Avalue Technology EMX-945GSE Series User Manual

Intel 945gse supports intel fcbga8 45nm atom n270 processor mini itx main board
Hide thumbs
Table of Contents

Advertisement

Quick Links

EMX-945GSE Series
Intel® 945GSE Supports Intel® FCBGA8 45nm Atom™ N270
Processor Mini ITX Main Board
User's Manual
nd
Ed – 31 August 2011
2
