Summary of Contents for Gator G4KDVR32
- Page 1 G4KDVR32 QUICK START GUIDE For more information on the Gator range go to our website gatordriverassist.com INCLUSIONS: Dash Cam, GPS Power Cable, Rear Camera, Rear Camera Cable, Adhesive Surface Mount, 12/24V In-Car Charger, Rear Camera Cable, 64GB Micro SD Card...
-
Page 2: Table Of Contents
Table of contents Table of contents...........2 Product information..........3 Product overview..........4 Product features............4 System contents...........5 Optional accessories..........6 Product structure...........7 Fixing the Dash Cam..........8 Installation of Dash Cam........8 Installation of Rear View Camera......10 Downloading the Dash Cam WiFi App....11 First time pairing procedure for iOS Devices..12 First time pairing procedure for Android Devices..13 Successful pairing of your device.......14 Formating SD card..........15... -
Page 3: Product Information
Product information For more information, videos and user guides, visit our website, gatordriverassist.com/G4KDVR32 or scan the following QR code: Please ensure that you have read the product manual and instructions prior to installation and use. Failure to do so may result in the product incorrectly operating or an... -
Page 4: Product Overview
Product overview The Gator G4KDVR32 Ultra High Definition Dash Cam has been designed to provide high definition recordings of your road trips for security and evidence in the case of an accident. This Dash Cam mounts to the windscreen and records footage onto a memory card. -
Page 5: System Contents
System contents Gator Dash Cam & Dash Cam GPS power cable Adhesive Mount Mounting Bracket Rear camera cable 64G Micro SD Car Charger Rear camera Card NOTE: Recorded resolution will change to 24 fps when rear camera added... -
Page 6: Optional Accessories
Optional accessories (sold separately) Hardwire Kits. (GHWCUSB2 & GHWCOBD2) needed for Park Mode operation and to free up the vehicles 12V socket for other usage. -
Page 7: Product Structure
Product structure 5) Hand gesture sensor 1) Speaker 6) Rear Dash Cam Input 2) Microphone 7) Type-C USB Power Input 3) Camera lens 8) MicroSD Card Slot 4) LED turn on/off, pulses when paired with phone, solid when recording... -
Page 8: Fixing The Dash Cam
Fixing the Dash Cam Suggested Installation of Dash Cam 1. Place mounting bracket onto the Dash Cam by sliding on fixing point. Orientate the device so the when you attach it to the wind screen, the USB socket is on the right hand side (looking from inside the car) and its lens is on the left. - Page 9 A place close to the rear-view mirror is ideal in most cases. Do not install the device near an airbag. (Airbags are often installed along the outer left- and right-hand sides of the windscreen). 3. Insert the included Micro SD card into the Dash Cam 4.
-
Page 10: Installation Of Rear View Camera
8. The Dash Cam starts recording automatically when it receives power from the power adapter. Once power is turned off (when you turn the car off), the Dash Cam will use its on-board super capacitor to save the current file and then turn itself off. Installation of rear view camera 1. -
Page 11: Downloading The Dash Cam Wifi App
Downloading the Dash Cam WiFi App On your iOS or Android smartphone, search for the "Gator Dash Cam App". Scan the QR code below for the suitable smartphone APP for your device. Gator Dash Cam App store download https://apps.apple.com/au/app/gator-dash-cam/id1541941092 Gator Dash Cam Google Play download https://play.google.com/store/apps/... -
Page 12: First Time Pairing Procedure For Ios Devices
11. Select "Save Device" 12. The dash cam will appear under paired devices 13. A notification may appear, "Gator Dash Cam" wants to join WiFi Network "G4KDVR32-XXX"?- Select "Join" 14. Another notification may appear, "Gator Dash Cam" would like to find and connect to devices on your local network - Select "OK"... -
Page 13: First Time Pairing Procedure For Android Devices
11. Select "Save Device" 12. The dash cam will appear under paired devices 13. A notification may appear, "Gator Dash Cam" wants to join WiFi Network "G4KDVR32-XXX"?- Select "Join" 14. Another notification may appear, "Gator Dash Cam" would like to find and connect to devices on your local network - Select "OK"... -
Page 14: Successful Pairing Of Your Device
Formatting the SD Card You should do this at least every 2 to 3 months You can format your SD card using the Gator Dash Cam App. It will ask you to confirm before formatting. It is recommended you do this to keep the card in good running... -
Page 15: Downloading To Your Phone
DUTY” Downloading to your phone Using the Gator Dash Cam App you can download videos to your smartphone. If you have a lot of videos, it may take a bit of time before it will load images onto your screen, it may appear empty to start with, be patient, the video images should appear in a minute. -
Page 16: Gps Logger
GPS logger GPS geolocation data is automatically saved to the video files of the Dash Cam. This can be viewed using the Gator Dash Cam App or the computer GPS player software which can be donwloaded from the gatordriverassist.com website. -
Page 17: Product Specifications
Product specifications Resolution:Front 3840*2160 (4K @24fps) / Rear 1920*1080@24fps Sony IMX415 CMOS sensor G-sensor three axis accelerometer WiFi 2.4GHz 802.11 b/g/n Lens 140 degree wide angle fixed focus, F = 2.0 Video format MP4 Resolution Front camera standalone 3840*2160P @30FPS Video codec. -
Page 18: Trouble Shooting Guide
Trouble shooting guide Under normal operating conditions, if there are problems with the device, please refer to the following methods to resolve them. Cannot take pictures or record video? Problem: Solution: • This kind of issue is almost ALWAYS an issue related to the Memory card. - Page 19 Trouble shooting guide The adhesive mount will not stay attached to the Problem: windscreen Solution: • Ensure windscreen is clean and free of debris, use glass cleaner or an alcohol swab to clean. • Ensure that the plastic film has been removed from the adhesive pad.
- Page 20 Trouble shooting guide The Dash Cam battery only lasts for a few Problem: minutes when power is disconnected Solution: • This Dash Cam does not have a battery, it has a Super Capacitor. • The Super Capacitor only holds enough power to safely shut down the Dash Cam, securely save the last file when power is disconnected and retain settings.
- Page 21 Trouble shooting guide The Dash Cam feels warm when it is operating Problem: Solution: • It is normal for the Dash Cam to feel warm to the touch during typical use, especially when it is recording HD video. The Dash Cam stops automatically while Problem: recording Solution: •...
- Page 22 Solution: • Reset the unit by pushing and holding the reset button for a few seconds and try again. • Format Micro SD Card in a computer. • Should the problem persist please contact your Gator Service Agent for your country.
-
Page 23: Safety Information & Warnings
If out of warranty then contact the authorised repair agent, Gator Support. Do not use a chemical substance, cleaning solvent or cleaner to clean the Dash Cam, please use a moist soft cloth if you would like to clean the Dash Cam. -
Page 24: Infringement Of Copyright Warning
Technical assistance For Australasian support TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST EMAIL - service@gator.com.au... - Page 25 If you need assistance setting up or using your Gator product now or in the future, call Gator Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST or EMAIL: service@tdj.com.au Please retain this user guide for future reference.
