Avalue Technology EMX-ALUC User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
EMX-ALUC
12th Gen Intel® Core™ Soc BGA Processor, Thin Mini ITX
Motherboard.
User's Manual
Ed – 11 February 2025
st
1
Copyright Notice
Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No: E2047EMAU00R

Advertisement

loading
Need help?

Need help?

Do you have a question about the EMX-ALUC and is the answer not in the manual?

Questions and answers

Related Manuals for Avalue Technology EMX-ALUC

Summary of Contents for Avalue Technology EMX-ALUC

  • Page 1 EMX-ALUC 12th Gen Intel® Core™ Soc BGA Processor, Thin Mini ITX Motherboard. User’s Manual Ed – 11 February 2025 Copyright Notice Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No: E2047EMAU00R...
  • Page 2 EMX-ALUC User’s Manual Document Amendment History Revision Date Comment February 2025 Avalue Initial Release 2 EMX-ALUC User’s Manual...
  • Page 3 For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2025 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc.
  • Page 4 ㆍDescription of your software (operating system, version, application software, etc.) ㆍA complete description of the problem ㆍThe exact wording of any error messages To receive the latest version of the user’s manual; please visit our Web site at: www.avalue.com 4 EMX-ALUC User’s Manual...
  • Page 5 On the other hand, if the new product defect is resulting from incorrect configuration or erroneous use by the user instead of any problem of the hardware itself, the customer will also be requested to pay for relevant handling fees. EMX-ALUC User’s Manual...
  • Page 6 Lacking detailed statement of fault steps also makes the problem hard to be identified, sometimes resulting in second-time repairs. 6 EMX-ALUC User’s Manual...
  • Page 7 • Product has been altered or its label of the serial number has been torn off. • Product functionality issues resulting from improper use by the user, unauthorized dismantle or alteration, unfit operation environment, improper maintenance, accident EMX-ALUC User’s Manual...
  • Page 8 If the customer demands an additional maintenance analysis report, a service fee of various level will be charged depending on the warranty status. In case the analysis result shows that the defect attributes to Avalue’s faulty design or process, the analysis fee will be exempted. 8 EMX-ALUC User’s Manual...
  • Page 9 9. Position the power cord so that people cannot step on it. Do not place anything over the power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to EMX-ALUC User’s Manual...
  • Page 10 The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. 10 EMX-ALUC User’s Manual...
  • Page 11 A NOTE provides additional information intended to avoid Note inconveniences during operation. Direct current. Alternating current Stand-by, Power on FCC Certification CE Certification Follow the national requirements for disposal of equipment. Stacking layer limit This side up EMX-ALUC User’s Manual 11...
  • Page 12 EMX-ALUC User’s Manual Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. 12 EMX-ALUC User’s Manual...
  • Page 13 EXPLOSION ou une fuite de liquide ou de gaz inflammable. - UNE BATTERIE soumise à une pression d'air extrêmement basse pouvant entraî ner une EXPLOSION ou une fuite de liquide ou de gaz inflammable. EMX-ALUC User’s Manual 13...
  • Page 14 2.3.22 LVDS Backlight Control Wafer (LVDS_P1) ................... 39 2.3.23 SIM card slot (J_SIM1) ........................40 2.3.24 GPIO Wafer (J_GPIO1) ......................... 40 2.3.25 Front Panel Wafer (F_PANEL1) ....................41 2.3.26 Battery connector (J_BAT1) ......................41 2.3.27 DC 12V Power Input Wafer (J_DCIN3) ..................42 14 EMX-ALUC User’s Manual...
  • Page 15 Hardware Monitor ........................65 4.6.2.6.1 Fan Function .......................... 65 4.6.2.7 Display Configuration ......................66 4.6.2.8 Power Control ........................67 4.6.2.9 S5 RTC Wake Settings ......................67 4.6.2.10 USB Configuration ......................... 68 4.6.2.11 Network Stack Configuration ....................69 EMX-ALUC User’s Manual 15...
