H3C MSR 2600 Routers Installation Quick Start (For MSR 26-30)-6PW105
H3C MSR 2600
Tool List
The installation tools are not provided with the router. Prepare them by yourself.
路由器不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Flathead
Phillips
screwdriver
screwdriver
一字螺丝刀
十字螺丝刀
ESD-preventive
Diagonal pliers
wrist strap
斜口钳
防静电腕带
Introduction of Installation Accessories
Grounding cable
Rubber pads
( required )
( required )
地线(标配)
胶垫贴(标配)
M6 screw
(user supplied)
Bail latch (required)
M6 螺钉(用户自备)
电源线卡勾(标配)
Wear an ESD-preventive wrist strap, and make sure that the wrist strap has a good skin
!
contact and is well grounded.
操作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认防静电腕带已经良
好接地。
Needle-nose
Wire-stripping
Multimeter
pliers
pliers
尖嘴钳
剥线钳
Network cable
Blow dryer
tester
热吹风
测线仪
M4 screw
Cage nut
( required )
(user supplied)
M4 螺钉(标配)
浮动螺母(需自备)
Mounting bracket ( required )
挂耳(标配)
(For MSR 26-30)-6PW105
Mounting the Router to a Workbench
Mount the router to a workbench.
将路由器安装到工作台
万用表
Marker
Mounting the Router to a Rack
记号笔
Install cage nuts. 安装浮动螺母
BOM:3104A0C7
1U
