ZKTeco FaceDepot-7BL User Manual

Hide thumbs Also See for FaceDepot-7BL:

Quick start manual (13 pages)

Quick start manual (14 pages)

User manual (89 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

FaceDepot-7BL

User Manual

FaceDepot-7BL

Date: November 2023

Doc Version: 1.3

English

Thank you for choosing our product. Please read the instructions carefully

before operation. Follow these instructions to ensure that the product is

functioning properly. The images shown in this manual are for illustrative

purposes only.

P a g e

| 1

For further details, please visit our Company's website

www.zkteco.com.

User Manual

Table of Contents

Need help?

Do you have a question about the FaceDepot-7BL and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco FaceDepot-7BL

Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.zkteco.com. P a g e Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Page 2 Copyright © 2023 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
Page 3 FaceDepot-7BL User Manual relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been advised of the possibility of such damages. This manual and the information contained therein may include technical, other inaccuracies or typographical errors.
Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks.
Page 5 The general information which helps in performing the operations faster. The information which is significant. Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 6: Table Of Contents
5.4.1 WIEGAND INPUT ......................................45 5.4.2 WIEGAND OUTPUT ...................................... 47 SYSTEM SETTINGS ..........................48 ......................................48 ATE AND ....................................50 CCESS ETTING .......................................51 ARAMETERS ★ ....................................53 ARAMETERS ★ ..................................53 INGERPRINT ARAMETERS P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 7 APPENDIX 1 ............................... 87 ................87 EQUIREMENTS OF OLLECTION AND EGISTRATION OF ISIBLE IGHT MAGES ..........................88 EQUIREMENTS FOR ISIBLE IGHT IGITAL MAGE APPENDIX 2 ............................... 89 ........................................89 RIVACY OLICY ......................................91 FRIENDLY PERATION P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 8: Data Security Statement
ZKTeco, as a smart product supplier, may also need to know and collect some of your personal information in order to better assist you in using ZKTeco's goods and services, and will treat your privacy carefully by developing a Privacy Policy.
Page 9: Electrical Safety
If the device has major defects that you cannot solve, contact your dealer as soon as possible.  Dust, moisture, and abrupt temperature changes can affect the device's service life. You are  advised not to keep the device under such conditions. P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 10 The warranty service does not cover accidental damage, damage caused by mis-operation, and  damage due to independent installation or repair of the product by the user. P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 11: Instructions To Use
The distance between the device and a user whose height is within 1.4m-1.8m is recommended to be 0.5m. Users may slightly move forwards and backwards to improve the quality of facial images captured. P a g e | 10 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 12 FaceDepot-7BL User Manual Facial Expression and Standing Posture Note: During enrollment and verification, please remain natural with facial expression and standing posture. P a g e | 11 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 13: Palm Registration
Keep the face in the center of the screen during registration. Please face the camera and stay still during face registration. The page looks like the following image: P a g e | 12 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 14: Standby Interface
★The punch states can be switched directly by using the screen shortcut keys. Click anywhere on the screen without icons, and six shortcut keys appear, as shown in the figure below: P a g e | 13 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 15 User Manual Press the corresponding shortcut key to select the current attendance state, which is shown in green. Please refer 7.5 Shortcut Key Mappings for specific operations. P a g e | 14 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 16: Virtual Keyboard
The device will automatically distinguish between the palm and the face verification mode. Place the palm in the palm collector area, and the device will automatically detect the palm verification mode. P a g e | 15 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 17 User Manual 1: 1 Palm Verification Mode Click the button on the main screen to open 1:1 palm verification mode. Enter the user ID and press OK. P a g e | 16 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 18: Fingerprint Verification
The device will enter the fingerprint authentication mode when a user presses his/her finger onto the fingerprint scanner. Please follow the instructions to place your finger on the sensor. For details, please refer 1.1 Finger Positioning. P a g e | 17 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 20 / fingerprint/ face/ badge/ password verification, the following screen will appear. Select the fingerprint icon to enter fingerprint verification mode. P a g e | 19 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 23: Facial Verification