  • Page 16 Discard Changes ........................86 4.6.6.7 Restore Defaults ........................87 4.6.6.8 Save as User Defaults ......................87 4.6.6.9 Restore User Defaults ......................87 4.6.6.10 Boot override ......................... 87 4.6.7 MEBx .............................. 88 5. Mechanical Drawing ....................89 16 EMX-ALUC User’s Manual...
  • Page 17 Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty EMX-ALUC Motherboard DB9M COM Cable Note: Before using the motherboard power, ensure the power pinout, cables, and voltage match to avoid equipment damage. EMX-ALUC User’s Manual 17...
  • Page 18 We strongly recommend that you study this manual carefully before attempting to set up EMX-ALUC or change the standard configurations. Whilst all the necessary information is available in this manual, we would recommend that unless you are confident, you contact your supplier for guidance.
  • Page 19 1 x M.2 Key-M 2242/2280 (PCIe x4/SATA) slot for storage NVMe/SATA SSD (Auto Detect) PCIe 1 x PCIe Gen4 x4 with PCIe x8 slot Storage 1 x M.2 Key-M 2242/2280 (PCIe x4/SATA) slot for storage NVMe/SATA SSD (Auto Detect) SATA 1 x SATA III (blue color connector) EMX-ALUC User’s Manual 19...
  • Page 20 1 x 2 pin, pitch 1.25mm Wafer horizontal type connector for CR2032(J_BAT1) RTC Battery (-20~60C Battery) Battery 3V/220mAh 85mm CR2032 Lithium Coin Cell. AT/ATX 1 x 3 pin, pitch 2.54mm pin header for AT/ATX jumper (J_AT/ATX1) Default ATX mode 20 EMX-ALUC User’s Manual...
  • Page 21 1 x DP++ 1.4a: Max: 4096 x 2340@60 Hz Resolution LVDS: 1920 x 1200 Dual channel 18/24-bits LVDS (CapStone CS5211 eDP to LVDS) Multiple Triple Independent Display: 1 x HDMI, 1 x DP++, 1 x LVDS EMX-ALUC User’s Manual 21...
  • Page 22 Intel@ standard CPU SKU support: 0~60°C Temp. w/HDD/SSD, ambient with 0.5 m/s Air flow Storage Temp. -20~ +75°C Operating 40°C @ 95% Relative Humidity, Non-condensing Humidity Size (L x W) 6.7" x 6.7" (170mm x 170mm) 22 EMX-ALUC User’s Manual...
  • Page 23 1 One corner , three edges, six faces 2 ISTA 2A, IEC-60068-2-32 Test:Ed Windows 11 Enterprise LTSC 24H2 or later, Linux Kernel 5.17 or later, Windows 10 IoT OS Information Enterprise 2021 LTSC Note: Specifications are subject to change without notice. EMX-ALUC User’s Manual 23...
  • Page 24 EMX-ALUC User’s Manual 1.5 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EMX-ALUC. 24 EMX-ALUC User’s Manual...
  • Page 25 User’s Manual 2. Hardware Configuration EMX-ALUC User’s Manual 25...
  • Page 26 EMX-ALUC User’s Manual 2.1 Product Overview Note: Before using the motherboard power, ensure the power pinout, cables, and voltage match to avoid equipment damage. 26 EMX-ALUC User’s Manual...
  • Page 27 3 x 1 header, pitch 2.54mm COM5 RS232/RS485 Select JP1/2 3 x 2 header, pitch 2.54mm Jumper 1/2 COM6 RS232/RS485 Select JP3/4 3 x 2 header, pitch 2.54mm Jumper 3/4 Connectors Label Function Note Line-out & Mic-in audio jack EMX-ALUC User’s Manual 27...
  • Page 28 6 x 1 wafer, pitch 1.25mm J_GPIO1 GPIO Wafer 5 x 2 wafer, pitch 2.00mm F_PANEL1 Front Panel Wafer 4 x 2 wafer, pitch 2.00mm J_BAT1 Battery connector 2 x 1 wafer, pitch 1.25mm PCIE_8X_SLOT1 PCI-E 8x Slot (PCIE x4 Signal) 28 EMX-ALUC User’s Manual...
