Table 1-9 Front panel LEDs description of MSR 20-40 router
LED
PWR
SYS
CF
Table 1-10 Rear panel LEDs description of MSR 20-40 router
LED
LINK
ACT
ESM0 to 1
VCPM
VPM0 to 1

Generic Modules

The MSR 20 series is available with generic modules such as SIC interface card and ESM. For detailed
information about interface cards, refer to MSR Series Routers Interface Card and Interface Module
Manual.

SIC and DSIC Interface Cards

MSR series routers adopt modular design and support a wide range of optional SIC/DSIC interface
cards, providing various interfaces, such as synchronous/asynchronous serial interface, Ethernet
interface, E1/T1, ISDN BRI/PRI, ADSL, audio interface, and Layer 2 switching interface, and so on.
Power LED:
ON means the circuit board supplies power normally.
OFF means the circuit board does not supply power.
Hardware system operation LED:
Blinking means the system is operating normally.
Steady ON or steady OFF means the system does not operate normally.
CF card LED:
Steady green means the CF card is in place, and can be identified by the router.
Blinking green means the CF card is being accessed and cannot be removed.
Steady yellow means the CF card is in place, but cannot be identified by the router.
OFF means no CF card is inserted or the CF card cannot be identified.
OFF means no link is present.
ON means a link is present.
OFF means no data is being transmitted or received.
Blinking means data is being transmitted or received.
OFF means no ESM is in the ESMx slot.
Steady green means an ESM is in the ESMx slot and operates normally.
Steady yellow means an ESM is in the ESMx slot but does not operate normally.
OFF means no VCPM is in the slot.
Steady green means a VCPM is in the slot and operates normally.
Steady yellow means a VCPM is in the slot but does not operate normally.
OFF means no VPM is in the VPMx slot.
Steady green means a VPM is in the VPMx slot and operates normally.
Steady yellow means a VPM is in the VPMx slot but does not operate normally.
Description
Description
