Ethernet communication module ETHM-1 Plus Firmware version 3.11 ethm1_plus_en 11/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
Page 2
FreeRTOS is used in this device (www.freertos.org). SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
Programming the GUARDX program settings ............. 35 Initiating connection from GUARDX program .............. 36 Initiating connection from keypad (through control panel) ........... 37 Initiating connection by SMS message ............... 37 Establishing connection via the SATEL server ............37 7.1.2 Web browser ...................... 38 7.1.3 INTEGRA CONTROL application ...............
192-bit key. If the ETHM-1 Plus module is connected to the INTEGRA Plus / INTEGRA control panel, you can connect the INT-GSM / INT-GSM LTE module to the module. This will allow the cellular data network to be used as a backup communication path and enable dual path reporting.
- tamper input (NC) – if not used, it should be shorted to common ground. A RS485 B - RS-485 port for connecting INT-GSM / INT-GSM LTE module if the ETHM-1 Plus module is connected to the INTEGRA Plus / INTEGRA (required control panel firmware version: 1.19 or newer).
ETHM-1 Plus SATEL − connecting a computer for the purpose of updating the module firmware. − connecting to the control panel RS-232 port. Depending on the alarm system in which the module is installed: INTEGRA Plus / INTEGRA: required for programming the system in the DLOADX program via Ethernet;...
SATEL ETHM-1 Plus 5 Installation Disconnect power before making any electrical connections. The device is designed to be used only in the local area networks (LAN). It must not be connected directly to the public computer network (MAN, WAN). For establishing connection with public networks, use a router or xDSL modem.
PERFECTA CONTROL app via Ethernet. Fig. 3. Wiring diagram of the cable connecting RS-232 ports of ETHM-1 Plus module and INTEGRA control panel with PIN5 connector socket.
ETHM-1 Plus module), the INT-GSM / INT-GSM LTE module will take over tasks from the ETHM-1 Plus module if the Ethernet connection is lost. These tasks are performed via cellular data network. Therefore many options and parameters apply to both modules.
Page 10
(module is identified as “ETHM-1”). INT-GSM options Options applicable to the INT-GSM / INT-GSM LTE module are available if the INT-GSM / INT-GSM LTE module is connected to the ETHM-1 Plus module (the module is identified as “ETHM+GSM”).
Fig. 6. DLOADX program: settings of the module connected to INTEGRA / INTEGRA Plus control panel (module is identified as “ETHM+GSM” – INT-GSM module is connected to ETHM-1 Plus module). DLOADX Communication with DLOADX [Connect DLOADX] – if this option is enabled, connection can be established between the DLOADX program and the alarm control panel via the module.
Page 12
ETHM-1 Plus SATEL In the LCD keypad, the function for programming address of the computer with DLOADX program is available in the user menu, C submenu (available HANGE OPTIONS to service and administrators). Port [Port (DLOADX)] – number of the TCP port used for communication with the DLOADX program.
Page 13
DLOADX program: →“Structure” window →“Hardware” tab →“Keypads” branch. SATEL server Connection via Satel server [SATEL server] – if the option is enabled, the module connects to the SATEL server and the communication via the SATEL server with the control panel can be established (Connection Setup Service).
SATEL server. You can read the QR code by using a mobile device or export to the file and transmit to the users. The QR code facilitates configuring the INTEGRA CONTROL application settings.
Page 15
SATEL ETHM-1 Plus Fig. 7. DLOADX program: “IP filter” tab. IP Address – if the subnet option is disabled: the network address from which connection with the Ethernet module can be established. If the subnet option is enabled: the IP address used for defining the subnet from which connection with the Ethernet module can be established.
The following is relevant if the INT-GSM / INT-GSM LTE module is not connected to the ETHM-1 Plus module. If INT-GSM / INT-GSM LTE is connected to ETHM-1 Plus, please refer to the INT-GSM / INT-GSM LTE module manual for description of remote...
