- Page 1 LUMA 6720 ™ MULTIFUNCTION CABINET USER MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Luma cabinet from BDI. Your cabinet has been designed to provide a lifetime of enjoyment. This manual will provide assembly instructions and other helpful information to ensure you get the most out of your product.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface, such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI retailer.
- Page 5 HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS Glass Top (C2) QTY: 1 Glass Shelf (C3) QTY: 1 Removable Back Panel (C4) QTY: 1 Drawer Tray (C6) QTY: 1 File Bar (C8) QTY: 2 File Clip (C9) QTY: 4 Wall Anchor Strap (C10) QTY: 1 HARDWARE REQUIRED HARDWARE REQUIRED...
- Page 6 STEP 1. INSTALL RUBBER BUMPERS Peel the backing off the adhesive backed Rubber Bumpers (H2) and stick them to the top RUBBER BUMPER – H2 of the Cabinet (C1). Use the bumper locations drawing provided. 6 | BDIUSA.COM LUMA 6720...
- Page 7 STEP 2. INSTALL GLASS TOP ASSEMBLY Place Glass Top (C2) on top of the Rubber Bumpers. NOTE: Edges of the glass should be flush with the edges of the cabinet. STEP 3. INSTALL GLASS SHELF ASSEMBLY Set the Shelf Pins (H1) to the desired hieght of the shelf.
- Page 8 Install the Removable Back Panel (C4) by positioning the panel under the grooves on the underside of the cabinet top panel. Lift the Removable Back Panel (C4) up and position the bottom of the panel above the grooves in the cabinet bottom panel then drop the panel in place. 8 | BDIUSA.COM LUMA 6720...
- Page 9 ANCHOR CABINET TO WALL RECOMMEDATION It is strongly recommended that you anchor your Luma Cabinet to the wall using the HEX WRENCH – H1 provided Anchor Strap (C10). Measure 23" (584mm) up from the floor and NOT INCLUDED 10.5" (267mm) from the outer edge of the PHILLIPS SCREWDRIVER cabinet and mark the wall as shown.
-
Page 10: Fine Tuning
If your cabinet is on carpeting, check your front to back level after loading the cabinet and opening the heaviest drawers. This will ensure the cabinet remains level during operation and prevents the risk of tip-over. 10 | BDIUSA.COM LUMA 6720... -
Page 11: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please avoid positioning your BDI cabinet in any area with ample direct sunlight. -
Page 12: Warranty
Select chairs carry coverage for five (5) years from the date of the product delivery, based on an 8-hour daily use pattern. BDI reserves the right to refine or update its warranty from time to time. See the complete and latest warranty document at www.bdiusa.com/warranty.
