modem to the remote modem through PSTN and then to the remote device. For the configuration

procedures, refer to MSR 20/30/50 Series Routers User Manual.

Interface Card Module

The MSR 20 Series Routers are available with various types of interface card modules. For detailed

information refer to MSR 20/30/50 Series Routers Interface Card and Interface Module Manual.

SIC slide rail

Figure 3-10 SIC slide rail

Figure 3-11 Install the slide rail

Figure 3-12 Fix the slide rail
