Summary of Contents for Gator GHDVR310
- Page 1 HDVR310 Manual Full 1.5” 1080P Resolution Screen Size Data G Sensor Wide Angle Adhesive Recording Mount...
-
Page 2: Introduction
Introduction Thank you for purchasing the Gator GHDVR310 FHD 1080P Dash Cam. Please ensure that you have read the product manual and instructions in full, prior to installation and use. Failure to do so may result in product failure/damage or incorrect operation and therefore impact the product performance. -
Page 3: Table Of Contents
Table of Contents Introduction Product overview Product features Table of contents Package components Product structure Installation of Dash Cam Fixing the Dash Cam Indicator lights Button functionalty Instructions for video and photo operation Video/Photo playback Using WiFi and phone APP software WiFi App functionality GPS logger information Dash Cam functions... -
Page 4: Package Components
Package components GHDVR310 Mounting Bracket with GPS Antenna USB to Mini USB Car Charger Installation disk INCLUDED GPS Logger 8G Micro SD Card GHDVR310 User Guide... -
Page 5: Product Structure
Product structure 1) Mini USB 6) Mode Key/ Emergency lock video key 2) Micro SD card slot 7) Mount slot 3) Menu/ Wifi function key/ Mic audio 8) Power key/ OK key/ REC record key video record key 4) Down Key (Zoom video mode) 9) Reset (Insert fine pin) 5) Up Key (Zoom video mode) -
Page 6: Installation Of Dash Cam
Installation of Dash Cam 1. Ensure windscreen is clean and free of debris. Attach adhesive mount onto the Dash Cam and firmly attach to the windscreen. 2. Fix where the vision is not blocked (Place close to rear-view mirror is recommended). -
Page 7: Fixing The Dash Cam
Fixing the Dash Cam Suggested Indicator lights 1. When the red LED is flashing circle on the screen, the Dash Cam is in recording mode. 2. When white battery symbol is flashing on the screen, the Dash Cam is being powered by the car. -
Page 8: Button Functionalty
Troubleshooting guide Button functionality Power Key Function 1: Long press to turn on and off Function 2: In standby mode, short press to record video or to stop recording Function 3: In menu, short press to perform operations or to save the set value and exit Function 4: In camera mode, short press to take a picture Function 5: In playback mode, short press to start playing video, and press... -
Page 9: Instructions For Video And Photo Operation
Instructions for video and photo operation Powering device on and off: To turn on the Dash Cam press the power key once, the white battery symbol will light up and flash when it is connected to a power source. To turn it off, hold down the power button and the device will turn off. -
Page 10: Video/Photo Playback
Video/Photo playback Press the mode button until you see the playback icon on the top left of the screen representing playback mode. Using the arrow buttons, you can choose between all your recorded videos or photos. The protected files have a lock icon meaning they cannot be deleted until unlocked. Press the OK button to select a file for playback. -
Page 11: Using Wifi And Phone App Software
Using WiFi and phone APP software With the Dash Cam’s built-in WiFi, you can use your smart device as a remote camera,viewfinder and to download files. Downloading the WiFi App The WiFi App is available to download for free at the Apple App Store™ and Google Play Store™. -
Page 12: Wifi App Functionality
WiFi APP functionality 1）Motion detection (not on this model) 2）Date and time watermark ON/OFF 3）WDR ON/OFF 4）Set video quality 5）Set photo resolution 6）Set brightness of viewer 7）Take a picture 8）Check files downloaded to app 9）Download or delete video 10）Settings 11）Set the preview volume 12）Recording / mute settings 13) Recording / stop recording... -
Page 13: Gps Logger Information
GPS logger instructions The GPS data from the GHDVR310 Dash Cam is automatically saved to the video files. In order to see the GPS data in the video files, you will need to install “JMS GPS Player” from the provided software on the disc or download from the link below. -
Page 14: Dash Cam Functions
DASH CAM functions Menu Settings Press the Menu button to get into the menu settings. You can navigate the settings menu by using the Up/Down buttons. To change or edit a selected setting, press the OK button. Press the menu button again to get out of the menu settings. -
Page 15: Record Audio
Exposure: This feature will change the white input. We recommend it always be set at ‘+0.0’. Record Audio: This Feature will allow you to turn the Dash Cam’s recording sound on or off. If you want to stop the Dash Cam recording sound in the cab of your vehicle, set this feature to ‘off’. - Page 16 Language: Allows you to choose from a selection of languages that include: English, French, Spanish, Dutch, Italian, Simplified Chinese, Traditional Chinese, Russian, Japanese, Korean and Czech. Frequency: This feature allows the best recording in conditions where street lights and Ac lighting is used. The Australian standard frequency is 50HZ so it should be set to ‘50hz’.
- Page 17 Version: This simply shows the firmware/software employed by the Dash Cam’s hardware. Colour: This changes the picture color filter to normal, Black & white or Sepia. ISO: ISO is the sensitivity of your sensor to light. The ISO setting you use depends on the amount of light in the scene you are photographing.
-
Page 18: Resetting Dash Cam
Resetting DASH CAM To hard reset the device in the case of a system jam or crash. Insert a fine point pin into reset hole on the bottom of the unit. DASH CAM glossary Micro SD Slot: Where the Micro SD card is inserted (Max size is 32GB Class 10). USB Interface: The USB charging adapter is used to power the Dash Cam with the Mini USB cable. -
Page 19: Product Specifications
Product specifications NTK96658 Display 1.5-inch LCD screen Color Black Video 1920*1080P at 30fps 720P 1280*720 at 30fps VGA 640*480 at 30fps Picture 12M/10M/8M/5M/3M/2M/1.3M/VGA Picture format Viewing Angle 140 degree view angle WiFi “FinalCam” APP Functions G-Sensor, Loop recording G- Sensor sensitivity Low, Mid, High OSD Language English, Russian, Chinese, etc... -
Page 20: Troubleshooting Guide
Troubleshooting guide Under normal operating conditions, if there are problems with the device, please refer to the following methods to resolve. Cannot take pictures or record video? Please check whether there is enough space on the micro SD card or internal storage. Stopping automatically while recording? Due to the high amount of HD video data being recorded, please use a high-speed Micro SD card. -
Page 21: Safety Information & Warnings
Safety information & warnings Do not use the Dash Cam in damp working conditions; the Dash Cam is not waterproof Do not try opening the shell or trying to repair the Dash Cam by yourself. If the accessories for the Dash Cam have any problems, please take it to an authorised repair agent for repair. -
Page 22: Technical Assistance
Technical assistance If you need assistance setting up or using your Gator product now or in the future, call Gator Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST Please retain this user guide for future reference.