  • Page 29 User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 Clear CMOS (CLR_CMOS1) Normal* Clear CMOS * Default 2.3.2 LVDS VDD Select Jumper (JC_LVDS1) +3.3V* +12V * Default EMX-ALUC User’s Manual 29...
  • Page 30 EMX-ALUC User’s Manual 2.3.3 LVDS Backlight PWM/CCFL Select Jumper (JC_LVDS2) PWM* CCFL * Default 2.3.4 AT/ATX Power Mode Select (J_AT/ATX1) ATX* * Default 30 EMX-ALUC User’s Manual...
  • Page 31 User’s Manual 2.3.5 COM5 RS232/RS485 Select Jumper 1/2 (JP1/JP2) RS232* RS485 * Default 2.3.6 COM6 RS232/RS485 Select Jumper 3/4 (JP3/JP4) RS232* RS485 * Default EMX-ALUC User’s Manual 31...
  • Page 32 EMX-ALUC User’s Manual 2.3.7 Power Debug Wafer (J_PRM1) Signal IMVP_PE VCCIN_SCL VCCIN_SDA 2.3.8 SYS fan connector (SYS_FAN1) Signal VCC12S SIO_FANTAC2 SIO_FANCTL2 32 EMX-ALUC User’s Manual...
  • Page 33 User’s Manual 2.3.9 CPU fan connector (CPU_FAN1) Signal VCC12S SIO_FANTAC1 SIO_FANCTL1 2.3.10 Serial port 1 connector (J_COM1) Signal RS232_PIN RS232 Signal EMX-ALUC User’s Manual 33...
  • Page 34 EMX-ALUC User’s Manual 2.3.11 Serial port 2 connector (J_COM2) Signal RS232_PIN RS232 Signal 2.3.12 Serial port 3 connector (J_COM3) Signal RS232_PIN RS232 Signal 34 EMX-ALUC User’s Manual...
  • Page 35 User’s Manual 2.3.13 Serial port 4 connector (J_COM4) Signal RS232_PIN RS232 Signal 2.3.14 Serial port 5 connector (J_COM5) RS232 Signal RS485 Signal RS485- RS485+ EMX-ALUC User’s Manual 35...
  • Page 36 EMX-ALUC User’s Manual 2.3.15 Serial port 6 connector (J_COM6) RS232 Signal RS485 Signal RS485- RS485+ 2.3.16 Amplifier Wafer (J_SPK1) Signal SPK_OUT_R+ SPK_OUT_R- SPK_OUT_L+ SPK_OUT_L- 36 EMX-ALUC User’s Manual...
  • Page 37 Signal PIN PIN Signal USB2_P8_R USB2_P7_R USB2_N8_R USB2_N7_R +5VSB +5VSB 2.3.18 SATA Power connector (P_SATA1) Signal VCC12S VCC5S Note: Before using the motherboard power, ensure the power pinout, cables, and voltage match to avoid equipment damage. EMX-ALUC User’s Manual 37...
  • Page 38 ESPI_RST0_N ESPI_ALERT0_N VCC3P3S ESPI_CS0_N ESPI_IO3_SIO ESPI_CLK_SIO ESPI_IO2_SIO ESPI_IO1_SIO VCC3P3A ESPI_IO0_SIO 2.3.20 DC 12V+5V Power Output Wafer (DC_OUT1) Signal VCC5 VCC12 Note: The maximum supply current for DC_OUT1 pin 1 and pin 4 is 5A per pin. 38 EMX-ALUC User’s Manual...
  • Page 39 LVDS_DB_N1 LVDS_DB_P1 LVDS_DB_N2 LVDS_DB_P2 LVDS_CLKB_N LVDS_CLKB_P LVDS_DB_N3 LVDS_DB_P3 2.3.22 LVDS Backlight Control Wafer (LVDS_P1) Signal VCC12S VCC12S LVDS _BKLT_EN LVDS_BKLTCTL Note: The maximum supply current for LVDS_P1 pin 5 and pin 6 is 2A per pin. EMX-ALUC User’s Manual 39...
