Easy Stick-20CC
Instruction Manual
Specifications
Wingspan: 72.5 in (1840mm)
Length: 63 in (1600mm)
Wing Area: 940.8 sq in (60.7sq dm)
Flying Weight: 8.8-9.5lb (4000-4300g)
*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Easy Stick-20CC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Value Hobby Easy Stick-20CC

Summary of Contents for Value Hobby Easy Stick-20CC

  • Page 1 Easy Stick-20CC Instruction Manual Specifications Wingspan: 72.5 in (1840mm) Length: 63 in (1600mm) Wing Area: 940.8 sq in (60.7sq dm) Flying Weight: 8.8-9.5lb (4000-4300g)

  • Page 2: Dear Customer

    In no way shall Value Hobby’s liability exceed the original cost of the purchased model. Further, Value Hobby reserves the right to modify this warranty without notice. Value Hobby has no control over the final stages of assembly or the material used for the final assembly. No liability shall be assumed nor materials used for the final user-assembled product.

  • Page 3: Safety In Flying

    Before Starting Assembly Examination Unpack your airplane and examine the components. Check for damage of any kind. If you see any damage, please contact Value Hobby immediately. Covering Your airplane was packed in plastic at the factory without any wrinkles in the covering. You may notice some wrinkles now; more likely, you will notice a few in a day or two or the first time you take the plane out to the flying field.
  • Page 4 SUGGESTED SETUP (NOT INCLUDED) Quantity Product GForce G60 Outrunner Motor (5065-400KV) VHB-MT-5454 or DLE-20RA or similar gas engines DLE-EN-6058 Hobbywing 80A ESC HWG-SC-4446 Power HD 1501MG PHD-SV-0370 5000mAh 6S LiPO RFI-LP-1494 15 x 8 or 16 x 8 Prop OTHER ACCESSORIES (NOT INCLUDED) Quantity Product 5-Pack 18in Servo Extension...
  • Page 5 Parts of the Airplane...

  • Page 6: Wing Installation

    Step 2 Step 4 Wing Installation Join the hinges with the aileron. Then secure Install your standard servo into the wing with them with CA glue. servo screws. Required Parts: Step 5 Install the metal control horn onto the wing with Step 1 Step 3 three M2x16 screws.
  • Page 7 Step 6 Step 8 Join aileron push rod with the servo arm. Then Apply the epoxy to the wing joiner strip and the connect aileron push rod to the control horn. joint areas of the wing (Side A, B and C). Step 7 Step 9 Secure wing dowel into the pre-cut hole of the...
  • Page 8 Step 2 Fuselage Installation Apply the epoxy to the fuselage joiner strip and the joint areas of the fuselage. Required Parts: Step 1 Step 3 Insert four fuselage joiner rods into the pre-cut After applying the glue, put the joined fuselage on hole of fuselage rear part.

  • Page 9: Horizontal Stabilizer Installation

    Step 4 Step 5 Horizontal Stabilizer Installation Check the alignment of the stabilizer to the wing. Use a felt-tipped pen to trace the outline of the Position the stabilizer so the measurements from fuselage on the stabilizer. Use a hobby knife Required Parts the stabilizer tips to the wing tips are equal.

  • Page 10: Vertical Fin Installation

    Step 1 Step 2 Vertical Fin Installation Insert the fin in the slot at the rear of the fuselage. Use a hobby knife and #11 blade to remove Use a felt-tipped pen to trace the outline of the the covering from the fuselage and fin. Trim the Required Parts fuselage on the area of the fin that fits into the covering 1/16-inch (1.5mm) inside the lines...
  • Page 11 Step 1 Step 2 Preparation for Tail Landing Gear Mark where it is 15mm from the tip of the rudder Use a hobby knife and #11 blade to cut a Installation and use 1.8mm drill bit to drill a hole 10mm deep. groove from the hole in the rudder to the bottom of the rudder for the tail gear wire to fit Required Parts...
  • Page 12 Step 3 Step 4 Step 5 Bend the rod 90 degrees as shown. Insert the tail gear wire into the rudder. It should Fit the rudder to the fin. Use a hobby knife and fit as shown. Use 30-minute epoxy to glue the #11 blade to check the hinge gap and that the wire into the fin.
  • Page 13 Step 6 Step 7 Step 8 Use thin CA to glue the two hinges that secure Position the elevator against the stabilizer. Use a Insert a T-pin in the center of the six stabilizer the rudder and fin. Perform a pull test on the felt-tipped pen to mark where the tail wheel wire hinges.
  • Page 14 Step 9 Step 10 Step11 Install the elevator against the stabilizer using Flex the elevator up and down a number of times Secure the tail landing gear to the horizontal the hinges. Set the hinge gap using a hobby to break in the hinges. stabilizer and install the wheel to the landing knife and #11 blade.

  • Page 15: Radio Installation

    Step 1 Step 3 Radio Installation Install the rudder and elevator servos the same Install ball head holders into the rudder push rod way we did in aileron servos. and elevator push rod Required Parts Step 2 . Remove the covering from the fuselage for inboard rudder and elevator servo.

  • Page 16: Landing Gear Installation

    Step 1 Step 2 Landing Gear Installation Secure the axle to the landing gear using pliers Slide a wheel collar on the axle, and tighten the and hex wrench. wheel collar using a grub screw. Required Parts...
  • Page 17 Step 3 Step 4 Step 5 Slide the wheel on the axle and use the other Remove the covering for the main landing gear Secure the assembled landing gear to the wheel collar to secure the wheel to the axle. mount.
  • Page 18 Step 1 Step 2 Nitro Engine Installation Attach the engine mount rails to the firewall using Secure the engine to the mount rails.(2 stroke four M3*20socket head screws and four M3 engine is shown as an example) Required Parts washers. Leave them slightly loose so the mount rails can be moved to fit your particular engine.
  • Page 19 Step 3 Install the propeller and spinner following the instructions provided with the engine. Never use an adjustable wrench to install the propeller nut as it will eventually round the corners of the nut, making it difficult to tighten or loosen in the future.
  • Page 20 Electric Motor Installation Step3. Use four M4*20mm (0.8in) socket head screws, four M4 locknuts and four M4 washers to Step2. Use four M4*20mm (0.8in) socket head screws Step 1 and four M4 washers to install the motor mount to install the motor to the firewall. Remove the covering for battery hatch.
  • Page 21 Step1. Before fly, be sure to range check your radio as manufacturer’s instruction manual of your radio-system recommends. Step2. Double-check all controls (aileron, elevator, rudder and throttle) move in the correct direction. Step3. Be sure that your LiPO battery is fully charged. Finally... Enjoy Your Easy Stick-20CC Have a nice flight!
