LINQ
9117, 9119, 9127, 9129
BED
INSTRUCTION MANUAL
LET'S GET STARTED.
DESIGNED BY MATTHEW WEATHERLY

Advertisement

loading
Need help?

Need help?

Do you have a question about the LINQ 9117 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BDI LINQ 9117

  • Page 1 LINQ 9117, 9119, 9127, 9129 ™ INSTRUCTION MANUAL LET’S GET STARTED. DESIGNED BY MATTHEW WEATHERLY...
  • Page 3 Congratulations on the purchase of your LINQ Bed from BDI. Your bed has been designed to provide a lifetime of enjoyment. This manual will provide assembly instructions and other helpful information to ensure you get the most out of your product.
  • Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface, such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI retailer.
  • Page 5 HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS Headboard Corner Bracket (C5) QTY: 2 Side Support Bracket (C7) QTY: 2 Footboard Corner Bracket (C6) QTY: 2 Leg / Rail Connector (C8) QTY: 2 Long Leg (C9) QTY: 3 Short Leg (C10) QTY: 4 Headboard Cleat (C11) QTY: 1 Center Support (C12)
  • Page 6 HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS 9127 Cross-LINQ shown Headboard (C13) QTY: 1 9119 Up-LINQ shown Headboard (C13) QTY: 1 Bed Slats (C14) QTY: 2 6 | BDIUSA.COM LINQ BEDS...
  • Page 7 LINQ BED SET-UP CONFIGURATIONS LINQ’s adjustable platform and frame allow the bed to accommodate a variety of mattresses, positioning the top of the mattress at the user’s preferred height. The bed can accommodate mattresses from 8"-16", with the recommended height for the top of the mattress being around 24"...
  • Page 8 ASSEMBLY STEP 1. INSTALL CAM LOCKS, CAM STUDS, AND DOWELS Lay the Side Rails (C1 & C2) and the Footboard and Headboard Rails (C3 & C4) on a soft, non- CAM LOCK – H1 marring surface, like carpet. Insert 8 Dowels (H3) and 4 Cam Studs (H2) into the holes on the ends of the Rails, as shown.
  • Page 9 STEP 2. CONNECT RAILS ASSEMBLY Connect the Side Rails (C1 and C2) to the Headboard Rail (C4). Tighten each Cam Lock HEX WRENCH – T2 (H1) with a 6mm Hex Wrench (T2). Connect the Footboard Rail (C3) to the ends of the Side Rails.
  • Page 10 ASSEMBLY STEP 3. ATTACH CORNER BRACKETS Attach the Headboard Corner Brackets (C5) to the corners near the Headboard Rail (C4) using HEX WRENCH – T1 8 Screws (H4). Tighten with Hex Wrench (T1). Attach the Footboard Corner Brackets (C6) to the corners near the Footboard Rail (C3) using SCREW–...
  • Page 11 STEP 4. CONNECT SIDE SUPPORT BRACKETS ASSEMBLY Connect the 2 Side Support Brackets (C7) to the Side Rails according to desired platform position. HEX WRENCH – T1 For a HIGH PLATFORM: mount the rails to the upper threaded inserts with the flat side facing up. SCREW–...
  • Page 12 ASSEMBLY STEP 5. PRE-THREAD SCREWS INTO RAILS Pre-thread 12 Screws (H4) into the threaded inserts as shown. Leave the screw head sticking SCREW– H4 out about 1/4" (6mm). For a HIGH FRAME position: use the upper set of threaded inserts for screw sets 1 and 2. For a LOW FRAME position: use the lower set of threaded inserts for screw sets 1 and 2.
  • Page 13 STEP 6. ATTACH LEG/RAIL CONNECTOR AND LEGS ASSEMBLY Thread the leg sections onto the Leg/Rail Connector (C8). HEX WRENCH – T1 For a HIGH FRAME position : first thread a Short Leg (C10) onto the end of the Long Leg LEVELER –...
  • Page 14 FRAME position, use the lower set of inserts. High Frame Low Frame BDI KLEETS Now is a great time to plug your headboard’s integrated power sources into the nearest available outlet. The BDI KLEETS can be used to wrap excess wires. 14 | BDIUSA.COM LINQ BEDS...
  • Page 15 STEP 8. CONNECT BED FRAME TO HEADBOARD ASSEMBLY Carefully lift the bed frame and pull it close to the Headboard (C13), then lower the Frame onto the Headboard Cleat (C11). Fasten the bedframe to the Headboard (C13) using 4 Screws (H5). Insert them into the HEX WRENCH –...
  • Page 16 ASSEMBLY STEP 9. INSTALL CENTER RAIL & LEGS Thread the appropriate leg sections onto the Center Support (C12), using the Long Leg (C9), HEX WRENCH – T1 and 2 Short Legs (C10), as needed. Complete the leg with a Leveler (H6) at the bottom. SCREW–...
  • Page 17 STEP 10. INSTALL SLATS ASSEMBLY Starting at the Headboard (C13), unroll the Bed Slats (C14) and place them on the platform with the Velcro facing down. Press to secure in place. NEED ASSISTANCE? customerservice@bdiusa.com | 17...
  • Page 18: Fine Tuning

    FINE TUNING FINAL ADJUSTMENTS Before adding your mattress, check that your headboard is level and adjust the floor levelers as needed. Both your bed’s frame and the headboard include floor levelers. Check your bed’s legs for even contact with the floor and adjust floor levelers as needed. Extend them securely against the wall to provide additional support for your bed.
  • Page 19: Care And Maintenance

    While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please avoid positioning your BDI cabinet in any area with ample direct sunlight.
  • Page 20: Warranty

    The decision to repair or replace will be at BDI’s sole discretion. BDI furniture is warranted for three (3) years from the date of purchase, as shown on your sales receipt. The warranty period starts from the date of purchase. This warranty extends only to the original purchasers who acquire new products from BDI Authorized Resellers.

This manual is also suitable for:

Linq 9119Linq 9127Linq 9129