  • Page 40 UIM1_PWR: Module power supply, dependent on the specific 4G module UIM1_VPP: Module power supply, dependent on the specific 4G module.. 2.3.24 GPIO Wafer (J_GPIO1) Signal PIN PIN Signal SIO_GPO76 SIO_GPI77 SIO_GPO74 SIO_GPI75 SIO_GPO73 SIO_GPI72 SIO_GPO71 SIO_GPI70 40 EMX-ALUC User’s Manual...
  • Page 41 User’s Manual 2.3.25 Front Panel Wafer (F_PANEL1) Description Signal PIN PIN Signal Description Power PWR- RESET+ Reset button button PWR+ RESET- PWR LED- HDD_LED- PWR LED HDD LED PWR LED+ HDD_LED+ 2.3.26 Battery connector (J_BAT1) Signal VCC_BAT EMX-ALUC User’s Manual 41...
  • Page 42 EMX-ALUC User’s Manual 2.3.27 DC 12V Power Input Wafer (J_DCIN3) Signal VCC_IN VCC_IN 42 EMX-ALUC User’s Manual...
  • Page 43 Enter to find all the relevant software, utilities, and documentation. (For reference only) Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EMX-ALUC User’s Manual 43...
  • Page 44 Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 3. Click Install. Step 4. Click Finish to complete setup. Step1. Click Next. Step 2. Click Accept. 44 EMX-ALUC User’s Manual...
  • Page 45 Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 3. Click Accept. Step 4. Click Finish to complete setup. Step 1. Click Begin installation. Step 2. Click I agree. EMX-ALUC User’s Manual 45...
  • Page 46 Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Finish to complete setup. Step 2. Click Next. 46 EMX-ALUC User’s Manual...
  • Page 47 All drivers can be found on the Avalue Official Website: www.avalue.com. Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 1. Click Next. Step 2. Click Finish to complete setup. EMX-ALUC User’s Manual 47...
  • Page 48 Windows 11 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. 48 EMX-ALUC User’s Manual...
  • Page 49 All drivers can be found on the Avalue Official Website: www.avalue.com. Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 1. Click OK. Step 2. Setup completed. EMX-ALUC User’s Manual 49...
  • Page 50 Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 3. Click Next. Step 1. Click High Definition Audio Step 4. Setup completed. Controller. Step 2. Click Browes my computer for drivers. 50 EMX-ALUC User’s Manual...
  • Page 51 User’s Manual 4.BIOS Setup EMX-ALUC User’s Manual 51...
  • Page 52 If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. 52 EMX-ALUC User’s Manual...
  • Page 53 Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “➢” pointer marks all sub menus. EMX-ALUC User’s Manual 53...
  • Page 54 BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 54 EMX-ALUC User’s Manual...
  • Page 55 Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com) to download the latest product and BIOS information. EMX-ALUC User’s Manual 55...
  • Page 56 Options Description Enabled[Default], Enable/Disable processor Turbo Mode (requires Turbo Mode Disabled EMTTM enabled too). AUTO means enabled. Intel (VMX) Virtualization Disabled When enabled, a VMM can utilize the additional Technology Enabled[Default] hardware capabilities provided by Vanderpool 56 EMX-ALUC User’s Manual...
  • Page 57 Eanble/Disable Intel® Speed Shift Technology Enabled[Default], Intel® Speed Shift Technology support. Enabling will expose the CPPC v2 Disabled interface to allow for hardware controlled P-states. Disabled, Hyper-Threading Enable or Disable Hyper-Threading Technology. Enabled[Default] 4.6.2.1.1 Efficient-core Information 4.6.2.1.2 Performance-core Information EMX-ALUC User’s Manual 57...
  • Page 58 0= no custom override. For 12.50w, enter 12500. Overclocking SKU: Power Limit 1/2 Value must be between Max and Min Power Limits (specified by PACKAGE_POWER_SKU_MSR). Other SKUs: This value must be between Min Power Limit and Processor Base Power 58 EMX-ALUC User’s Manual...