The 1:1 Facial Verification mode compares the face captured by the camera with the facial template related to the entered user ID. Press on the main interface to open the 1:1 facial verification mode. Enter the user ID and click OK. P a g e | 22 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 24 , fingerprint, card number and password in addition to the face, the following screen will appear. Select the icon to enter the face verification mode. After successful verification, the prompt "Successfully verified" will appear. P a g e | 23 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 26: Card Verification
User ID registered in the device. Press on the main interface to open the 1:1 card verification mode. Enter the user ID and click OK. P a g e | 25 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 27 If an employee registers palm , fingerprint, face, and password in addition to the card, the following screen will appear. Select the icon to open the card verification mode. P a g e | 26 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 28: Password Verification
If an employee registers palm , fingerprint, face and card number in addition to the password, the following screen will appear. Select the icon to open the password verification mode. P a g e | 27 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 31: Combined Verification
For example, if a user uses Face Registration but the verification mode is Face + Password, the user verification will be failed. P a g e | 30 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 32: Main Menu
Note: When users use the product for the first time, they should operate it after setting administrator privileges. Click User Mgt. to add an administrator or edit user permissions as a super administrator.If the P a g e | 31 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 33 FaceDepot-7BL User Manual product does not have an administrator setting, the system will show an administrator setting command prompt every time you enter the device menu. P a g e | 32 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 34: User Management
Register a User ID and Name Enter the User ID and Name. Note: A Username may contain up to 17 characters. The User ID may contain 1 to 9 digits by default. P a g e | 33 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 35 The authentication is based on the authentication method(s) that the super administrator has registered. Please refer 1.7 Verification Method. ★ Register Palm Click Palm to enter the palm registration page. Select the palm to be enrolled. P a g e | 34 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 36 User Manual Register Fingerprint★ Click Fingerprint to enter the fingerprint registration page. Select the finger to be enrolled. Press the same finger consecutively until the success message appears. P a g e | 35 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 37 Click Password to open the password registration page. Enter a password and re-enter it. Click OK. If the two entered passwords are different, the prompt "Password does not match" will appear. Note: The password may contain one to eight digits by default. P a g e | 36 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 38 Duress Fingerprint: The user may specify one or more fingerprints that have been registered as a duress fingerprint(s). When press the finger corresponding to the duress fingerprint on the sensor and the verification is successful, the system will immediately generate a duress alarm. P a g e | 37 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 39: Search For Users
Click the search bar on the user list and enter the retrieval keyword (The keyword may be an ID, surname or full name.). The system will search for the users related to the information. P a g e | 38 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 40: Edit Users
Select a user from the list and click Delete to enter the delete user interface. Select the user information to be deleted and click OK. Note: If you select Delete User, all information of the user will be deleted. P a g e | 39 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 41: User Role
Click Name and enter the name of the role. Click Define User Role to assign privileges to the role. Once the privilege assignment is completed, click Return. P a g e | 40 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 42 User Mgt. > New User > User Role. If no super administrator is registered, the device will prompt "Please enroll super admin first!” after clicking the enable bar. P a g e | 41 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 43: Communication Settings
When the device needs to communicate with a PC over the Ethernet, you need to configure the network settings and ensure that the device and the PC are connected to the same network segment. Click Ethernet on the Comm. Settings interface. P a g e | 42 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 44: Pc Connection
The identity number of the device, which ranges between 1 and 254. If the Device ID communication method is RS232/RS485, you need to enter this device ID in the software communication interface. P a g e | 43 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 45: Cloud Server Setting
This function is enabled by default. This function can be enabled or disabled through the menu interface, and when changing the HTTPS status, the device will pop up a security prompt, and restart after confirmation. P a g e | 44 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 46: Wiegand Setup
