Summary of Contents for GIGAIPC QBiX-Jetson Series
- Page 1 QN-ORNX16 (QN-ORNXD-SI) Quick Start Guide www.gigaipc.com...
-
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. - Page 3 ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. • NVIDIA®, Jetson™ are trademarks of NVIDIA Corporation All other product names or trademarks are properties of their respective owners. www.gigaipc.com...
-
Page 4: Packing List
19V / 65W adapter Power cord (May vary based on local distribution) VESA mount VESA screws (M4-10L x 4pcs, M3-3L x 2pcs) If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements
China RoHS Requirements 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 限用物質及其化學符號 Restricted substances and its chemical symbols 六價鉻 多溴聯苯 多溴二苯醚 單元 Ｕnit Lead Mercury Cadmium 鉛 汞 鎘 Hexavalent Polybrominated Polybrominated chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (PBB) (PBDE) －... - Page 10 C) Wireless Module: How to safely install the Module (Wireless Module inclusion may vary based on local distribution) ..............21 Antenna Installation (Antenna inclusion may vary based on local distribution) ............ 22 VESA Bracket ..............23 Recovery button ............24 Safety and Regulatory Information ....... 25 www.gigaipc.com...
-
Page 11: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 12 23.2 121.0 121.0 39.1 40.0 41.9 80.3 www.gigaipc.com...
-
Page 13: Specifications
1 x Power button with LED 1 x Recovery button 1 x Scrw type DC Jack 1 x RJ45 LAN Port Rear I/O 1 x HDMI 2 x USB 3.2 Gen2x2 2 x External Antenna Holes (Optional) Power +19VDC www.gigaipc.com... - Page 14 Single Box size: 286 x 178 x 66 (mm) Packaging Content Including: Power Cord : Optional (by region) PSU ADP 19V 65W 100-240VAC x 1 (P/N: 25EP2-10065Q-A3S) VESA Mount x 1 (P/N: 25HB1-TPL021-S8R) VESA Screws x1 (P/N: 25KSD-000002-C0R) Order System: 9BQNORNXDMR-SI (Box packing) Information www.gigaipc.com...
-
Page 15: Chapter 2 - Quick Start Guide
Chapter 2 Chapter 2 – Quick Start Guide www.gigaipc.com... - Page 16 Dimension 23.2 121.0 121.0 39.1 40.0 41.9 80.3 www.gigaipc.com...
-
Page 17: Getting Familiar With Your Unit
1 x Kensington lock slot USB 2.0 Power button [Rear I/O Side] [Right Side] 2 x External Antenna Holes (optional) HDMI DC IN 2 x USB 3.2 Gen2x2 VGA input HDMI input 1 x GbE LAN port (Optional) (Optional) www.gigaipc.com... - Page 18 * Before Connecting the power, make sure to fasten the case securely. [Bottom PCB Side] Information 1 x 2280 M.2 M-Key (M2M1) 1 x 2280 M.2 M-Key (M2M2) 1 x 2230 M.2 E-Key www.gigaipc.com...
- Page 19 Carefully insert the M.2 SSD into the Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot hole (Location : M2M1_SO) slot, and secure with the screw. 鎖入固定於無線模組中央頂端的螺 移除位置 M2M1_SO 的螺絲。 小心的安裝 M.2 SSD，並使用步驟 1 小心地將無線模組安裝於M.2插槽中。 絲。 卸下的螺絲固定 M.2 SSD。 www.gigaipc.com...
- Page 20 Carefully remove the screw and the Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot hole (Location : M2M2_SO) M.2 SSD. 鎖入固定於無線模組中央頂端的螺 移除位置 M2M2_SO 的螺絲。 小心的將 M.2 SSD 從 M.2 插槽移除。 小心地將無線模組安裝於M.2插槽中。 絲。 www.gigaipc.com...
- Page 21 Lock the screw in the middle Install the antenna on the left side of the Lock the screw in the middle. Install the antenna on the left side of the connection connection wireless module down 使用步驟 1 卸下的螺絲，將無線模 wireless module down. 組固定於插槽中。 將天線安裝於無線模組上。 www.gigaipc.com...
-
Page 22: Antenna Installation
Carefully insert the antennas into the Turn the antennas clockwise until they are connectors completely secure on the connectors 小心地安裝外接天線。 將外接天線依照順時鐘方向旋轉直到鎖 緊。 Flip up the antenna heads so that they are perpendicular to the machine 將外接天線前端向上扳起與系統垂 直 。 www.gigaipc.com... -
Page 23: Vesa Bracket
入 VESA 支撐架的滑軌孔，向下壓至定位點 後即可固定。 Note : If need to use the VESA mounting plate, the total weight of the system and monitor should be less than 7kg. 懸掛裝置 / 設備 ( 被掛的設備 , 例如 Monitor…等 ) 總重量不可超過 7 公斤 . www.gigaipc.com... - Page 24 BSP. 4. Back to QN-ORNX16 System, complete the informations which the system requires you to fill-in. 5. After filling in all the information, the system will reboot automatically, your re-program process is complete. www.gigaipc.com...
-
Page 25: Safety And Regulatory Information
At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. www.gigaipc.com... - Page 26 Non-rechargeable batteries are not to be recharged. 非充電電池不得進行充電。 Remove and immediately recycle or dispose of used batteries, batteries from equipment not used for an extended period of time according to local regulations and keep away from children. DO NO dispose of batteries in household trash or incinerate. 請按照當地法規，立即回收或妥善處理用過的電池，以及長時間未 使用設備中的電池，並遠離兒童。請勿將電池丟入家庭垃圾或焚燒 處理。 Even used batteries may cause severe injury or death. 即使是已使用的電池也可能導致嚴重傷害或死亡。 Do not force discharge, recharge, disassemble, heat above (manufactruer's specified temperature rating) or incinerate. Doing so may result in injury due to venting, leakage or explosion resulting in chemical burns. 請勿強行放電、充電、拆解、加熱超過（製造商指定的溫度範圍） 或焚燒。否則可能會導致氣體釋放、洩漏或爆炸，從而引發化學灼 傷或其他傷害。 For treatment information, call a local poison control center. 如需處理相關資訊，請聯絡當地毒物控制中心。 The product contains non-replaceable batteries. 本產品含有不可更換的電池。 www.gigaipc.com...
