  • Page 1 LUMA 6766 & 6767 ™ MODESTY PANEL USER MANUAL LET’S GET STARTED. DESIGN BDI DESIGN STUDIO...
  • Page 2 Congratulations on the purchase of your Luma modesty panel from BDI. Your panel has been designed to provide a lifetime of enjoyment. This manual will provide assembly instructions and other helpful information to ensure you get the most out of your product.
  • Page 3 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface, such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI retailer.
  • Page 4 Attach the Wire Trough (C2) to the Panel (C1) using the 4 Screws (H1) and tighten with Hex „ Wrench (T1). 1.5" 38 mm Desktop Position 1 Position 2 6.34" 161 mm 4.84" 123 mm Desktop Position 3 Position 4 4 | BDIUSA.COM LUMA 6766 & 6767...
  • Page 5 STEP 2. PRE-INSTALL SCREWS FOR TROUGH ATTACHMENT ASSEMBLY Locate the 2 sets of holes closer to the „ center of the Rear Tube of the desk frame. HEX WRENCH – T1 Insert 1 Screw (H2) in the outer hole of each „...
  • Page 6 Slide the Modesty Panel Assembly onto the „ heads of the 2 Screws (H2). HEX WRENCH – T1 Thread the remaining 2 Screws (H2). „ Tighten all Screws with Hex Wrench (T1). „ SCREW – H2 6 | BDIUSA.COM LUMA 6766 & 6767...

  • Page 7: Care And Maintenance

    While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please avoid positioning your BDI cabinet in any area with ample direct sunlight.

  • Page 8: Warranty

    Select chairs carry coverage for five (5) years from the date of the product delivery, based on an 8-hour daily use pattern. BDI reserves the right to refine or update its warranty from time to time. See the complete and latest warranty document at www.bdiusa.com/warranty.
