- Page 1 LINEA 6223 ™ WORK DESK INSTRUCTION MANUAL DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Linea Work Desk 6223 from BDI. Your desk has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your product.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for the assembly of this product.
- Page 5 HARDWARE AND COMPONENTS PART # PART # Wire Management DESCRIPTION DESCRIPTION Wire Trough Extrusion QUANTITY QUANTITY (4) Neodymium Magnets PART # DESCRIPTION Power Strip Mounting Kit QUANTITY NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
- Page 6 Assembly using 4 (H1) Screws. Partially tighten with (T1) Hex Wrench. The (C4) Wire Trough is reversible and can be installed facing toward the T1-HEX WRENCH front or back of the desk as needed. H1-SCREW 6 | BDIUSA.COM LINEA 6223...
- Page 7 STEP 2. ATTACH LEG FRAMES ASSEMBLY Connect (C2) Left Leg Frame to (C4) Wire PART/DESCRIPTION Trough using 2 (H1) Screws. Fasten to (C1) Top Panel Connection Tab using 1 (H1) Screw. Partially tighten screws. T1-HEX WRENCH Connect (C3) Right Leg Frame to (C4) Wire Trough using 2 (H1) Screws.
- Page 8 ASSEMBLY STEP 3. FASTEN LEG FRAMES Fasten (C2) and (C3) Leg Frames to (C1) Top PART/DESCRIPTION Panel using (H2) Screws. Tighten all screws connecting Legs and Wire Trough. T1-HEX WRENCH H2-SCREW 8 | BDIUSA.COM LINEA 6223...
- Page 9 2 PERSON TASK STEP 4. INSTALL WIRE MANAGEMENT EXTRUSION ASSEMBLY —OPTIONAL With help from another person, carefully position your Linea Work Desk onto its base. Once the desk is upright, install the (C5) Wire Management Extrusion on the leg of your choice. NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 9...
-
Page 10: Fine Tuning
POWER STRIP MOUNTING KIT (Power strip not included) (4) Neodymium Magnets Your Linea Work Desk is equipped with built-in levelers. Dial down one or more levelers (by hand) until you attain a level stance. Dial down 10 | BDIUSA.COM LINEA 6223... -
Page 11: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 12: Warranty
WARRANTY BDI warrants to the original purchaser that for the below-stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty that fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component.