The default value is 1000 microseconds, which can be adjusted within the range Pulse Interval(us) of 200 to 20000 microseconds. ID Type Selects between the User ID and badge number. P a g e | 45 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 47 “C “denotes the card number; “E” denotes the even parity bit; “O” denotes the odd parity bit; “F“ denotes the facility code; “M” denotes the manufacturer code; “P” denotes the parity bit; and “S” denotes the site code. P a g e | 46 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 48: Wiegand Output
Pulse Width(us) high-frequency capacitance regularly within a specified time. Pulse Interval(us) The time interval between the pulses. ID Type Selects between the User ID and Badge number. P a g e | 47 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 49: System Settings
If users need to set date and time manually, disable Date and Time Auto Sync first, and then tap Manual Time Setting to set date and time and tap Confirm to save. P a g e | 48 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 50 Note: For example, the user sets the time of the device (18:35 on March 15, 2019) to 18:30 on January 1, 2020. After restoring the factory settings, the time of the equipment will remain 18:30 on January 1, 2020. P a g e | 49 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 51: Access Logs Setting
When the remaining memory space reaches a predefined value, the device will Alert/ Access Logs automatically display a record memory warning. Users may disable the function or set a valid value between 1 and 9999. Warning P a g e | 50 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 52: Face Parameters
The valid value ranges from 65 to 120. The higher the thresholds, the lower the misjudgment rate, the higher the rejection rate, and vice versa. The value 75 is recommended. P a g e | 51 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 53: Motion Detection Sensitivity
Improper adjustment of the exposure and quality parameters may severely Notes affect the performance of the device. Please adjust the exposure parameter only under the guidance of the after-sales service technician of our company. P a g e | 52 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 54: Palm Parameters
Under the 1:N verification method, the verification will only be successful when the 1:N Match similarity between the acquired fingerprint data and the fingerprint templates enrolled Threshold in the device is greater than the set value. P a g e | 53 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 55: Factory Reset
This feature restores the device parameters, such as communication settings and system settings, to factory settings (will not clear registered user data). Click Reset on the System interface. Click OK to reset. P a g e | 54 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 56: Security Settings
After enabled, the personnel verification result will show the user's verification Display mode. The verification result will not show the verification mode after you Verification Mode disable it. P a g e | 55 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 57: Usb Upgrade
The device's firmware program can be upgraded with the upgrade file in a USB drive. Before conducting this operation, please ensure that the USB drive contains the correct upgrade file and is properly inserted into the device. P a g e | 56 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 58: Personalize Settings
You may customize the interface settings such as voice, bell, punch state options, and shortcut key mappings. Click Personalize on the main menu interface. Interface Settings You can customize the display style of the main interface. Click User Interface on the Personalize interface. P a g e | 57 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 59: Voice Settings
Selects whether to enable voice prompts during operating. Touch Prompt Selects whether to enable keypad sounds. Volume Adjusts the volume of the device. The valid range is 0-100. P a g e | 58 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 60: Bell Schedules
Delete a Bell On the All Bell Schedules interface, tap the bell to be deleted and click Delete, and select Yes to delete the bell. P a g e | 59 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 61: Punch State Options
The time duration for time out, i.e. remaining inactive in the main menu. Timeout (s) Punch State Specifies whether an attendance status must be selected during verification. Required P a g e | 60 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 62: Shortcut Key Mappings
The switch time is used in conjunction with the punch state options. When the punch state mode is set to auto mode, the switch time should be set. Select the switching period and set the switch time every day, as shown in the figure below: P a g e | 61 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 64: Data Management
The Data Management function is used to delete the relevant data in the device. Click Data Mgt. on the main menu interface. Delete Data Tap Delete Data on the Data Mgt. interface to delete the required data. P a g e | 63 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 65: Function Description
Delete All or Delete by Time Range. If you select Delete by Time Range, you need to set a specific time range to delete all the data with the period. Set the time range and click OK. Select Delete by Time Range. P a g e | 64 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 66: Access Control
In default settings, the new users are allocated into the first group with the default group time zone and access combination as “1“ and set to an unlocking state. P a g e | 65 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 67: Access Control Options