  • Page 59 Custom value for Turbo Activation Ration. ConfigTDP Turbo Activation Needs to be configured with valid values Ratio from LFM to Max Turbo. 0 means don’t use custom value. 4.6.2.2 PCH-FW Configuration 4.6.2.3 Trusted Computing EMX-ALUC User’s Manual 59...
  • Page 60 Hibernate (OS/S4 Sleep State). This option Enabled[Default], may not be effective with some OS. Select the highest ACPI sleep state the Suspend Disabled, ACPI Sleep State system will enter when the SUSPEND button S3 (Suspend to RAM)[Default] is pressed. 60 EMX-ALUC User’s Manual...
  • Page 61 Set Parameters of Serial Port 3 (COM3). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COM4). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COM5). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COM6). EMX-ALUC User’s Manual 61...
  • Page 62 4.6.2.5.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 4.6.2.5.2 Serial Port 2 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 62 EMX-ALUC User’s Manual...
  • Page 63 4.6.2.5.3 Serial Port 3 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 4.6.2.5.4 Serial Port 4 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled EMX-ALUC User’s Manual 63...
  • Page 64 4.6.2.5.5 Serial Port 5 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 4.6.2.5.6 Serial Port 6 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 64 EMX-ALUC User’s Manual...
  • Page 65 User’s Manual 4.6.2.6 Hardware Monitor 4.6.2.6.1 Fan Function Item Option Description Full on Mode[Default], CPU_FAN1 Mode Automatic Mode CPU_FAN1 Mode Select. Manual Mode Full on Mode[Default], SYS_FAN1 Mode Automatic Mode SYS_FAN1 Mode Select. Manual Mode EMX-ALUC User’s Manual 65...
  • Page 66 1366x768 18 Single 1280x1024 24 Dual LCD Panel Type Select LCD Panel Type. 1280x1024 18 Dual 1024x768 24 Single[Default] 1920x1080 24 Dual 1024x600 24 Single 1024x600 18 Single 800x600 24 Single 800x600 18 Single 800x480 18 Single 66 EMX-ALUC User’s Manual...
  • Page 67 Delay 4 Sec. 4.6.2.9 S5 RTC Wake Settings Item Options Description Disabled[Default], Enable or disable System wake on alarm event. Select Wake system from S5 Fixed Time Fixed Time, system will wake on the hr::min::sec specified. EMX-ALUC User’s Manual 67...
  • Page 68 Maximum time the device will take before it Auto[Default] properly reports itself to the Host Controller. Device power-up delay ‘Auto’ uses default value: for a Root port it is Manual 100ms, for a Hub port the delay is taken form 68 EMX-ALUC User’s Manual...
  • Page 69 Optical drives are emulated as ‘CDROM’, drives with no media will be Hard Disk CD-ROM emulated according to a drive type. 4.6.2.11 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 4.6.2.12 NVMe Configuration EMX-ALUC User’s Manual 69...
  • Page 70 EMX-ALUC User’s Manual 4.6.2.13 Intel® I210 Gigabit Network Connection 4.6.2.13.1 Firmware Image Properties 70 EMX-ALUC User’s Manual...
  • Page 71 User’s Manual 4.6.2.13.2 NIC Configuration 4.6.2.13.3 iSCSI Configuration EMX-ALUC User’s Manual 71...
  • Page 72 EMX-ALUC User’s Manual 4.6.2.13.3.1 iSCSI General Parameters 4.6.2.13.3.2 iSCSI Initiator Parameters 72 EMX-ALUC User’s Manual...
  • Page 73 User’s Manual 4.6.2.13.3.3 iSCSI First Target Parameters 4.6.2.13.4 Device Level Configuration EMX-ALUC User’s Manual 73...
  • Page 74 EMX-ALUC User’s Manual 4.6.2.14 Intel® Ethernet Connection (16) I219-LM 4.6.3 Chipset 74 EMX-ALUC User’s Manual...