INTEGRA – if this option is enabled, the INTEGRA Plus / INTEGRA control panel firmware will be updated. ETHM-1 Plus – if this option is enabled, the ETHM-1 Plus module firmware will be updated. Download firmware – click to download new version of firmware.
Page 18
IP cameras in case of different events (e.g. motion detection). In the “IP zone” tab, the settings of HTTP notification support are available. The notifications can control the alarm system zones. The cameras must operate in the same local network as the ETHM-1 Plus module.
SATEL ETHM-1 Plus Write – click to write the IP zones settings to the module. Quit – click to cancel reading / writing the settings. User functions If the INTEGRA CONTROL application is used in the mobile device, the virtual keypad allows you to quickly start user functions after entering the code and pressing an arrow key.
ETHM-1 Plus SATEL Fig. 11. DLOADX program: parameters and options of the virtual keypad available in GUARDX program, web browser or mobile device. Macro commands In the DLOADX program you can prepare macro commands that will be used in the INTEGRA CONTROL app: →“Structure”...
Page 21
SATEL ETHM-1 Plus The macro commands settings are stored in the ETHM-1 Plus module memory. The INTEGRA CONTROL app can download the macro commands from the module after establishing connection. Prepared macro commands can also be exported to a file. After the file is copied to a mobile device, the macro commands can be imported to the app.
Page 22
ETHM-1 Plus SATEL Fig. 12. DLOADX program: “Groups” tab. Definitions In the “Definitions” tab you can configure the macro command settings. New macro – click to create a new macro command. Remove macro – click to remove the selected macro command.
Page 23
SATEL ETHM-1 Plus Fig. 13. DLOADX program: “Definitions” tab. Icon Icon – the macro command icon. Click to display the list of icons, then click the icon that is to be used. If the State follow output option is enabled, select 2 icons for the macro commands.
Page 24
ETHM-1 Plus SATEL Commands Commands list – commands assigned to the currently highlighted macro command. buttons allow you to change the order of commands (moving the highlighted command up and down). Add – click to add to the list a new command, selected in the “Command” field.
Page 25
SATEL ETHM-1 Plus Priority – telegram priority (if two elements of the bus start transmitting simultaneously, the telegram with higher priority will be sent first). KNX telegram (v2) – the following settings are available for the function: Module INT-KNX – INT-KNX-2 module in which the value is to be set.
Page 26
ETHM-1 Plus SATEL 4. Enter a name for the new macro command. 5. If running a macro command is to be each time preceded by user authorization, enable the Authorization required option. 6. If the macro command is to be unavailable when any of the partitions managed by the keypad is armed, enable the Disabl.
Page 27
SATEL ETHM-1 Plus 9. If the icon is to change depending on the selected output state: − enable the State follow output option; − indicate the output number; − select the icons. 10. If the macro command name is to be displayed, enable the Show name option.
Page 28
ETHM-1 Plus SATEL 12. Configure the command parameters. 13. Click the “Add” button. A new command will appear on the list of commands assigned to the macro command. You can still modify parameters of the command after clicking on it (having made the changes, click the “Change”...
Page 29
SATEL ETHM-1 Plus 17. Enter the group name, if it is to be displayed. 18. Click and select the icon for the macro command group. 19. Click the “Add macro” button. A list of all defined macro commands will be displayed.
ETHM-1 Plus SATEL 6.2 Module connected to PERFECTA 64 M control panel You can configure the module settings using a computer with the PERFECTA Soft program installed or using the keypad. 6.2.1 Programming in the PERFECTA Soft program Required version of the PERFECTA Soft program: 2.01 (or newer).
/ operated via Ethernet. Report Satel server connection trouble [ETHM-1 SRV TRBL] – if this option is enabled, the module will report a trouble in case of communication problems with the SATEL server. 6.3 Module connected to VERSA control panel You can configure all of the module settings using a computer with the DLOADX program installed.
