Summary of Contents for BDI LUMA 6762
- Page 1 LUMA 6762 ™ DESK | LIFT DESK USER MANUAL LET’S GET STARTED. DESIGN BDI DESIGN STUDIO...
- Page 3 Congratulations on the purchase of your Luma desk from BDI. Your desk has been designed to provide a lifetime of enjoyment. This manual will provide assembly instructions and other helpful information to ensure you get the most out of your product.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface, such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI retailer.
- Page 5 HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS Control Module (C8) QTY: 1 KLEET (C6) QTY: 4 Hook & Loop Tie (C7) QTY: 2 LIFT DESK ONLY Power Strip (C9) Paddle Mounting Plate (C10) Digital Control Paddle (C11) QTY: 1 QTY: 1 QTY: 1 LIFT DESK ONLY LIFT DESK ONLY...
- Page 6 Legs (C1). Attach them using 16 Screws (H1) and tighten with T1. „ Slide the 2 Short Frame Tubes (C3) onto the Legs (C1). „ Attach them using 8 Screws (H1) and tighten with T1. „ 6 | BDIUSA.COM LUMA 6762...
- Page 7 2 PERSON TASK STEP 2. ATTACH SHORT TUBES TO FORM DESK FRAME ASSEMBLY With help from another person, stand both sides of the Frame upright. HEX WRENCH – T1 Slide the Short Frame Tubes (C3) onto the „ Legs (C1). SCREW –...
- Page 8 Control Paddle (in a later step). Note: If you have purchased the Luma Drawer (not included), now would be a good time to refer to those instructions and begin the installation process. Control Module Orientation Reference 8 | BDIUSA.COM LUMA 6762...
- Page 9 STEP 3. ORIENTATION OF OPTIONAL INSTALL LOCATIONS ASSEMBLY Front of Frame Front of Top Panel Drawer (Left, Right, or Center Positions) KLEET (C6) KLEET (C6) CONTROL MODULE (C8) KLEET (C6) KLEET (C6) POWER STRIP POWER STRIP (C9) (C9) NEED ASSISTANCE? customerservice@bdiusa.com | 9...
- Page 10 2 PERSON TASK ASSEMBLY STEP 4. PLACE TOP PANEL ONTO FRAME With help from another person, Lift the Top Panel up, flip it over, and gently place it on the Frame. 10 | BDIUSA.COM LUMA 6762...
- Page 11 STEP 5. LIFT DESK ONLY: ATTACH CONTROL PADDLE ASSEMBLY LIFT DESK ONLY: Attach the Paddle Mounting Plate (C10) to „ HEX WRENCH – T1 the Frame based on how you oriented the Control Module (C8) in Step 3. SCREW – H3 Use 2 Flathead Screws (H3) and tighten „...
- Page 12 „ Use Kleets (C6) and the included Hook and Loop Ties (C7) to secure loose cords. „ Route Leg Extension Cods (C4) along wider outer groove Route Control Paddle Cord (C11) along narrow inner groove 12 | BDIUSA.COM LUMA 6762...
-
Page 13: Fine Tuning
FINE TUNING ADJUST LEVELERS Levelers are integrated into the bottom of each leg. If your floor is uneven, you may extend one or more levelers to attain a level, stable position. Dial down FINE TUNING ATTACH A MONITOR ARM The Luma Desk is compatible with most third-party monitor arms. Attach your monitor arm anywhere along the frame of the desk, ensuring the mount’s clamp is resting on the flat frame tubes, and not the curved surface of the legs. -
Page 14: Safety Information
10–15 seconds. 3. Press and hold the paddle DOWN once again until the desk lowers a little more, slightly rises, then stops. Release paddle. Your desk is now ready to use! 14 | BDIUSA.COM LUMA 6762... -
Page 15: Adjusting The Height
USING YOUR DIGITAL CONTROL PADDLE (CONTINUED) ADJUSTING THE HEIGHT Manually adjust the height by pressing or raising the control paddle until you achieve the desired height. Menu Button PROGRAMMING DESK HEIGHT PRESETS 1. To program your favorite seated and standing position, start by using the paddle to position the desktop to the desired height. -
Page 16: Advanced User Settings
MAX Saves current desktop height as the maximum that the desk will not go above OFF Removes any programmed minimum or maximum positions Returns you to the main menu 5. Press the Menu Button again to program your selection. 16 | BDIUSA.COM LUMA 6762... - Page 17 USING YOUR DIGITAL CONTROL PADDLE (CONTINUED) CHANGING YOUR DISPLAY FROM INCHES TO CENTIMETERS If you would prefer to see your display in metric dimensions, you can change this setting while your desk is in Reset Mode. 1. Press the paddle DOWN until the desk is in its lowest position. Release the paddle. 2 Press and hold the paddle DOWN again until the display reads RESET.
-
Page 18: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please avoid positioning your BDI cabinet in any area with ample direct sunlight. -
Page 19: Warranty
Select chairs carry coverage for five (5) years from the date of the product delivery, based on an 8-hour daily use pattern. BDI reserves the right to refine or update its warranty from time to time. See the complete and latest warranty document at www.bdiusa.com/warranty. - Page 20 These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Luma & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2025, BDI | V.04.07.2025 Made in Vietnam.