1 to 9 times, an alarm will be triggered. If the value is set as “None”, the alarm Alarm will never be triggered due to failed verifications. P a g e | 66 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 68: Auxiliary Input Configuration
Setting input configuration and alarm. However, the access control data in Data Mgt. is excluded. P a g e | 67 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 69: Time Schedule
Click Time Schedule on the Access Control interface. Click the grey box to search for a time zone. Enter the number of time zone (maximum: 50 zones). P a g e | 68 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 70 The effective time period to unlock the door is open all day (00:00~23:59) or when the ending time is later than the starting time, such as 08:00~23:59. The default time zone 1 indicates that the door is open all day long. P a g e | 69 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 71: Holiday Settings
On the Holidays interface, select a holiday to be deleted and click Delete. Click OK to confirm the deletion. After deletion, this holiday is no longer displayed on All Holidays interface. P a g e | 70 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 72: Access Groups
When the holiday is set to be invalid, the access control time of the personnel in a group is not affected during holidays. P a g e | 71 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 73: Combined Verification Settings
5 people, and the 5 individuals are from 5 groups, namely, access control group 1 (AC group 1), AC group 3, AC group 5, AC group 6, and AC group 8, respectively. P a g e | 72 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 74: Duress Options Settings
1 to 999 seconds. Initially, the user sets the 6-digit duress password. When the user enters this Duress Password★ duress password for verification, an alarm signal will be generated. P a g e | 73 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 75: Usb Manager
Downloads the blocklisted photos taken after failed verifications within a specified Blocklist Photo time period or all the pictures taken after failed verifications from the device to a USB drive P a g e | 74 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 76: Upload
Uploads a JPG picture named with a user ID from a USB drive to the device. Before uploading, you may select Upload Current Picture or Upload All Pictures. Portrait P a g e | 75 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 77: Attendance Search
2. If you want to search the records of all users, click OK without entering any user ID. Select the time range in which the records you want to search for. P a g e | 76 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 78 FaceDepot-7BL User Manual 3. Click the record list in green to view its 4. The below figure shows the details of the details. selected record. P a g e | 81 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 79: Autotest
To test whether the clock works normally and accurately with a stopwatch. Touch Test Clock RTC the screen to start counting and press it again to stop counting. P a g e | 82 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 80: System Information
U disc export. Note: The current privacy policy's text is only available in Simplified Chinese/English. However, translation of other multi-language content is underway, with more iterations. P a g e | 83 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 81: Connection To Zkbiosecurity Software
Server Port: Set the Server port of ZKBioSecurity (The default is 8088). In Software Login to ZKBioSecurity software, click System > Communication > Communication Device to set the ADMS service port, as shown in the figure below: P a g e | 84 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 82: Add A Device To The Software
Click Search, and it will prompt Searching……. After searching, the list and the total number of access controllers will be displayed. Click Add to add the required device. P a g e | 85 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 83: Add Personnel On The Software
Click Personnel > Person > New to add new personnel. After setting all the parameters, click OK. Note: For other specific operations, please refer ZKBioSecurity User Manual. P a g e | 86 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 84: Requirements Of Live Collection And Registration Of Visible Light Face Images
Do not include more than one face in the capturing area. A distance of 50cm to 80cm is recommended for capturing the image. (the distance is adjustable, subject to body height). P a g e | 87 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 85 The captured person should be easily visible, natural in color, no harsh shadow or light spot or reflection in the face or background. The contrast and lightness level should be appropriate. P a g e | 88 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 86: Privacy Policy
Privacy Policy Notice: To help you better use the products and services of ZKTeco and its affiliates, hereinafter referred as "we", "our", or "us", the smart service provider, we consistently collect your personal information. Since we understand the importance of your personal information, we took your privacy sincerely and we have formulated this privacy policy to protect your personal information.
Page 88: Eco-Friendly Operation
The components which contain toxins or harmful elements are included due to the current economic or technical limitations which prevent their replacement with non-toxic materials or elements. P a g e | 91 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
Page 89 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