  • Page 75 User’s Manual 4.6.3.1 System Agent (SA) Configuration 4.6.3.1.1 Memory Configuration EMX-ALUC User’s Manual 75...
  • Page 76 Internal Graphics Disabled Keep IGFX enabled based on the setup options. Enabled Enable/Disable above 4GB MemoryMappedIO Above 4GB MMIO BIOS Enabled[Default] BIOS assignment. This is enabled automatically assignment Disabled when Aperture Size is set to 2048MB. 76 EMX-ALUC User’s Manual...
  • Page 77 User’s Manual 4.6.3.1.3 VMD setup menu Item Option Description Disabled[Default] Enable VMD controller Enable/Disable to VMD controller. Enabled 4.6.3.1.4 PCI Express Configuration EMX-ALUC User’s Manual 77...
  • Page 78 EMX-ALUC User’s Manual 4.6.3.1.4.1 PCI Express Root Port 1 Item Option Description Disabled PCIEX8_SLOT1 Control the PCI Express Root Port. Enabled[Default], Auto[Default] Gen1 Gen2 PCIe Speed Configure PCIe Speed. Gen3 Gen4 Gen5 4.6.3.1.4.2 PCI Express Root Port 3 78 EMX-ALUC User’s Manual...
  • Page 79 Disabled Auto[Default] Gen1 Gen2 PCIe Speed Configure PCIe Speed. Gen3 Gen4 Gen5 4.6.3.2 PCH-IO Configuration Item Option Description Enabled Indicates what type of I2C Touch Panel is I2C Touch Panel Disabled[Default], connected to this SerialIO controller. EMX-ALUC User’s Manual 79...
  • Page 80 EMX-ALUC User’s Manual 4.6.3.2.1 PCI Express Configuration 4.6.3.2.1.1 M.2_KEYE_WLAN1 Item Option Description Enabled[Default], M.2_KEYE_WLAN1 Control the PCI Express Root Port. Disabled Auto[Default] Gen1 PCIe Speed Configure PCIe Speed. Gen2 Gen3 80 EMX-ALUC User’s Manual...
  • Page 81 User’s Manual 4.6.3.2.1.2 LAN2 Item Option Description Enabled[Default], LAN2 Control the PCI Express Root Port. Disabled Auto[Default] Gen1 PCIe Speed Configure PCIe Speed. Gen2 Gen3 4.6.3.2.2 SATA Configuration EMX-ALUC User’s Manual 81...
  • Page 82 Enable/Disable SATA Device. Disabled, SATA Mode Selection AHCI[Default] Determines how SATA controller(s) operate. Enabled[Default] Port 1 Enable or Disable SATA Port. Disabled 4.6.4 Security ⚫ Administrator Password Set setup Administrator Password ⚫ User Password Set User Password 82 EMX-ALUC User’s Manual...
  • Page 83 User’s Manual 4.6.4.1 Security Boot EMX-ALUC User’s Manual 83...
  • Page 84 EMX-ALUC User’s Manual 4.6.4.1.1 Key Management 4.6.5 Boot 84 EMX-ALUC User’s Manual...
  • Page 85 User’s Manual Item Option Description Boot Option #1/2/3/4/5/6/7 Set the system boot order. 4.6.6 Save and Exit EMX-ALUC User’s Manual 85...
  • Page 86 Changes made to BIOS settings during this session are committed to NVRAM. The setup program remains active, allowing further changes. 4.6.6.6 Discard Changes Any changes made to BIOS settings during this session of the BIOS setup program are 86 EMX-ALUC User’s Manual...
  • Page 87 If BIOS setup options have been changed and saved, a reboot will be required and the boot override selection will not be valid. EMX-ALUC User’s Manual 87...
  • Page 88 EMX-ALUC User’s Manual 4.6.7 MEBx 88 EMX-ALUC User’s Manual...
  • Page 89 User’s Manual 5. Mechanical Drawing EMX-ALUC User’s Manual 89...
  • Page 90 EMX-ALUC User’s Manual Unit: mm 90 EMX-ALUC User’s Manual...