SATEL service LAN [SATEL server LAN] – if the option is enabled, the module connects to the SATEL server and the communication via the SATEL server with the control panel can be established (Connection Setup Service). This way of communication requires no additional configuring of the network device through which the module connects to the public network.
Page 33
SATEL server. You can read the QR code by using a mobile device or export to the file and transmit to the users. The QR code facilitates configuring the VERSA CONTROL application settings.
Messaging E-MAIL The e-mail messaging settings stored in the ETHM-1 Plus module memory. Before you make any changes, click the “Read” button. After you have made the changes – click “Write”. The settings stored in the keypad are not read / written after you click in the main menu.
Page 35
SATEL ETHM-1 Plus SMTP account – click to open “SMTP account” window. Read – click to read the data related to e-mail messaging. Write – click to write the data related to e-mail messaging. Fig. 16. DLOADX program: configuring the e-mail messaging.
7 Programming and operating the alarm system via Ethernet An alarm system in which the ETHM-1 Plus module is installed can be programmed and operated remotely via Ethernet. Details vary depending on the alarm system. 7.1 INTEGRA Plus / INTEGRA system The Ethernet communication can be used to: •...
SATEL ETHM-1 Plus 4. Establishing connection via the SATEL server (Connection Setup Service). The control panel can be operated from any location. No public IP address is required for the control panel or the computer with GUARDX program. Required settings of the module for all methods of establishing connection: •...
Select the “ETHM-1 MAC” variant. ETHM-1 MAC – hardware address of Ethernet module. ETHM-1 ID – individual ID number assigned to the module by the SATEL server. Server key – a string of up to 12 alphanumeric characters (digits, letters and special characters) used for data encryption during communication between the control panel and the computer with GUARDX.
• enabled Connection via Satel server option. Required settings of the GUARDX program for communication via the SATEL server: • programmed: ID number assigned to the module by the SATEL server (ETHM-1 ID), MAC address of the module (ETHM-1 MAC) and data encryption key (Server key).
It is recommended that the 32-bit version of Java Virtual Machine be installed. 1. Start the web browser. 2. In the address field, enter the IP address of ETHM-1 Plus module, and then press ENTER. If a port other than 80 is to be used for communication between the module and the web browser, the address entered must be followed by a colon and the port number.
“App Store” (iOS system devices). On the www.satel.eu website, you will find links to the locations from which the applications can be downloaded. The INTEGRA CONTROL app can connect directly to the ETHM-1 Plus module (the module must have a public IP address) or establish connection via the SATEL server (Connection Setup Service –...
Page 42
ETHM-1 Plus SATEL 1. Configure the communication settings. You can enter the settings manually (see “Adding communication settings manually”) or import them by using a QR code (see “Importing communication settings by using a QR code”). 2. Enter the name for alarm system. The name helps to identify the system when the application is in use (you can define settings for multiple alarm systems).
1. Select the “Connection via SATEL server using MAC address” communication method. 2. Enter the module’s MAC address. 3. Enter the module’s ID number (identifier assigned to the module by the SATEL server). 4. Enter the data encryption key – the same as in the module (GUARDX key).
Page 44
1. Enable the “Server Satel” option. 2. Enter the module’s MAC address. 3. Enter the module’s ID number (identifier assigned to the module by the SATEL server). 4. Enter the data encryption key – the same as in the module (GUARDX key).
SATEL ETHM-1 Plus Establishing the communication Tap the name of the alarm system. After communication with the control panel is established, the application will ask you to enter the user code. After you enter the code, the “Macros” screen will be displayed (in the iOS system you can define, which screen will be displayed as the first one after the next communication is established).
ETHM-1 Plus SATEL • operate the alarm system in the VERSA CONTROL mobile app. For information on how to program the alarm system via Ethernet using the DLOADX program, please refer to the control panel programming manual. For information on the VERSA CONTROL app, please refer to the control panel user manual.
